  • Page 1 INSTRUCTION MANUAL...

  • Page 2: Table Of Contents

    EXPLODED VIEWS AND PARTS LIST FRONT ASSEMBLY........14 The exploded views and parts lists for the Serpent Viper 989E are presented in the Reference Guide section CENTER ASSEMBLY........22 in the back of this manual. The exploded views show all the parts of a particular assembly step along with MOTORMOUNT ASSEMBLY......24...
  • Page 3 HOW TO USE THE MANUAL LINES DESCRIPTION ICONS DESCRIPTION Each step contains a variety of numbers, lines, and symbols. The numbers represent the order in Each step contains a variety of symbols described below. which the parts should be assembled. The lines are described below. Step number;...

  • Page 4: Rear Assembly

    REAR ASSEMBLY STEP 1 STEP 2 BAG 1 M3x6 M4x8 M3x6 M3x8 M3x6 M3x8 M4x8...
  • Page 5 STEP 3 STEP 4 M4x10 M4x8 32.5mm M4x10 M4x8...
  • Page 6 STEP 5 STEP 6 BAG 2 M3x8 2.5x22 M4x8 2.5x22 M4x8 M3x8...
  • Page 7 STEP 7 STEP 8 M3x10 Note that the rear solid axle M3x8 excenters are not symetrical and are market with L (=left) and R (=right). LEFT RIGHT M3x8 12x18x4 Use the central slot as 12x18x4 starting position M3x8 M3x8 M3x10 M3x8 12x18x4...
  • Page 8 STEP 9 Fully tighten the M3x3 setscrews M3x10 after adjusting the rear antiroll bar play to the minimum. M3x3 i t t until the step 10.2 M3x3 5X8X2.5 M3x3 M3x10 5x8x2.5...
  • Page 9 STEP 10 BAG 3 10.1 10.3 2.5x12 3x22 M3x4 10.2 12x15x0.25 1- Note orientation of the outside wheel axle shim. 12x18x1 i t i lever spring. 12x18x4 12x18x4 2.5x12 3x22 M3x4 12x15x0.25 12x18x1 Conical 12x18x4...
  • Page 10 STEP 11 REAR TRACK WIDTH 3 mm 3.3 mm...
  • Page 11 STEP 12 12.1 12.2 M3x18 M3x18 11.5 mm M3x8 M3x8 M3x18...
  • Page 12 STEP 13 BAG 4 13.1 M4x8 M4x8 M4x8...
  • Page 13 STEP 14 Adjust the position of the side 14.1 14.2 M5x4 pulley to have a little play on the 2-speed shaft. M4x4 8x16x5 8x16x5 M4x4 M5x4 8x16x5...

