Atlas - Single Robe Carcass
Assembly Instructions -
Dimensions
Width - 50cm
Depth - 59.5cm
Height - 212.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
152/9432
157/2537
157/9107
MADE IN
BRITAIN
Issue 2 - 05/02/14
Advertisement
Related Manuals for Argos Atlas 152/9432
Summary of Contents for Argos Atlas 152/9432
- Page 1 Atlas - Single Robe Carcass Assembly Instructions - 152/9432 Please keep for future reference 157/2537 157/9107 Dimensions Width - 50cm Depth - 59.5cm MADE IN Height - 212.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 2 - 05/02/14...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 34kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Top/Base (D2399A) (500 x 592mm) Fixed Shelf (D2401A) (468 x 590mm) Universal End Hanging Rail Back...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 The fixed shelf will Are you fitting 1 or 2 need to go here if Hanging Rails or, an you are fitting the Internal Chest or, a following:-...
- Page 6 Assembly Instructions Step 3 Only follow Steps 2 and 3 if you are only fitting 1 hanging rail or, an internal chest or, a shelf pack. Prepare the right end If you are fitting 2 hanging rails, follow Step 4 and 5. Refer to step 1 and, if you have chosen to fit 1 hanging rail or, an...
- Page 7 Assembly Instructions Step 5 Only follow Steps 4 and 5 if you are fitting 2 hanging rails. If you are just fitting 1 rail, follow Step 2 and 3. Prepare the right end Refer to step 1 and, if you have chosen to fit 2 hanging rails, screw 2 metal dowels into the...
- Page 8 Assembly Instructions Step 7 If you have fitted the 2 metal dowels in this Join the fixed shelf to position, the fixed the right side shelf will go here. Push the fixed shelf onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to...
- Page 9 Assembly Instructions Step 9 Note: Use the shallow Prepare the base mark holes to fit the feet. Screw the 4 feet into the shallow mark holes on the base using screws Finished front edge Step 10 Fit the base Attach the base the ends using 6 screws...
- Page 10 Assembly Instructions Step 12 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 11 Assembly Instructions Step 14 IMPORTANT The unit MUST be fixed to a wall Fit the bracket using the bracket supplied. To prevent possible The unit must be level and square overbalancing, we before fitting the bracket. recommend that this unit is secured to a suitable wall by use of the bracket...
- Page 12 Shelf Door Shelf Shelf If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2954...
