  • Page 1 Cirris CH2 User Manual...

  • Page 2: Table Of Contents

    Table of Contents THE CH2 TESTER ........................1 ................................1 NTRODUCTION High Voltage Warning ............................1 Medical Warning ..............................1 ..............................2 OLTAGE AFETY ..................................3 ARTS ............................3 CANNER ARTS GENERAL INFORMATION ....................... 4 ................................4 AINTENANCE ................................5...
  • Page 3 ..................................32 ..............................34 NSTRUCTIONS ......................38 NERGIZATION ERFORMANCE ERIFICATION ....................38 TEMS NEEDED FOR THE ERFORMANCE ERIFICATION ............................38 ELECTING OWER ESISTORS WARRANTY ......................... 52...

  • Page 4: The Ch2 Tester

    In order to mitigate the risk, the high voltage energy limit of the CH2 is 35 mJ and the high voltage charge limit is 45μC. These limits prevent circuits energized during high voltage testing from meeting the definition of hazardous or dangerous live points found in international standards.

  • Page 5: High Voltage Safety

    High Voltage Safety The restricted high voltage energy and charge limits of the CH2 do not mean that performing hipot testing with the system is entirely without risk as operators can still receive a startling or even painful shock. Therefore, it’s necessary and prudent to protect operators. Consider the following while recognizing it is not an exhaustive list.

  • Page 6: Parts List

    You may want to add these optional accessories You can purchase the listed accessories at computer and office supply stores. Each accessory is easy to integrate with your computer and CH2 test system to fit your requirements. ❑ Sheet Printer ❑...

  • Page 7: General Information

    Cirris support personnel, you may need to send the affected module or the entire tester back to Cirris for repair. If needed during the repair period, a loaner tester can be sent to you. You should not attempt to service any circuit board at the component level. All component-level service should be performed by Cirris technicians.

  • Page 8: Tester Symbols

    Conditions for Operation Your CH2 Tester is intended to be used indoors at a temperature of 50 to 104 degrees Fahrenheit (10 to 40 degrees Celsius). Best performance can be obtained at a relative humidity less than 70%. Insulation Resistance Measurements will degrade at over 70% relative humidity.

  • Page 9: Help

    HELP Accessing the Online Manual/Help System In addition to this user manual, the complete Easy-Wire manual is available in the Easy-Wire help system. Sections of the online manual may be printed if desired. 1. In the Easy-Wire software, click the Help button at the bottom of any window.
  • Page 10 Click Contents to view the Easy-Wire manual by chapter. • Click Search to find information using key words. • Click Contact to view the contact information for Cirris. • Click Website to view the Cirris website if you have an internet connection. Help 7...

  • Page 11: Easy-Wire Software

    USB 2.0 or 3.0 port (not required on server) • Internet connection: Not required, but if available, can facilitate support issues. For Easy-Wire station installation instructions, please see the Cirris Easy-Wire Software Manual – CH2 & CR. For Easy-Wire Server Installation Instructions, please see the Cirris Server Software Install guide.

  • Page 12: Setting Up The Tester

    Spaced apart: The units can be spaced apart to allow for a shorter interface cable to the device-under- test. For this type of configuration, you must order custom box-to-box cables from Cirris. The maximum total length of a box-to-box cable is 200 ft (60m).

  • Page 13: Electrical Assembly

    Digital I/O connector Note: CH2 testers made after March of 2007, have HV interlock capability. An interlock helps protect operators from high voltage during the high voltage test. For more information on interlocks, search the word “interlock” in the Easy-Wire help system.
  • Page 14 The power supply auto adjusts to line voltages of either 120 VAC 60 hertz or 240 VAC 50 hertz. For optimum measurement accuracy, the CH2 must have a consistent earth ground to the entire system. Make sure to use a grounded (3- prong) outlet or plug strip.

  • Page 15: Checking The System

    Enter the station name or server name (the station name will be used on reports generated by this station). Select Easy-Wire CH2 as tester that will be attached to this station. Important! Make sure you select the correct tester. If you...
  • Page 16 See “Troubleshooting a Red Status Indicator” on the next page. For other unresolved problems, see “Startup and Verify” in the help system, or call Cirris Technical Support at 1-800-441-9910. Connecting to a Network 13...

