Operating & Installation
Fully Automatic Washing Machine
Model No.
Contents
Thank you for purchasing this
product.
- Read these instructions carefully for
optimum performance and safety
before use.
- Keep this manual for future reference.
Instructions
(Domestic use)
NA-F70B7
NA-F65B7
NA-F62B7
AWW9901A5900
A1704-1018
Printed in India
05-2019
2
3
4
5
6
7
8
9
10
12
14
15
16
Advertisement
Table of Contents
Related Manuals for Panasonic NA-F70B7
Summary of Contents for Panasonic NA-F70B7
-
Page 1: Table Of Contents
Operating & Installation Instructions Fully Automatic Washing Machine (Domestic use) NA-F70B7 Model No. NA-F65B7 NA-F62B7 Contents Safety Precautions Part Names Operation Panel Variety of Programs Detergent Washing Washing Options • Favorite • Delicate • Bed Sheets • Air Dry • Wash / Rinse / Spin... -
Page 2: Safety Precautions
Safety Precautions Read and follow these safety precautions. WARNING May cause serious injury or death. Avoid installation in humid place. Never disassemble, repair or modify the appliance yourself. (To prevent fire or electric shock) ● In case of malfunction or failure, immediately stop Do not allow children to use on their use, unplug the power cord, and ask your nearest own. -
Page 3: Part Names
Part Names Softener inlet CAUTION (P. 6) Lint filter (P. 10) Bleach / Liquid Power cord May cause injury or property damage. detergent inlet and plug (P. 6) (P. 13) Do not wash, rinse, or spin waterproof sheets or clothes. Operation (To prevent injury, damage to the main unit, walls, floor Panel (P. -
Page 4: Operation Panel
Operation Panel Reserve Water level/ Water level/ remaining time water amounts Water amounts Water Level F70B7 F65B7 F62B7 Indicates the selected program (No.) e.g.) 8 hours later 52 L 48 L 46 L 48 L 44 L ● Setting range: 2 - 24 hours later, in one-hour increments. -
Page 5: Variety Of Programs
Variety of Programs Maximum capacity Program Purpose NA-F70B7 NA-F65B7 NA-F62B7 Everyday clothes Normal * (P. 7) 7.0 kg 6.5 kg 6.2 kg • Daily washing Everyday clothes Favorite * (P. 8) • Washing with your saved preferred 7.0 kg 6.5 kg 6.2 kg... -
Page 6: Detergent
Detergent Detergent Put in detergent, bleach or softener at described location. Do not put detergent directly into the tub. Detergent may remain undissolved. ■ Liquid detergent/liquid bleach ■ Softener NOTE ● If powder detergent is poorly soluble, put detergent in the detergent inlet. ●... -
Page 7: Washing
Washing Preparation: ● Check if the washing machine is properly installed. (P. 12) ● Turn on the water faucet. Timer reservation After loading laundry Turn the power on. Select a program. (P. 5) operation. (P. 4) ● 2 minutes after start, all indications e.g.) Normal except “Reserve”... -
Page 8: Washing Options
Washing Options Favorite Delicate Use this program to save your preferred settings. Use this program to gently wash delicate clothes and stylish garments. Load laundry evenly. After loading laundry ● Load lighter items first and press Turn the power on. them from above. -
Page 9: Air Dry
Convenient Functions Air Dry Cancelling end buzzer Water is removed from clothes by the air blown Pressing down, from the tub rotation. ■ Clothes that can be dried press. • Material: Synthetic fibre • Weight: 2 kg or less Then hold on for After loading clothes and closing the lid 2 short 3 seconds. -
Page 10: Maintenance
● Do not wash laundry without the filter. (To prevent damage to clothes) ● Turn the tub by hand if it is difficult to remove the filter. ● If the filter is broken, purchase a new one at nearest Panasonic Service Centre. - Page 11 Water supply filter If water does not flow smoothly Once a week <Air Dry> ● Follow the procedure below to prevent After operation ends splashing of water. Run the Air Dry program without After turning off the water faucet loading laundry. (P. 9) Turn the Once a month <Tub Hygiene>...
-
Page 12: Installation
Installation 1. Check the location. ■ Avoid the following locations for installation. • Uneven or unstable locations (on blocks, timbers, a table with wheels, etc.) • Locations with a possibility of freezing Water tap adaptor 2. Attach the bottom cover. Preparation: Set a cardboard, etc. - Page 13 ■ If the installation, test run and inspection of the washing machine are not carried out following this installation method, Panasonic will not be liable for any accident or damage caused. 4. Connect the water tap adaptor and water supply hose.
-
Page 14: Error Display
Error Display ● The buzzer sounds and “U”/“H” and a number are alternately displayed. ● Cancel Child Lock (P. 9) if it is set. Error display Points to be checked Water cannot drain. Check the drain water hose for the following abnormalities: ●... -
Page 15: Troubleshooting
MEMO - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -... - Page 19 Troubleshooting Symptoms Points to be checked Time indication increases or ● Time indication is approximate. Remaining time is corrected does not change during operation and displayed. Operation time is longer than ● The operation time may be longer if laundry is concentrated the time indication.
- Page 20 525 mm (W) x 571 mm (D) x 929 mm (H) x 969 mm (H) Product weight 31 kg 30 kg Pressure of tap water 0.03 - 0.9 MPa (0.3 - 9 kgf/cm http://www.panasonic.com © Panasonic India Pvt. Ltd. 2019...
