- Page 1 Inspiron 11 3195 2-in-1 Setup and Specifications Regulatory Model: P31T Regulatory Type: P31T001...
- Page 2 Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
-
Page 3: Table Of Contents
Contents 1 Set up your Inspiron 3195 2-in-1..................... 4 2 Views of Inspiron 3195 2-in-1......................6 Right......................................6 Left......................................6 Base......................................7 Display..................................... 8 Bottom....................................9 Modes..................................... 9 3 Specifications of Inspiron 3195 2-in-1.................... 11 Dimensions and weight.................................11 Processors..................................... 11 Chipset....................................11 Operating system................................. -
Page 4: Set Up Your Inspiron 3195 2-In-1
Set up your Inspiron 3195 2-in-1 NOTE: The images in this document may differ from your computer depending on the configuration you ordered. 1. Connect the power adapter and press the power button. NOTE: To conserve battery power, the battery might enter power-saving mode. Connect the power adapter and press the power button to turn on the computer. - Page 5 Resources Description SupportAssist Proactively checks the health of your computer’s hardware and software. The SupportAssist OS Recovery tool troubleshoots issues with the operating system. For more information, see the SupportAssist documentation at www.dell.com/support. NOTE: In SupportAssist, click the warranty expiry date to renew or upgrade your warranty. Table 2.
-
Page 6: Views Of Inspiron 3195 2-In-1
Views of Inspiron 3195 2-in-1 Right 1. Headset port Connect headphones or a headset (headphone and microphone combo). 2. USB 2.0 ports (2) Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 480 Mbps. Left 1. -
Page 7: Base
Base 1. Speakers Provide audio output. 2. Left-click area Press to left-click. 3. Touchpad Move your finger on the touchpad to move the mouse pointer. Tap to left-click and two finger tap to right-click. 4. Right-click area Press to right-click. Views of Inspiron 3195 2-in-1... -
Page 8: Display
Display 1. Left microphone Provides digital sound input for audio recording and voice calls. 2. Camera Enables you to video chat, capture photos, and record videos. 3. Camera-status light Turns on when the camera is in use. 4. Right microphone Provides digital sound input for audio recording and voice calls. -
Page 9: Bottom
Bottom 1. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. Modes Notebook Views of Inspiron 3195 2-in-1... - Page 10 Tablet Stand Tent Views of Inspiron 3195 2-in-1...
-
Page 11: Specifications Of Inspiron 3195 2-In-1
Specifications of Inspiron 3195 2-in-1 Dimensions and weight Table 3. Dimensions and weight Description Values Height: Front 17.30 mm (0.68 in.) Rear 19.15 mm (0.75 in.) Width 287.40 mm (11.31 in.) Depth 197.80 mm (7.79 in.) Weight (maximum) 1.21 kg (2.66 lb) NOTE: The weight of your computer depends on the configuration ordered and the manufacturing variability. -
Page 12: Operating System
Description Values Flash EPROM 8 MB PCIe bus Operating system • Windows 10 Home in S Mode • Windows 10 Home (64-bit) • Windows 10 Professional (64-bit) NOTE: Availability varies by country. Memory Table 6. Memory specifications Description Values Slots One SODIMM slot Type Single-channel DDR4... -
Page 13: Communications
Table 8. Internal ports and connectors Internal: One M.2 2230 slot for WiFi and Bluetooth combo card NOTE: To learn more about the features of different types of M.2 cards, see the knowledge base article SLN301626. Communications Wireless module Table 9. Wireless module specifications Description Values Model number... -
Page 14: Storage
Description Values Microphone Dual-array microphones Storage Your computer supports one of the following configurations: • One eMMC solid storage drive Table 11. Storage specifications Storage type Interface type Capacity One embedded MultiMediaCard (eMMC) Integrated on system board 64 GB or 128 GB Media-card reader Table 12. -
Page 15: Camera
Description Values Shortcut keys Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. To type the alternate character, press Shift and the desired key. To perform secondary functions, press Fn and the desired key. -
Page 16: Power Adapter
Power adapter Table 16. Power adapter specifications Description Values Type 45 W Diameter (connector) 4.5 mm Input voltage 100 VAC-240 VAC Input frequency 50 Hz-60 Hz Input current (maximum) 1.30 A Output current (continuous) 2.31 A Rated output voltage 19.50 VDC Temperature range: Operating 0 °C to 40 °C (32 °F to 104 °F) -
Page 17: Display
Description Values Coin-cell battery CR-2032 Operating time Varies depending on operating conditions and can significantly reduce under certain power-intensive conditions. Display Table 18. Display specifications Description Values Type High Definition (HD) Panel technology Twisted Nematic (TN) Luminance (typical) 200 nits (base panel); 170 nits(after bonding touch screen) Dimensions (active area): Height 256.13 mm (10.08 in.) -
Page 18: Video
Video Table 19. Video specifications Integrated graphics Controller External display support Memory size Processor AMD Radeon R5 Graphics One HDMI 1.4a port Shared system memory Generation AMD A9-9420e Computer environment Airborne contaminant level: G1 as defined by ISA-S71.04-1985 Table 20. Computer environment Description Operating Storage... -
Page 19: Keyboard Shortcuts
Keyboard shortcuts NOTE: Keyboard characters may differ depending on the keyboard language configuration. Keys used for shortcuts remain the same across all language configurations. Some keys on your keyboard have two symbols on them. These keys can be used to type alternate characters or to perform secondary functions. - Page 20 Table 22. List of keyboard shortcuts Function key Behavior Turn off/on wireless Pause/Break Sleep Toggle scroll lock Toggle between power and battery-status light/hard-drive activity light System request Open application menu Toggle Fn-key lock Page up Page down Home Keyboard shortcuts...
-
Page 21: Getting Help And Contacting Dell
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 23. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com Tips Dell Help & Support app NOTE: Availability varies by country.
