Operating Instructions
LED TV
Model No.
TH-49HX900Z
For more detailed instructions, please refer to [eHELP]
(Built-in Operating Instructions).
●
How to use [eHELP]
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and retain them
for future reference.
Please carefully read the "Safety Precautions" of this manual before use.
The images shown in this manual are for illustrative purposes only.
F0420-0
(p. 19)
English
FAS
TQB4GD0352
English
Advertisement
Table of Contents
Related Manuals for Panasonic TH-49HX900Z
Summary of Contents for Panasonic TH-49HX900Z
- Page 1 ● How to use [eHELP] (p. 19) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use.
-
Page 2: Table Of Contents
Contents Be Sure to Read Important Notice··················································· 3 Safety Precautions ··············································· 4 Accessories ························································ 7 Installing the TV ··················································· 7 Installing the wall-hanging bracket ··························10 Connections ·······················································10 Identifying Controls ··············································16 First time Auto Tuning···········································18 How to Use eHELP ··············································19 FAQs ································································20 Maintenance ······················································21 Specifications ·····················································22 English... -
Page 3: Important Notice
(excerpted from our privacy policy). We do this to protect our customers and the integrity of our Service as well as to protect the rights or property of Panasonic. If you wish ● For information about the trademarks, refer to to know more about the processing of your information [eHELP] (Search by Purpose >... -
Page 4: Safety Precautions
Mains plug and lead of the copyright or other such rights in that content. Warning Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, If you detect anything unusual, ability or intention to obtain such permission on your immediately remove the mains behalf. - Page 5 Keep these parts ● Do not use an unapproved pedestal / mounting out of reach of young children. equipment. Be sure to ask your local Panasonic ■ dealer to perform the setup or installation of approved Pedestal wall-hanging brackets.
- Page 6 ■ ■ Built-in wireless LAN Moving the TV Caution Caution ● Do not use the built-in wireless LAN to connect to any Before moving the TV, disconnect all cables. wireless network (SSID*) for which you do not have ● At least two people are required to move the TV to usage rights.
-
Page 7: Accessories
Accessories Installing the TV Standard accessories Assembling / Removing the pedestal Make sure the following accessories are included with Preparations your TV. If any items are missing, contact your dealer. Take out the pedestal and the TV from the packing case 1. - Page 8 Style2 English...
- Page 9 Removing the pedestal from the TV Be sure to remove the pedestal in the following procedures when you use the wall-hanging bracket or repack the TV. 1 Put the TV onto a work table with the screen panel down on the clean and soft cloth. 2 Pull out the pedestal from the TV.
-
Page 10: Installing The Wall-Hanging Bracket
Installing the wall- Connections hanging bracket ● External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the Choosing to wall mount the TV shall be done at the mains socket before attaching or disconnecting any owner’s risk. - Page 11 Terminals Basic connections ■ Mains lead AC 220-240 V 50 / 60 Hz Mains lead (supplied) Insert the mains plug firmly into place. ● When disconnecting the mains lead, be absolutely sure to disconnect the mains plug from the mains socket first.
- Page 12 ■ Satellite dish Network A broadband network environment is required to be able to use internet services. ● If you do not have any broadband network services, please consult your retailer for assistance. ● Prepare the internet environment for wired connection or wireless connection.
- Page 13 ■ ■ [HDMI Auto Setting] (Setup Menu) Camcorder / Game equipment Reproduces the image more precisely with the expanded colour gamut when connecting the 4K compatible equipment. Select the mode depending on the equipment. (Viewing) [Mode1]: For better compatibility. Set to [Mode1] when the image or sound in HDMI input is not played properly.
- Page 14 ■ Headphones Cable arrangement ● To use the headphones, set [Headphone Terminal Fix the cables using the cable clamp, cable tie, etc. and Output] to [Headphone]. then attach the terminal cover / rear cover to the TV. ■ Fixing the cables using the cable band (3.5 mm stereo mini plug) ■...
- Page 15 ■ Attaching the terminal cover / rear cover ● Be careful not to nip the cables between the TV and the terminal cover / rear cover. ● When using USB 2 port, USB 3 port, HDMI3 terminal or HDMI4 terminal, you cannot attach the terminal cover.
-
Page 16: Identifying Controls
Identifying Controls 7 OK ● Confirms selections and choices. 8 [Option Menu]: ● Easy optional setting for viewing, sound, etc. 9 Coloured buttons (red-green-yellow-blue) Remote Control 10 Volume Up / Down 11 Numeric buttons 12 [eHELP] ● Built-in Operating Instructions 13 [MY APP]** 14 Input mode selection ●... - Page 17 Indicator / Control panel ● When pressing 4, 5, 6 buttons, the control panel guide appears on the right side of the screen for 3 seconds to highlight which button has been pressed. 2, 3 Rear side of the TV 1 Power LED Red: Standby Green: On...
-
Page 18: First Time Auto Tuning
First time Auto Tuning Set up the network connection Tick the TV signal mode to tune, and then select [Start Auto Tuning] If satellite TV is selected, select your preferred When the TV is turned on for the first time, it will Satellite TV search mode automatically search for available TV channels and give Select your region (Satellite) -
Page 19: How To Use Ehelp
How to Use eHELP ● To scroll the description (if more than 1 page) While the description is highlighted [eHELP] is the detailed operating instructions built into the TV, and gives a more detailed explanation for a better understanding of the operation of each feature. ●... -
Page 20: Faqs
● Check all required cables and connections are firmly About the inquiry in place. ● Please contact your local Panasonic dealer for assistance. An unusual image is displayed If you make an inquiry from a place where this TV ●... -
Page 21: Maintenance
Maintenance First, remove the mains plug from the mains socket. Display panel, Cabinet, Pedestal Regular care: Gently wipe the surface of the display panel, cabinet, or pedestal by using a soft cloth to remove dirt or fingerprints. For stubborn dirt: (1) First clean the dust from the surface. -
Page 22: Specifications
Specifications Specification TH-49HX900Z Dimensions 1 095 mm × 690 mm × 197 mm (With Pedestal) (W x H x D) 1 095 mm × 638 mm × 44 mm (TV only) 16.0 Net (With Pedestal) Mass 15.5 Net (TV only) Power Rating AC 220-240 V, 50 / 60 Hz 0.85 A... - Page 23 WARRANTY - New Zealand only NEW ZEALAND Distributed in New Zealand by Panasonic New Zealand Limited 18 Sir Woolf Fisher Drive, Highbrook, East Tamaki, Private Bag 14911, Panmure, Auckland Tel. 09 272 0100 Customer Care Center Email: Customerservice@nz.panasonic.com www.panasonic.co.nz...
- Page 24 Warranty Service purposes. Model Number Serial Number English Web Site: http://www.panasonic.com Printed in Malaysia © Panasonic Corporation 2020 04-2020...
