Colours may vary
BMW S1000RR Kids Ride-on
Motorbike
User Manual
[Revision 1.0 October 2018]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY
DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by
this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
THE BATTERY MAY HAVE SOME CHARGE ON ARRIVAL, IT IS IMPORTANT
HOWEVER THAT THE BATTERY IS CHARGED PRIOR TO USE.
E&OE
© 2018 Rovo Kids

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BMW S1000RR and is the answer not in the manual?

Questions and answers

Related Manuals for Rovo Kids BMW S1000RR

Summary of Contents for Rovo Kids BMW S1000RR

  • Page 1 Colours may vary BMW S1000RR Kids Ride-on Motorbike User Manual [Revision 1.0 October 2018] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.

  • Page 2: Safety

    BMW S1000RR Kids Ride-on Motorbike Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols: You WILL be KILLED or...
  • Page 3 BMW S1000RR Kids Ride-on Motorbike General Electrical Safety General Electrical Safety General Service Information • Inspect electrical equipment, extension • Electrically grounded equipment must • The equipment must be serviced or cords, power bars, and electrical fittings have an approved cord and plug and repaired at authorised service centres for damage or wear before each use.

  • Page 4: Safety Symbols

    BMW S1000RR Kids Ride-on Motorbike Safety Symbols The product may have safety warning labels attached to it, explained below. Understand the symbols on your product and their meanings. If any stickers become unreadable, unattached etc, replace them. Flammable Material Hazard...
  • Page 5 BMW S1000RR Kids Ride-on Motorbike Carbon-Monoxide Hazard Pull Hazard Slope / Fall Injury Hazard "Slam Dunk" Warning Do not use the product in Be aware that the product Be aware that using the Do NOT attempt "slam dunk" confined areas or without...

  • Page 6: Table Of Contents

    BMW S1000RR Kids Ride-on Motorbike Table of Contents Safety ..............................2 Safety Symbols ............................4 Parts Identification ..........................7 Assembly ............................8 Before Assembly ............................8 Attaching the Rear Wheels ........................9 Attaching the Handle Bar ......................... 10 Attaching the Faceguard .......................... 11 Connecting the Power Supply ........................

  • Page 7: Parts Identification

    BMW S1000RR Kids Ride-on Motorbike Parts Identification NOTE: Some parts shown are assembled on both sides of motorbike. Name Qty. Name Qty. Motorbike body Gear box Faceguard Rear wheel Handle bar Ø8 washer M5x35 machine screw Lock nut Ø5 nut...

  • Page 8: Assembly

    BMW S1000RR Kids Ride-on Motorbike Assembly Video Tutorial: Typical Ride-On Car Assembly Before Assembly • CHOKING HAZARD - Small parts. Not suitable for children under 36 months. The product contains small parts, keep children away when assembling. • ADULT ASSEMBLY REQUIRED.

  • Page 9: Attaching The Rear Wheels

    BMW S1000RR Kids Ride-on Motorbike Attaching the Rear Wheels Remove all the parts from the rear axle. Turn the motorbike body upside down. 1. Insert the rear axle into the hole located on the rear of the motorbike. 2. Slide a gear box onto the rear axle.

  • Page 10: Attaching The Handle Bar

    BMW S1000RR Kids Ride-on Motorbike Attaching the Handle Bar Remove the M5x35 machine screw and Ø5 nut from the end of the front fork. 1. Insert the front fork into the opening on the front of the motorbike body from the bottom side, and out through the hole on the top side of the motorbike.

  • Page 11: Attaching The Faceguard

    BMW S1000RR Kids Ride-on Motorbike Attaching the Faceguard If your motorbike is equipped with music function, follow steps 1 – 4 below to add batteries (not included). 1. With a small screwdriver, remove the screw on the battery cover on the faceguard.

  • Page 12: Connecting The Power Supply

    BMW S1000RR Kids Ride-on Motorbike Connecting the Power Supply 1. Use a screwdriver to remove the screw on the seat back. 2. Remove the seat. 3. Plug the motorbike connector into the motor connector as shown. 4. Put the seat back on.
  • Page 13 BMW S1000RR Kids Ride-on Motorbike E&OE © 2018 Rovo Kids...

  • Page 14: Operation

    BMW S1000RR Kids Ride-on Motorbike Operation 1. Sounds buttons (if equipped): Press for sounds playing. 2. Foot pedal: Applies power (speed) to the motorbike. E&OE © 2018 Rovo Kids...

  • Page 15: Lithium Battery Care And Maintenance

    BMW S1000RR Kids Ride-on Motorbike Lithium Battery Care and Maintenance Top 3 Battery Care Requirements Charge battery before first use. The battery may arrive with some charge, regardless of this the Do not recharge the battery for more battery must be charged for 4 to 6 hours on the initial charge.

  • Page 16: Charging The Battery

    BMW S1000RR Kids Ride-on Motorbike Charging the Battery ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! • PREVENT FIRE AND ELECTRIC SHOCK • Use the only rechargeable battery and charger supplied with your motorbike. NEVER substitute the battery or the charger with another brand. Using another battery or charger may cause a fire or explosion.

  • Page 17: Battery Replacement & Fuse

    BMW S1000RR Kids Ride-on Motorbike 1. Plug the charger port into the input socket. (the socket is at the back of the motorbike) 2. Plug the charger plug into a wall outlet. The battery will begin charging. Battery Replacement & Fuse The battery features a thermal fuse with a rest fuse that will automatically trip and cut all power to the motorbike if the motor, electric system or battery is overloaded.

  • Page 18: Battery Replacement And Disposal

    BMW S1000RR Kids Ride-on Motorbike Battery Replacement and Disposal The battery will eventually lose the ability to hold a charge. Depending on the amount of use, and varying conditions, the battery should operate for one to three years. Follow these steps to replace and dispose the battery: 1.

  • Page 19: Troubleshooting

    BMW S1000RR Kids Ride-on Motorbike Troubleshooting Problem Possible Cause Solution Battery low on power. Recharge battery. Thermal fuse has Reset fuse, see Battery Replacement & Fuse. tripped. Check that the battery connectors are firmly plugged Battery connector or into each other. If wires are loose around the motor, wires are loose.

  • Page 20: Specifications

    BMW S1000RR Kids Ride-on Motorbike Specifications Officially Licensed Model S1000RR Motor Max Speed 3km/h (weight dependent) Max Load 20kg Battery 6V 4AH Charge Time 6-8hrs (full charge) Drive Time 1-2hrs (full charge) Max User Height 110cm E&OE © 2018 Rovo Kids...
  • Page 21 ©2018 Rovo Kids. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system, without express permission or consent from the publisher.