  • Page 14: Front Assembly

    FRONT ASSEMBLY STEP 15 STEP 16 BAG 5 16.1 M2.5x6 16.2 12x18x4 M4x8 M4x8 12x18x4 M4x8 M2.5x6 12x18x4...
  • Page 15 STEP 17 STEP 18 M3x12 18.1 5x8x2.5 3x6x3 M3x10 Flanged M3x10 5x8x2.5 M3x18 M3x6 Flanged 18.2 8x14x4 Flanged 8x14x4 Flanged 18.3 Use the central slot as starting position. M4x8 M3x6 M3x10 M3x12 M3x18 M4x8 3x6x3 5x8x2.5 5X8X2.5 Flanged Flanged 8x14x4 Flanged...
  • Page 16 19.3 FRONT ANTIROLL BAR ROD LENGTH M3x6 Serpent 989 alows to move front bottom arms 3 mm in (NARROW) and out (WIDE). To maintain the same shock angle, use the suspension bracket and shock bracket as shown here. WIDE NARROW 28 mm 19.2...
  • Page 17 STEP 20 20.1 20.3 FRONT ANTI -ROLL BAR ASSEMBLY M3x3 FRONT DOWN STOPS M3x3 M3x12 3.3 mm M3x8 20.2 M3x3 5x8x2.5 M3x3 M3x3 M3x8 M3x12 5x8x2.5...
  • Page 18 STEP 21 STEP 22 BAG 7 21.1 21.2 22.1 22.2 M3x8 6X10x3 M3x6 M3x6 M3x6 9 mm 6X10x3 Nylock nut REARWARD FORWARD Preload the servo- saver-spring 1mm. 1 mm M4X8 M3x6 M3x6 M3x8 Nylock Nut M3 M4x8 6x10x3...
  • Page 19 FRONT ASEMBLY II STEP 23 STEP 24 M4x4 M3x10 3x6x1 INSIDE OUTSIDE RIGHT LEFT RIGHT LEFT RIGHT LEFT M4x4 3x6x1 M3x10...
  • Page 20 STEP 25 BAG 8 2.5x12 25.1 25.2 Nylock 12x15x0.25 nut M3 3.2x7x0.5 12x18x4 5 pcs 12x18x4 12x18x0.3 M3x12 M3x4 i t i lever spring. STEERING BLOCK INSERTS CHART 3x20 LEADING NEUTRAL TRAILING RIGHT 25.3 ACKERMANN POSITION LEFT 3x6x1 M3x8 3x20 M3x4 2.5x12 3x6x1...
  • Page 21 STEP 26 STEP 27 FRONT CAMBER AND TRACK WIDTH 6.8 mm 45.5 mm 7 mm...

  • Page 22: Center Assembly

    CENTER ASSEMBLY STEP 28 STEP 29 BAG 9 M3x6 M3x6 3x6x3 M3x6 M3x6 M3x10 M3x10 M3x6 M3x6 M3x10 3x6x3...
  • Page 23 STEP 30 M4x4 M4x4 M4x8 M4x8 M4x4 M4x8...

  • Page 24: Motormount Assembly

    MOTORMOUNT ASSEMBLY STEP 31 STEP 32 Nylock nut M3 3x6x6 M5x4 M3x20 M3x5 M3x6 2.5x12 M3x6 M3x5 M3x10 2.5x12 M3x6 3x6x6 Nylock Nut M3 M5x4 M3x6 M3x20 M3x10 M3x5...

  • Page 25: Radio Assembly

    RADIO ASSEMBLY STEP 33 STEP 34 M4x8 M3x6 M3x6 M3x5 M3x5 M3x16 M3x8 Flanged M3x5 M3x5 M3x8 M3x6 M3x6 M3x16 Flanged M4x8...

  • Page 26: Shocks Assembly

    SHOCKS ASSEMBLY STEP 35 STEP 36 SHOCKS BAG 35.1 35.2 36.1 Use some silicone oil For the correct piston during the assembly. holes please check the default setupsheet. Insert the o-ring inside the spring collar. 36.2 Use some silicone oil during the assembly.
  • Page 27 STEP 37 STEP 38 37.1 37.3 Push the shock top and 1-Bleed: push shockrod all the way the membrane into the shock cap. in slowly, to allow Assemble the spring and spring- excessive oil to escape. cup (align correctly) to complete the shock.

  • Page 28: Final Assembly

    FINAL ASSEMBLY STEP 39 STEP 40 BAG 10 M3x6 Nylock nut M4 M3x8 M4x12 M4x10 Flanged Nylock Nut M3x6 M3x8 M4x12 M4X10 Flanged...
  • Page 29 STEP 41 STEP 42 Do not overtighten Do not overtighten the M3x10 M3x6 Flanged screws. screws to prevent binding. M3x10 M3x10 M3x10 M3x10 M3x6 M3x10 M3x10 M3x6 Flanged M3x6 M3x6 M3x10 M3x10 Flanged...
  • Page 30 STEP 43 M3x4 M3x4 M3x6 M3x4 M3x6...
  • Page 31 STEP 44 M3x10 M3x10...
  • Page 32 STEP 45 M3x8 M3x6 M3x8 M3x6 M3x8...

