Parts and Dimensions
Parts and Dimensions
Control box parts diagram
<AVR-M100JHAX>
Sub PCB assembly
Fuse
Transformer
Relay
Terminal block
<AVR-M100FHAX>
60 (2.36)
120 (4.72)
39 (1.54)
145 (5.71)
4
English
Accessories
Sub PCB assembly
Fuse
Relay
Terminal block
Unit: mm (inch)
Product Body (1)
Bracket Holder (1)
Installation Guide (1)
M4 x L12 Screw (5)