  • Page 17: Troubleshooting A Red Status Indicator

    2. Verify that the USB cable is connected between the computer and the Base Scanner. 3. Reboot the tester. If the problem persists, write down the error messages that appear after launching the software, and call Cirris for assistance. Connecting to a Network 14...

  • Page 18: Checking The Sound

    Checking the Sound The Easy-Wire software relies on sound prompts to provide test feedback to the operator. 1. In the Easy-Wire main menu, click the green status indicator. You should hear two trumpet sounds coming from the tester. 2. If you hear the sounds, skip to “Error! Reference source not found.”...
  • Page 19 Verify that the speakers are on and that the volume is turned up. • Verify that the volume on your PC is turned up (the PC volume control can be found on your Windows task bar). If the sound problem persists, call Cirris for assistance. Connecting to a Network 16...

  • Page 20: Adding Or Removing Scanner Modules

    2. Remove the four screws (two on each side) from the chassis. Lift the chassis top straight up and off the unit. Screws Base box Pictured here are the parts of the CH2 Power assembly system. There is a Base Box Assembly supply only in the Base Unit.
  • Page 21 4. Unplug all of the connectors from the Node/Scanner assembly. 5. Remove the Node/Scanner assembly. Set this assembly so the Node Module is facing down. Node module Separating Scanner Modules Terminator 1. Remove the Terminator from the last scanner in the assembly. General Information 18...
  • Page 22 2. While holding the scanner to be removed with one hand, press the retaining latch INWARD. Retaining latch 3. Insert a flat blade screw driver in the slot next to the retaining latch. Twist the screw driver to slightly separate the scanner.
  • Page 23 5. Lift the assembly straight up to remove it. Adding a Scanner 1. Align each tab on a Scanner Module with the corresponding slots in the previous module. Slot Terminator 2. Press the two assemblies together until the retaining catches lock. 3.
  • Page 24 Reassembling the Unit 1. Align the Scanner/Node assembly with the mounting pins in the chassis. 2. Attach all of the power cables to each of the modules 3. Make sure the TERMINATOR is in place on the last scanner in the stack. 4.

  • Page 25: Traditional Fixturing

    Cirris sales representative. Optional: Bi-color LEDs for guided assembly. You can either purchase discrete LEDs from a distributor or a strip of ten LEDs mounted on card stock from Cirris. Ask for p/n ELED-01. Connector Saver Sacrificial CH2 Connector Savers protect the pins in the CH2 tester from wear and damage.

  • Page 26: Building Fixturing For Fast Attach

    When to build fixtures Best practice is to build the mating fixture connecting the device-under-test (DUT) to the tester before creating the Test Program used for the test setup. Why? If you use Defined Connectors you can create connector and pin documentation by probing the pins of the fixture’s connectors while the fixture is attached to the tester, greatly speeding up test creation.

  • Page 27: Requirements For Using Fast Attach

    Requirements for using Fast Attach Fixture connectors that mate to the device-under-test must be wired in the same relative pattern to the system pins of the tester’s scanner connectors. What makes Fast Attach Connector Types different than the others? A Fast Attach Connector Type requires one more step in its construction, which is to set a wiring pattern describing the relative position of its pins to the pins on the scanner connectors of the tester.

  • Page 28: Four-Wire Fixturing

    Two-wire Test Four-wire Test • • Two-wire testing measures resistance at Four-wire testing measures resistance at the face of the CH2. the point where the 4-wire pairs come • together. Adds test lead resistance (R ) to Lead •...

  • Page 29: Requirements For Kelvin Points

    In order to fixture four-wire to the CH2, the two wires in each 4-Wire Pair must connect to two different kinds of test points called Visible and Hidden. Each Visible point has one specific Hidden mate and the two must go together.
  • Page 30 Mapping the Visible points to Hidden mates From any visible point, the next vertical point is its hidden pin mate. Now that you have built your fixturing, you are ready to Define Four Wire Connectors in the Easy-Wire software. Refer to the online manual/help system for more information on setting up a four-wire test program.

