Kids Ride-On Mercedes-Benz
AMG G63
Colours may vary
User Manual
[Revision 5.0 May 2020]
THE BATTERY MAY HAVE SOME CHARGE ON ARRIVAL, IT IS IMPORTANT
HOWEVER THAT THE BATTERY IS CHARGED PRIOR TO USE.
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY
E&OE
DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by
© 2020 Rovo Kids
this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kids Ride-On Mercedes-Benz AMG G63 and is the answer not in the manual?

Questions and answers

Ulrik.Coessens
February 6, 2025

Can you provide the references for the battery as the original battery needs to be replaced. What is the product number for the battery, what are its specs, for replacini by an original battery or a valabele alternative

0

Related Manuals for Rovo Kids Kids Ride-On Mercedes-Benz AMG G63

Summary of Contents for Rovo Kids Kids Ride-On Mercedes-Benz AMG G63

  • Page 1 READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY E&OE DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by © 2020 Rovo Kids this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.

  • Page 2: Safety

    Kids Ride-On Mercedes-Benz AMG G63 Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols: You WILL be KILLED or...
  • Page 3 Kids Ride-On Mercedes-Benz AMG G63 General Electrical Safety General Electrical Safety General Service Information • Inspect electrical equipment, extension • Electrically grounded equipment must have • The equipment must be serviced or cords, power bars, and electrical fittings for an approved cord and plug and be repaired at authorised service centres by damage or wear before each use.
  • Page 4 Kids Ride-On Mercedes-Benz AMG G63 • In order to avoid accidents, please ensure the vehicle is safe before riding. • Do not let any child touch the wheels or be near them when the car is moving. • This vehicle has adjustable play seat belts. please instruct children how to tie the safety belt before using, guarantee the security.

  • Page 5: Safety Symbols

    Kids Ride-On Mercedes-Benz AMG G63 Safety Symbols The product may have safety warning labels attached to it, explained below. Understand the symbols on your product and their meanings. If any stickers become unreadable, unattached etc., replace them. Flammable Material Hazard...
  • Page 6 Kids Ride-On Mercedes-Benz AMG G63 Carbon-Monoxide Hazard Pull Hazard Slope / Fall Injury Hazard "Slam Dunk" Warning Do not use the product in Be aware that the product Be aware that using the product Do NOT attempt "slam dunk" confined areas or without...

  • Page 7: Table Of Contents

    Kids Ride-On Mercedes-Benz AMG G63 Table of Contents Safety ................................2 Safety Symbols ................................5 Parts Identification ............................8 Assembly ............................... 9 Installing the Front Axle .............................. 9 Installing the Front and Rear Wheels ........................10 Installing the Seat and Rear Wing ..........................11 Installing the Toolbox ..............................

  • Page 8: Parts Identification

    Kids Ride-On Mercedes-Benz AMG G63 Parts Identification Name Car body Wheels Wheel mounting hardware Hubcap / Centre cap Windshield Side mirrors Drive motor Seat Rear wing Toolbox E&OE © 2020 Rovo Kids...

  • Page 9: Assembly

    Kids Ride-On Mercedes-Benz AMG G63 Assembly Video Tutorial: Assembly Tools needed: • Screwdriver (not included) • tip forceps (not included) • plastic wrenches Installing the Front Axle As shown in the image above, the direction of the front wheel shaft is noticeable. Insert it in the support frame and at the bottom of the frame with 1pc.

  • Page 10: Installing The Front And Rear Wheels

    Kids Ride-On Mercedes-Benz AMG G63 Installing the Front and Rear Wheels Rear Wheel The drive motor has already been installed in the car body. Insert the rear wheel directly, placing additional 10 gaskets, and then secure it with a M8 nut. Finally, insert the wheel core cover.

  • Page 11: Installing The Seat And Rear Wing

    Kids Ride-On Mercedes-Benz AMG G63 Installing the Seat and Rear Wing Rear Wing Align the rear wing on the car body, press down until it clicks securely into place. Seat First, insert the rear wing at the rear end of the seat on the car body, and then secure it with 2pcs. of Ø4x12 self- tapping screws.

