10. MAGS1 Error Code Table

MAGS1 can detect and show a number of errors in one error code value.
Error position
0
1
2
3 – 6
7
8 – 12
13
14-15
Errors in Modbus register are indicated in hex format and have to be converted to binary
format!
Once the error code has been converted to binary format, each position is related to a different error
(see the table above). Number 1 indicates error and number 0 indicates no error.
Example:
Error shown in Modbus
register:
085HEX =
MAGS1 User Guide
Position 0
Position 1
Position 15
Error Description
Empty Pipe (Air Detect)
Overloaded
Excitation
RESERVED (non-use)
AD converter error
RESERVED (non-use)
Temperature error
RESERVED (non-use)
Error position:
76543210
10000101 BIN
25
Read errors:
AD converter / Excitation / Empty pipe
