- Page 1 Translation of the Original Operator‘s Manual GREEN FIT Using the GREEN FIT Controller Software Version 1.2.12 Item # 560666 Version EN 3.0 April 2020 Corresponds to version DE 3.0 www.reichhardt.com...
- Page 2 Reichhardt GmbH. Any type of reproduction, distribution or storage on data storage devices in any form and type which has not been authorized by Reichhardt GmbH constitutes a violation of the applicable national and international co- pyright and will be prosecuted.
-
Page 3: Table Of Contents
Safety Instructions on Electrics ........................7 Safety Instructions for Hydraulics (for Hydraulic Steering Systems) ............8 Safety Instructions for Commissioning and Operation ................8 GREEN FIT Application ..................9 GREEN FIT Icon and its different Statuses ....................9 Warning Messages ..........................9 Start Screen ............................10 Main Menu ............................11 Teach Menu ............................12... -
Page 5: General Information
Service Manual GREEN FIT Personnel concerned with calibration of GREEN FIT have to comply with all information given in the service manual. Operator’s Manual GREEN FIT Personnel concerned with operation of GREEN FIT have to comply with all information given in the oper- ator’s manual. -
Page 6: Understanding The Manual
The signal word NOTICE indicates important information that, if disregarded, can result in property damage or malfunction of GREEN FIT or the vehicle. Follow these instructions to ensure long life and proper func- tionality of GREEN FIT and the vehicle. -
Page 7: Warranty And Liability
Service and Repair If you have any questions concerning GREEN FIT as well as the ordering of system supplements or spare parts, please contact your dealer or the manufacturer. Always notify the dealer or Reichhardt immediately in case of damage to the product. -
Page 9: For Your Own Safety
Intended Use The sole purpose of GREEN FIT is to connect the John Deere AutoTrac™ components to an existing steering equipment interface or to a hydraulic valve supplied by Reichhardt for the use of John Deere AutoTrac™, in ac- cordance with the intended use of AutoTrac™. -
Page 10: Safety Instructions For Installation And Service
• Look out for damaged or incorrectly installed electrical lines. These may cause severe electric shocks. • Obtain parts to be replaced (hoses, screws, brackets, etc.) only via Reichhardt, to ensure proper function and safety of the vehicle and GREEN FIT. -
Page 11: Safety Instructions On Electrics
Safety Instructions on Electrics When performing works on the electrical system of the vehicle, you need to disconnect the power supply of the vehicle for safety reasons. Switch off the battery master switch. If there is no switch or if you want to perform welding works on the vehicle or works in the vicinity of the battery, you need to disconnect the battery. -
Page 12: Safety Instructions For Hydraulics (For Hydraulic Steering Systems)
Damaged hose lines must not be repaired nor be put together from old, already used components. Replace old, worn or damaged hose lines immediately by components approved by Reichhardt. The period of use for hydraulic hoses should not exceed six years (operational life including a maximum of two years of storage time). -
Page 13: Green Fit Application
GREEN FIT Application Using the software of the GREEN FIT controller, you can make vehicle-specific settings and read out informa- tion on the system. NOTICE The figures shown in these instructions have been created on a GreenStar terminal GS3 2630 using software version 3.36.1073. -
Page 14: Start Screen
Start Screen As soon as the application has been fully loaded and there are no errors, the start screen is display- ed (see Fig. 4). Tap the wrench key (F) in order to get to the main menu. Fig. 4: Start screen PAGE 10... -
Page 15: Main Menu
Main Menu The following menu points are available in the main menu (see Fig. 5): A: Teach menu B: Terminal configuration C: Diagnostics D: System information E: Unlock system (unlock code)* The activation of the software is reserved exclusively for aut- horized technical personnel. -
Page 16: Teach Menu
Teach Menu WARNING Risk of injury due to deactivation of the automatic steering! If you open the Teach menu during the automatic steering process, automatic steering is immediately stop- ped. The vehicle will move forwards without being steered. Before any travel, go back to the main menu or the start screen of the application using the ESC key. Call up the Teach menu only when the vehicle is at a standstill. -
Page 17: 3.5.1 Detect Vehicle Code
3.5.1 Detect Vehicle Code In the vehicle code menu, you can read out the ve- hicle code and rename the vehicle. With the vehicle code vehicle-specific parameters are set in the system. These include the vehicle di- mensions. Tap the tractor symbol (A) in the Teach menu (see Fig. -
Page 18: Teach Basic Settings (Isobus Delay Time)
3.5.2 Teach Basic Settings (ISOBUS Delay Time) In the basic settings you can set the delay time of the power supply for ISOBUS devices after the ignition is switched off. This ensures that the John Deere terminal shuts down correctly, even if the vehicle does not provide a standard delay time. -
Page 19: Terminal Configuration
Terminal Configuration In the terminal configuration, among other things, you can select a VT (virtual terminal) for the display of GREEN FIT. Tap the VT symbol (B) in the main menu (see Fig. 14) to open the terminal configuration. The terminal configuration is arranged on two pages which you can scroll using the arrow keys. - Page 20 CAN bus 2 and if this is permitted by the vehicle code. • Change VT: Press the select button to select the terminal on which GREEN FIT shall be loaded (active VT) from several available VTs. By repeatedly tapping the “Next” button, the dif- ferent selection options (active and available VT) can be displayed (see Fig.
