Operating & Installation
Fully Automatic Washing Machine
Model No.
Contents
Thank you for purchasing this
product.
- Read these instructions carefully for
optimum performance and safety
before use.
- Keep this manual for future
reference.
Instructions
(Domestic use)
NA-F80VS7
NA-F76VS7
NA-F70VS7
W9901-9NN20
A0415-2046(V)
Printed in Vietnam
2
3
4
5
6
7
8
10
10
12
14
15
16
04/2016
Advertisement
Table of Contents
Related Manuals for Panasonic NA-F80VS7
Summary of Contents for Panasonic NA-F80VS7
-
Page 1: Table Of Contents
Operating & Installation Instructions Fully Automatic Washing Machine (Domestic use) NA-F80VS7 Model No. NA-F76VS7 NA-F70VS7 Contents Safety Precautions Part Names Operation Panel Variety of Programs Detergent Washing Washing Options • GIẶT NHẸ (Delicate) • CHĂN MÀN (Blanket) • SẤY BẰNG GIÓ 90' (Air Dry) •... -
Page 2: Safety Precautions
Safety Precautions Read and follow these safety precautions. WARNING Do not allow children to use on their own. ● This appliance is not intended for use by persons May cause serious (including children) with reduced physical, sensory injury or death. or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a... -
Page 3: Part Names
Part Names Lint filter (P. 10) CAUTION Power cord and plug Bleach / Liquid (P. 13) detergent inlet (P. 6) May cause injury or property damage. Operation Panel (P. 4) Do not wash, rinse, or spin waterproof sheets or clothes. (To prevent injury, damage to the main unit, walls, floor or laundry, or water leakage if the appliance falls over Softener... -
Page 4: Operation Panel
After approx. 5 seconds, indicates the the power is recovered. approximate remaining time (min). The lamp lights up when the operation resumes. • Operation panel of the NA-F80VS7 Wash/Rinse/Spin Program selection (P. 5) Start/Pause (P. 9) Child Lock lamp (P. 10) -
Page 5: Variety Of Programs
Variety of Programs Maximum capacity Purpose Program NA-F80VS7 NA-F76VS7 NA-F70VS7 Everyday GIẶT THƯỜNG Daily washing 8.0 kg 7.6 kg 7.0 kg clothes (Normal) (P. 7) GIẶT NHẸ Washing Delicates 3.5 kg 3.5 kg 3.5 kg (Delicate) delicates gently (P. 8) Clothes for babies &... -
Page 6: Detergent
Detergent Putting in detergent Put in detergent, bleach and softener according to the water ● When powdered detergent is poorly soluble, dissolve level displayed. in warm water before putting in. ● Follow the instructions on each package. • Put in the detergent little by little while stirring to prevent it from getting ■... -
Page 7: Washing
Washing Preparation: ● Check if the washing machine is properly installed. (P. 12) ● Turn on the water faucet. Timer preset After loading laundry Set how many hours later to finish Turn the power on. operation. (P. 4) Select a program. (P. -
Page 8: Washing Options
Washing Options Change process settings Select a program GIẶT NHẸ (Delicate) CHĂN MÀN (Blanket) ■ Use this program to gently wash delicate Washable blankets clothes and stylish garments. • Material: 100 % synthetic fibre or 100 % cotton • Weight: 4.2 kg or less •... -
Page 9: Sấy Bằng Gió 90' (Air Dry)
SẤY BẰNG GIÓ 90' (Air Dry) Wash/Rinse/Spin Water is removed from clothes by the air Preparation: Turn on the water faucet. blown from the tub rotation. After loading laundry ■ Clothes that can be dried • Material: Synthetic fibre Turn the power on. •... -
Page 10: Convenient Functions
NOTE ● If the filter is broken, purchase a new one at nearest Panasonic Service Centre. ● If there is water in the tub or “Start” is pressed, the ● Separate clothes following instructions (P.5) before tub cannot be turned. - Page 11 Water supply filter If water does not flow smoothly Once a week <SẤY BẰNG GIÓ 90' (Air Dry)> After operation ends NOTE Run the SẤY BẰNG GIÓ 90' ● Do not throw away or puncture the filter (Air Dry) program without to avoid damaging feeding valve.
-
Page 12: Installation
Installation 1. Check the location. ■ Avoid the following locations for installation. • Locations with a possibility of freezing • Damp locations or locations where it may be exposed to rain, etc. (To prevent electric shock or fire) • Uneven or unstable locations (on blocks, timbers, a table with wheels, etc.) Water tap adaptor 2. - Page 13 ■ If the installation, test run and inspection of the washing machine are not carried out following this installation method, Panasonic will not be liable for any accident or damage caused. 4. Connect the water tap adaptor and water supply hose.
-
Page 14: Troubleshooting
Troubleshooting Symptoms Points to be checked Time indication ● Time indication is approximate. Remaining time is corrected during increases or does not operation and displayed. change Operation time is longer ● The operation time may be longer if laundry is concentrated on one than the time indication. -
Page 15: Error Display
Error Display ● The buzzer sounds and “U”/“H” and a number are alternately displayed. ● Cancel Child Lock (P. 10) if it is set. Error display Points to be checked Water cannot drain. Check the drain water hose for the following abnormalities: ●... -
Page 16: Specifications
525 mm (W) × 571 mm (D) × 929 mm (H) Product weight 28 kg Pressure of tap water 0.01 - 1 MPa * Operation is guaranteed with the voltage fluctuation from 195 V to 245 V, but not for performance. http://www.panasonic.com © Panasonic Appliances Vietnam Co., Ltd. 2016...