  • Page 31: Optional Capabilities

    Advanced Instructions Advanced Instructions are optional software capabilities that extend the standard functions of the CH2 system. The instructions are grouped into two categories - Common and Cirris CH2. Instructions for usage are provided in the CH2 Advance Instructions Manual.

  • Page 32: External Instruments

    External Instruments Two types of external instruments are available for use with the CH2 system – meters and programmable power supplies. Meters can be used to extend the tester’s measurement range, provide additional measurement capabilities or to improve measurement accuracy.

  • Page 33: Required Parts For Measuring Devices

    A Power Cable ❑ An External (comes with instrument) Instrument Interface Cable (from Cirris) Setting up and Attaching External Instruments Please see the CH2 Advanced Instructions Manual for instructions to set up, attach and program external instruments. Optional Capabilities 30...

  • Page 34: Energization Box

    ENERGIZATION BOX Introduction The CH2 Energization Box (E-Box) allows you to provide external power to points in your device-under-test. The E-Box also provides the CH2 with the ability to test relays, lamps, LED lights, and other similar components needing external power. CH2 systems can have an unlimited number of E-Box units.

  • Page 35: Required Parts

    3 lengths: ½ meter, 1 additional power supply meter, and 2 meters. Set Up E-Box 1. Put the CH2 E-Box on top of the CH2 Base, ensuring that each side is aligned. CH2 base 2. Attach the CH2 Base to the CH2 E- Box using the box-to-box cable.
  • Page 36 3. On the back of the E-Box, plug the power cable into the power connector and plug the other end into Power connector a grounded outlet. 4. For a fixed power supply, plug your Energization voltage fixed voltage power supply into the socket Energization Voltage socket on the back of the E-Box, power on the E-...
  • Page 37 E-Box Instructions Relay energization is accomplished by attaching test points on the CH2 base to energization points on the E-Box using instructions. The E-Box Instructions include: Actuate and Energize. Energization points are selected in a test program using the “Actuate” instruction in the Easy- Wire software.
  • Page 38 Energize Instruction The Energization instruction controls a switch inside the E-Box, which connects the energization supply to the energization switch point matrix. Use the Activate commands to connect the E-points of the device to be powered, and then turn on the power using the Energize “On”...
  • Page 39 Setting Up the Test 1. When you set up a test to use the E- Box, in the “Set Test Defaults” tab, change the Test Method to Energize Test. 2. If you are using a fixed power supply, skip to step 8. If you are using one or more variable power supplies, continue to steps 3-8.
  • Page 40 6. Select the Cable you attached from your Power Supply to your PC. If necessary, edit the parameters to match your Power Supply and click OK. 7. The “Custom Instruction” window will be open on your screen, click OK. Verify that the custom instruction has been added to the “Define Instructions”...
  • Page 41 You will be instructed to connect these resistors to the E-Box during the test. Cirris recommends using power resistors from the TMC series by Huntington Electric Inc. from digikey.com.
  • Page 42 To run the E-Box Performance Check test: 1. In the Easy-Wire main menu, click Utilities. 2. Click Import. 3. Click Import Text File. 4. Import the CH2E- BoxPerformanceCheck.TXT text file into your Easy-Wire software. 5. In the Easy-Wire main menu, select the E-Box Performance Check test and click Test.
  • Page 43 4. Attach the resistor that has an Ohm value equivalent to the power supply voltage divided by 2 and click OK. If the test passes, your E-Box is working correctly. If the test fails, call Cirris at 1-800-441-9910 for assistance. Optional Capabilities 40...
  • Page 44 CR / CH+ / CH2 Analyzer. ANY IMPLIED WARRANTIES ARISING OUT OF SALES OF THE CR / CH+ / CH2 ANALYZER,...
  • Page 45 Cirris CH2 User Manual Version 2020.3.2 © 2020 Cirris Systems Corporation 401 North 5600 West Salt Lake City, UT 84116 www.cirris.com...
