- Page 1 Huawei AR200-S Series Enterprise Routers V200R002C00 Quick Start Guide Issue Date 2011-12-30 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 All other trademarks and trade names mentioned in this document are the property of their respective holders. Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope.
-
Page 3: About This Document
Huawei AR200-S Series Enterprise Routers Quick Start Guide About This Document About This Document Intended Audience This document provides an overall description of the AR200-S, details about each chassis and board, cables available to the device, lists of components and basic configuration. - Page 4 Huawei AR200-S Series Enterprise Routers Quick Start Guide About This Document Change History Changes between document issues are cumulative. Therefore, the latest document issue contains all the changes in previous issues. Changes in Issue 01 (2011-12-30) Initial commercial release. Issue 01 (2011-12-30) Huawei Proprietary and Confidential Copyright ©...
-
Page 5: Table Of Contents
Huawei AR200-S Series Enterprise Routers Quick Start Guide Contents Contents About This Document........................ii 1 AR200-S Overview........................1 1.1 Naming Rule...............................2 1.2 Device Structure..............................2 1.3 Indicator Description............................3 1.4 Physical Specifications............................6 2 Installation Product........................8 2.1 Installation Preparations.............................9 2.2 Installing the Device............................9 2.3 Connecting Device............................14 2.4 Powering on the Device............................15... -
Page 6: Ar200-S Overview
Huawei AR200-S Series Enterprise Routers Quick Start Guide 1 AR200-S Overview AR200-S Overview About This Chapter This section describes the naming rule, appearance and structure, indicators, and physical specifications of the AR200-S. 1.1 Naming Rule This section describes the meanings of the AR200-S names. -
Page 7: Naming Rule
Huawei AR200-S Series Enterprise Routers Quick Start Guide 1 AR200-S Overview 1.1 Naming Rule This section describes the meanings of the AR200-S names. Figure 1-1 shows the AR200-S naming rule. Figure 1-1 AR200-S Naming rule 【B1 B2 B3 B4】 【AR】... -
Page 8: Indicator Description
Huawei AR200-S Series Enterprise Routers Quick Start Guide 1 AR200-S Overview Figure 1-2 shows the AR200-S models. Figure 1-2 AR200-S models Product Model Appearance Series Port Port 8 FE 1 FE 201-S AR200-S Series SL2+ 8 FE 207-S Anne xA/M... - Page 9 Huawei AR200-S Series Enterprise Routers Quick Start Guide 1 AR200-S Overview Indicators The indicators on the AR200-S front panels vary according to the product models. Table 1-2 lists the indicator differences. Table 1-2 AR200-SIndicator differences Difference Description WAN port silkscreen...
- Page 10 Huawei AR200-S Series Enterprise Routers Quick Start Guide 1 AR200-S Overview Table 1-3 Indicator description Numbe Indicator Color Description Green If the indicator is steady on, the system power supply is normal. If the indicator is off, no system power supply is available.
-
Page 11: Physical Specifications
Huawei AR200-S Series Enterprise Routers Quick Start Guide 1 AR200-S Overview Numbe Indicator Color Description green If the indicator is steady on, a link is connected to the LAN port. If the indicator blinks green, the LAN port is transmitting or receiving data. - Page 12 Huawei AR200-S Series Enterprise Routers Quick Start Guide 1 AR200-S Overview Table 1-5 System configuration Product Name Processor Memory Flash Memory AR201-S Dual-core 533 MHz 512 MB 512 MB AR207-S Dual-core 533 MHz 512 MB 512 MB Issue 01 (2011-12-30) Huawei Proprietary and Confidential Copyright ©...
-
Page 13: Installation Product
This section describes AR200-S installation scenarios and installation methods. 2.3 Connecting Device This section describes how to connect AR200-S series products. 2.4 Powering on the Device This section provides the checklist used to check the AR200-S before powering on it. -
Page 14: Installation Preparations
Huawei AR200-S Series Enterprise Routers Quick Start Guide 2 Installation Product 2.1 Installation Preparations This section lists the tools and accessories for installing the AR200-S. Tools Marker pen Philips screwdriver Flat-head screwdriver Utility knife Claw hammer COAX crimping tool RJ45 crimping tool... - Page 15 Quick Start Guide 2 Installation Product NOTE All AR200-S series products have the same installation scenarios, installation methods, and cable connections. This section uses AR207-S as an example. Placing Chassis on the Desktop Before placing the AR200-S on the desktop, attach rubber pads onto each of the four recessed corner areas on the bottom of the chassis.
- Page 16 Huawei AR200-S Series Enterprise Routers Quick Start Guide 2 Installation Product The diameter of the mounting screws is 4 mm. Choose an appropriate drill bit according to the diameter of the mounting screws. Hammer the hollow wall anchors into the drilled holes.
- Page 17 Huawei AR200-S Series Enterprise Routers Quick Start Guide 2 Installation Product Connect the power adapter. Place the power adapter on a nearby horizontal surface, but do not hang it under the equipment. Installing the Chassis in a Cabinet or Rack CAUTION l When installing the AR200-S in a cabinet or rack, do not attach rubber pads to the chassis.
- Page 18 Huawei AR200-S Series Enterprise Routers Quick Start Guide 2 Installation Product Floating nut mounting bar Raise and hold the chassis by hands and move the chassis into the cabinet. Insert the panel screws into the below floating nuts and keep a 2 mm space between the screws and mounting bar.