  • Page 33: Exploded Views

    EXPLODED VIEWS INDEX SHCOKS EXPLODED VIEW REAR EXPLODED VIEW FRONT I EXPLODED VIEW FRONT II EXPLODED VIEW RADIO EXPLODEDE VIEW BUMPER AND BODYMOUNT EXPLODED VIEW FINAL EXPLODED VIEW TEAM SERPENT NETWORK...
  • Page 34 SHOCKS EXPLODED VIEW 903741 Shockset XLV short (2) 903720 160139 903744 909405 903788 opt 160146 160141 160324 6442 160140 160138 110437 903746 160154 160300 opt 160123 160302 opt 160305 opt 160134 160306 903777 opt 903778 opt 903779 opt 160122 160311 opt 160147 Shock onroad big bore bushing LF (4) 160310 Spring-set short (5x2) 160329 Spring black L27 (10/57) (2)
  • Page 35 REAR EXPLODED VIEW 110206 904194 110504 903509 903722 opt 110305 110305 903666 110504 903509 110124 110109 1311 110124 110109 110116 903686 903691 903343 903690 110116 903739 903738 110159 903341 110124 903395 110124 903273 903675 903263 903395 903515 903693 903553 903679 903687 110433 902282...
  • Page 36 FRONT I EXPLODED VIEW 903669 1311 903723 1312 110159 110109 901255 903754 804332 110306 903756 110417 903721 903794 1394 110112 1394 110172 903505 903513 110306 9212 903574 903509 110504 110199 903505 110504 110112 110124 110116 110112 903795 9212 110124 903509 1311 903691 903343...
  • Page 37 FRONT II EXPLODED VIEW 903740 1321 902134 903568 903790 opt 110122 110124 903568 110108 411207 902138 903589 opt 411207 903568 902139 902128 401025 411206 808214 110118 902135 903563 903231 1321 903612 opt 110109 903782 903678 808214 110449 110102 1652 903702 opt 110449 110401 903508...
  • Page 38 RADIO EXPLODED VIEW 110108 904190 804332 903756 902157 804332 904189 1606 110118 903737 110118 110108 903737 110402 110448 110417 904188 804514 110140 110122 904191 804512 opt 804513 opt 110122 804515 opt 110128 804516 opt 904187 110306 401687 110122 904192 110108 600263 110128 904186...
  • Page 39 BUMPER AND BODYMOUNT EXPLODED VIEW 903538 903706 903502 110403 110115 903719 903536 903724 110109 110172 903741 903379 opt 903663 opt 1650 903718 110172 903521 903537 110108 110137 909345 110124 110109 903619 110169 909345 110109 903741 1650 110108 808152 110109 1650 110105 903741 903379 Bumper 966 aero with inserts L+R...
  • Page 40 FINAL EXPLODED VIEW 905122 904136 401653 110122 110104 110129 110118 110104...

  • Page 41: Team Serpent Network

    ANNIV ERSAR Y TEAM SERPENT NETWORK www.serpent.com/903019/spares/ www.serpent.com/903019/Optionals/ www.serpent.com/product/Tools/ www.serpent.com/product/Merchandising/...
  • Page 42 SERPENT WEBSITE AND BLOG www.serpent.com www.teamserpent.com www.dragon-rc.com SERPENT PROMO PAGES http://promo.serpent.com SERPENT FACEBOOK GROUPS http://promo.serpent.com/indexfb.htm SERPENT ADVANCED MANUALS http://promo.serpent.com/sam/ SERPENT SOCIAL MEDIA www.facebook.com/teamserpentrc www.youtube.com/user/SerpentMRC www.twitter.com/SerpentMRC www.plus.google.com/+SerpentModelcars/posts www.weibo.com/teamserpent...
  • Page 43 INSTRUCTION MANUAL Manual Viper 989E #57591-1...