-
Page 21: Diagnostics
Diagnostics The diagnostics menu provides you with an overview of the current state of the system. Additionally, it supports you in locating malfunctions. Tap the diagnostics symbol (C) in the main menu (see Fig. 19) to open the diagnostics menu. The diagnostics is arranged on five pages which you can scroll using the arrow keys: •... - Page 22 System Overview of the current operating status of GREEN FIT (see Fig. 22). Fig. 22: Diagnostic page “System” Error History The last 20 occurred in the system are recorded in the error history. This information can be used for diagnostic purposes.
-
Page 23: System Information
System Information The “System information” provide details about the service partner responsible for you. Select the i symbol (D), to access the system infor- mation (see Fig. 25) and display the service partner (see Fig. 26). Fig. 25: Accessing system information Fig. -
Page 25: Error List
GREEN FIT Controller troller to GPS-receiver - fuse B6.1 or B6.2 defective - check fuses in the GREEN FIT Con- troller - no power at receiver - check the signals from the GPS re- ceiver to be evaluated (NMEA 0183,... - Page 26 - Short circuit in cable. - Inspect 2nd angle sensor. sensor. - Open wire in cable. - Check cables from GREEN FIT Con- troller to wheel angle sensor. - Sensor is defective. - If all connections are good, replace - Contacts of connectors are ope- wheel angle sensor.
- Page 27 Lock valve left – open wire - Lock valve is defective. - Inspect lock valve. - Open wire in cable. - Check cables from GREEN FIT Con- troller to lock valve. - Contacts of connectors are ope- ned. - Check contacts of connectors.
- Page 28 Troubleshooting 2200 Footswitch error - Footswitch defective. - Check footswitch - Short circuit in cable. - Check cables from GREEN FIT Con- troller to footswitch - Footswitch engaged too long or stuck. 2201 Activation switch error Engage switch is in error.
- Page 29 No life message is received from contact Reichhardt support the ATP module. 2330 CLAAS XERION – communica- GREEN FIT doesn‘t receive any check cables from GREEN FIT control- tion error information from XERION ler to vehicle 2. CAN bus 2335 CLAAS LEXION – communica- GREEN FIT doesn‘t receive any...
- Page 30 No ISO-VT connected or switched check cables from GREEN FIT control- ler and ISO-VT. 4000 No communcation to Terra no CAN information is received - check cables from GREEN FIT con- Variant fromTerra Variant troller to Terra Variant - check vehicle code 4010...
- Page 31 Description Cause Troubleshooting 4013 Invalid resume switch state invalid resume switch state - check cables from GREEN FIT con- with Kubota M7 troller to M7 VCU2. - check resume switch 4020 Braud – Field / Road Switch status road is active...
- Page 32 - Check setup, type of detection for direction of travel. 9991 task 1 runtime error task 1 requires too much time contact Reichhardt support 9992 task 2 runtime error task 2 requires too much time contact Reichhardt support 9993...