-
Page 19: Connecting Device
Huawei AR200-S Series Enterprise Routers Quick Start Guide 2 Installation Product 2.3 Connecting Device This section describes how to connect AR200-S series products. Figure 2-1 Connecting the AR200-S to network Issue 01 (2011-12-30) Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd. -
Page 20: Powering On The Device
Huawei AR200-S Series Enterprise Routers Quick Start Guide 2 Installation Product 1: Console cable l The 8-pin RJ45 connector is inserted into the console port (CON/AUX port) of the AR200- l The DB9 male connector is connected to the maintenance terminal, such as a computer. - Page 21 Huawei AR200-S Series Enterprise Routers Quick Start Guide 2 Installation Product Item Method The bent part of signal cables cannot be too tight. View The cables in the cabinet are not crossed and the cables View outside the cabinet are bundled.
-
Page 22: Logging In To The Router
Huawei AR200-S Series Enterprise Routers Quick Start Guide 3 Logging In to the Router Logging In to the Router About This Chapter After the router is powered on, you can log in to the router. 3.1 Logging In to the Router Through the Console Port This section describes how to log in to the router through the console port. -
Page 23: Logging In To The Router Through The Console Port
Huawei AR200-S Series Enterprise Routers Quick Start Guide 3 Logging In to the Router 3.1 Logging In to the Router Through the Console Port This section describes how to log in to the router through the console port. Procedure Step 1 Connect the router to a PC using a Console Cable. Connect the RJ45 connector of the cable to the console port of the router, and connect the DB9 connector to the serial port of the PC. - Page 24 Huawei AR200-S Series Enterprise Routers Quick Start Guide 3 Logging In to the Router Figure 3-2 Selecting the console port Step 4 Click Restore Defaults and click OK, as shown in Figure 3-3. Figure 3-3 Setting communication parameters Issue 01 (2011-12-30) Huawei Proprietary and Confidential Copyright ©...
-
Page 25: Logging In To The Router Using Telnet
Huawei AR200-S Series Enterprise Routers Quick Start Guide 3 Logging In to the Router Step 5 Press Enter on the subsequent dialog boxes until the command line prompt of the user view, such as <Huawei>, is displayed. You can run commands to configure the router. Enter a question mark (?) to see a list of available commands. -
Page 26: Connecting To The Internet
Huawei AR200-S Series Enterprise Routers Quick Start Guide 4 Connecting to the Internet Connecting to the Internet About This Chapter This section describes how to enable users to connect to the Internet through the router. Select the network access mode based on the link type of uplink physical interfaces. -
Page 27: Connecting To The Internet Using An Xdsl Interface
Huawei AR200-S Series Enterprise Routers Quick Start Guide 4 Connecting to the Internet 4.1 Connecting to the Internet Using an xDSL Interface This section describes how to connect to the Internet using an xDSL interface. Networking Requirements As shown in Figure 4-1, users connected to the router use the same account. - Page 28 Huawei AR200-S Series Enterprise Routers Quick Start Guide 4 Connecting to the Internet Procedure Step 1 Configure a dialer interface and ACL. <Huawei> system-view [Huawei] sysname Router [Router] dialer-rule [Router-dialer-rule] dialer-rule 10 ip permit [Router-dialer-rule] quit [Router] acl 2000 [Router-acl-basic-2000] rule 5 permit source 192.168.1.0 0.0.0.255...
-
Page 29: Connecting To The Internet Through An Ethernet Interface
Huawei AR200-S Series Enterprise Routers Quick Start Guide 4 Connecting to the Internet Users can access the Internet and obtain IP addresses in the range of 192.168.1.2 to 192.168.1.254. ----End Configuration Files Configuration file of the Router sysname Router dhcp enable acl number 2000 rule 5 permit source 192.168.1.0 0.0.0.255... - Page 30 Huawei AR200-S Series Enterprise Routers Quick Start Guide 4 Connecting to the Internet Figure 4-2 router functions as the PPPoE client Host 1 Eth0/0/1 Eth0/0/8 Host 2 PPPoE Client PPPoE Server Host n Configuration Roadmap The configuration roadmap is as follows: Create a dialer interface and set parameters for the dialer interface.
- Page 31 Huawei AR200-S Series Enterprise Routers Quick Start Guide 4 Connecting to the Internet [Router-Dialer0] nat outbound 2000 [Router-Dialer0] quit NOTE If a private address is used, configure an ACL referenced by NAT. Step 3 Create a PPPoE session. [Router] interface ethernet 0/0/8...
-
Page 32: How To Obtain Documentation And Technical Support
Huawei customer service center (CSC) for help. Email: support@huawei.com You can also visit http://support.huawei.com, click Contact Us in the lower area of the page, and select the country to obtain contact information about Huawei local office. Issue 01 (2011-12-30) Huawei Proprietary and Confidential Copyright ©... -
Page 33: Faqs
Huawei AR200-S Series Enterprise Routers Quick Start Guide 6 FAQs FAQs This section describes the frequently asked questions about the router. Why Is the Power Supply Indicator Off? The possible causes are as follows: The router is powered off. The power supply is powered off. - Page 34 In the preceding example, the user names of the Telnet users are huawei and their passwords are in cipher text. Run the following commands to set the passwords of the huawei users to huawei. <Huawei> system-view...
