Xrc 8 Winch Parts List - Smittybilt XRC8 Installation Manual

No. Parts No. Description
01 97281-01 Sun Gear-Input
02 97281-02 Gear Carrier-Input
03 97281-03 Gear Carrier-Intermediate
04 97281-04 Washer-1.2mm thickness
05 97281-05 Gear Carrier-Output
06 97281-06 Outer Spline
07 97281-07 Spline Positioning Bolt
08 97281-08 Drum
09 97281-09 Brake Positioning Bolt
10 97281-10 Brake System
11 97281-11 Coupling Joint
12 97281-12 Rotor
15 97281-15 Motor Long Bolts
16 97281-16 Motor End Cover
17 97281-17 Carbon Frame & Brush Assy
18 97281-18 Stator
19 97281-19 Tie Rod Bolt
20 97281-20 Motor Base
21 97281-21 Nylon Bearing
22 97281-22 Tie Rod
23 97281-23 Bolt
24 97281-24 Spring Washer
25 97281-25 Gear Box Base
26 97281-26 Gasket
Installation Manual

XRC 8 WINCH PARTS LIST

Qty No. Part No.
1 27
1 28
1 29
2 30
1 32
1 33
1 34
1 35
1 36
1 37
1 38
1 39
2 40
1 41
1 42
1 43
4 44
1 45
2 46
2 47
10 48
10 49
1 50
1
Description
97281-27 Inner Gear
97281-28 Clutch Gear
97281-29 Gear Box Tube
97281-30 Gasket
97281-32 Gear Box End Cover
97281-33 Bolt + Spring Washer
97281-34 Shaft Sleeve
97281-35 Washer
97281-36 Bearing
97281-37 Clutch Spring
97281-38 Locking Pin
97281-39 Clutch Lever
97281-40 Clutch Steel Ball
97281-41 Wire Rope
97281-42 Wire Rope Fix Bolt
97281-43 Screw
97281-44 Spring Washer
97281-45 Winch Mount Bolt
97281-46 Clevis Hook
97281-47 Roller Fairlead
97281-48 Fairlead Mount Bolt/Nut
97281-49 Control Box
97281-50 Remote Control
Qty
1
1
1
1
1
10
1
1
1
1
1
1
1
1
1
4
4
4
1
1
2
1
1
