Lumination
LPL GenB Series
BEFORE YOU BEGIN
Read these instructions completely and carefully.
RISK OF ELECTRIC SHOCK
• Turn power off before inspection, installation or
removal.
• Properly ground electrical enclosure.
RISK OF FIRE
• Follow all NEC and local codes.
• Use only UL approved wire for input/output
connections. Minimum size 18 AWG (0.75mm2).
Save These Instructions
Use only in the manner intended by the manufacturer.
If you have any questions, contact the manufacturer.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
CAN ICES-005(A)/NMB-005(A)
Note: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
LED Luminaires
TM
WARNING / AVERTISSEMENT
RISQUES DE DÉCHARGES ÉLECTRIQUES
• Coupez l'alimentation avant d''inspecter, installer ou déplacer le luminaire.
• Assurez-vous de correctement mettre à la terre le boîtier d'alimentation
électrique.
RISQUES D'INCENDIE
• Respectez tous les codes NEC et codes locaux.
• N'utilisez que des fils approuvés par UL pour les entrées/sorties de
connexion. Taille minimum 18 AWG (0.75mm2).
Tools and Components Required
• Screwdriver
• UL approved conduit fittings
• UL approved twist-on wire connectors
Prepare Electrical Wiring
Electrical Requirements
• The LED luminaire must be connected to the mains
supply according to its ratings on the product label.
• Class 1 wiring should be in accordance with NEC.
Grounding Instructions
• The grounding and bonding of the overall system
shall be done in accordance to local electric code
of the country where the luminaire is installed.
1
Installation Guide
Advertisement
Related Manuals for GE Lumination LPL GenB Series
Summary of Contents for GE Lumination LPL GenB Series
- Page 1 Installation Guide Lumination LED Luminaires LPL GenB Series BEFORE YOU BEGIN Read these instructions completely and carefully. WARNING / AVERTISSEMENT RISK OF ELECTRIC SHOCK RISQUES DE DÉCHARGES ÉLECTRIQUES • Coupez l’alimentation avant d’’inspecter, installer ou déplacer le luminaire. • Turn power off before inspection, installation or •...
- Page 2 Luminaire Installation Carefully unpack unit from its packaging. Properly inspect for defects before installing. Wear work gloves to prevent dirt and oil from being transferred to the luminaire. Remove the fixture and driver box from the package. If a lumen level other than M (medium) is desired, remove switch cover and set to the desired lumen level and re-attach cover.
- Page 3 LPL 2X2 SERIES LPL 2X4 SERIES Insert the luminaire into the T-grid ceiling. Unit should not move freely within the ceiling grid. Safety cable hole T-Bar Bracket on back plate Bend the brackets on the back plate to make sure they hook to T-Bar.
- Page 4 NOTE: Please cover dimming leads with wire nuts if you will not connect with dimming leads. www.led.com GE and the GE Monogram are trademarks of the General Electric Company. All other trademarks are the property of their respective owners. Information provided is subject to change without notice. All values are design or typical values when measured under laboratory conditions.