  • Page 12: Installing The Toolbox

    Kids Ride-On Mercedes-Benz AMG G63 Installing the Toolbox Insert the Toolbox on the car body and secure it with 2pcs. of Ø4x12mm black screws. E&OE © 2020 Rovo Kids...

  • Page 13: Installing The Steering Wheel

    Kids Ride-On Mercedes-Benz AMG G63 Installing the Steering Wheel Connect the plugs before installing the steering wheel, then install the steering wheel. Secure the steering wheel with a Ø5x40 and M5 nut. NOTE: before installing the steering wheel, the front and rear of the steering wheel should be noticeable when reverse installing.

  • Page 14: Installing The Windshield And Side Mirrors

    Kids Ride-On Mercedes-Benz AMG G63 Installing the Windshield and Side Mirrors Windshield Align the windshield on the car body and insert it until it clicks in place. NOTE: Ensure that the windshield is fully clamped onto the car body. Side Mirrors Insert the side mirrors, one on each side, onto the car body until they click in place.

  • Page 15: Connecting The Power Supply

    Kids Ride-On Mercedes-Benz AMG G63 Connecting the Power Supply IMPORTANT! When connecting the connectors to the battery, ensure that they are connected to the correct polarities: Black to black. Red to red. Please remove the terminal cover first when assembling the battery (see image to the right).

  • Page 16: Operation

    Kids Ride-On Mercedes-Benz AMG G63 Operation Basic Car Functions 1. Power Switch: Turn the power ON/OFF. 2. Forward/Backward Switch: controls the moving direction of the ride-on car, either forward or backward. 3. USB player 4. Foot pedal: Stepping on the foot pedal will make the rid-on car move forwards. Lifting the foot from the pedal will make the ride-on car brake gradually.

  • Page 17: Usb Player Functions

    Kids Ride-On Mercedes-Benz AMG G63 USB Player Functions 1. USB interface (if equipped): Insert a USB in the USB terminal to connect to audio source and play audio files. 2. TF card slot (if equipped): Insert a TF card to play audio files.

  • Page 18: Steering Wheel Function

    Kids Ride-On Mercedes-Benz AMG G63 Steering Wheel Function A. Horn button B. Music button (if equipped) Charging the Battery • The charging input socket is below the seat. • The power switch must be turned in OFF position when charging.

  • Page 19: Proper Battery Disposal

    Kids Ride-On Mercedes-Benz AMG G63 Fuse This product is equipped with a self-reset fuse, when overloaded or used improperly, self-reset fuse will automatically cut off the power supply for 15-20 seconds, and then restart. The self-reset fuse of the car is installed under the seat.

  • Page 20: Lithium Battery Care And Maintenance

    Kids Ride-On Mercedes-Benz AMG G63 Lithium Battery Care and Maintenance Top 3 Battery Care Requirements 4. Charge battery before first use. The battery may arrive with some charge, regardless of this the battery must be charged for 4 – 6 hours on the initial charge and 8 – 12 hours for each subsequent charge.

  • Page 21: Maintenance

    Kids Ride-On Mercedes-Benz AMG G63 Maintenance • It is the responsibility of the child’s parents/guardians to check the main parts of the toy before using. They must regularly examine them for any potential hazards such as the battery, charger, cable or cord, plug, screws are fastening enclosure of other parts and that in the event of such damage, the toy must not be used until that damage had been properly removed.

  • Page 22: Troubleshooting

    Kids Ride-On Mercedes-Benz AMG G63 Troubleshooting Problem Possible Reasons Solutions Is the fuse of the vehicle Yes, the fuse automatically cuts off the power overloaded? (fuse box under the for 15-20 seconds and restarts: No, next step. seat of the car) No, fix the foot pedal;...

  • Page 23: Specifications

    Kids Ride-On Mercedes-Benz AMG G63 Specifications Speed Range 3-5km/h Gears Forward and Reverse Motor 50W (2 x 25W) Suspension Max Capacity 30kg Suitable Age 3-8 Years Old Power Plug Australian Standard E&OE © 2020 Rovo Kids...
  • Page 24 ©2020 Rovo Kids. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,...
