Chapter 1 – IP Telephone

INSTALL IP TELEPHONES

SUPPORTED IP
TELEPHONES
IPT Installation Manual Feb,, 2015
This document covers the installation of the IP5000-series IP Telephones
(IPTs) on IPedge and VIPedge systems. Unless indicated the procedures
for IPedge and VIPedge are the same. Install the IP Telephones and
cables with the same care and considerations as any other device
connected to the local network. Before installing any telephone wiring,
read the following caution notes:
CAUTION! When installing the station cable, do not run the cables
parallel to an AC power line if the lines are within three
feet. AC power lines should be crossed at right (90
angles only. In particular, avoid running station wire near
devices that generate electrical noise, such as neon or
fluorescent light fixtures.
CAUTION! Do not use cleansers that contain benzene, paint thinner,
alcohol or other solvents on the telephone's rubber feet.
The color of the rubber may transfer to the desk or
mounting surface.
Important! When installing the handset cord ensure that it is plugged
into the Handset connector. If the handset is plugged into
the Headset connector the telephone set will not function
correctly and can not be placed into programming mode.
The IPedge supports the IP5000-series telephones (IPT) and Add-On
Modules (ADM). Please refer to the IPedge General Description for more
information about each model IPT and ADM.
The VIPedge solution supports the IP5131-SDL, IP5531-SDL and
IP5631-SDL telephones. The VIPedge also supports the LM5110 Add-On
Module.
°
)
