Philips VU6 Installation & Operation Instructions

INSTALLATION & OPERATION INSTRUCTIONS
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL
1.
SAFETY INSTRUCTIONS.
2. Review the diagrams thoroughly before beginning. If you feel
you do not have electrical wiring experience, refer to a
do-it-yourself wiring handbook or have your fixture installed by a
qualified licensed electrician.
3. All electrical connections must be in accordance with local codes,
ordinances, and the National Electric Code.
unfamiliar with methods of installing electrical wiring, secure the
services of a qualified licensed electrician.
4. Before starting the installation, disconnect the power by turning
off the circuit breaker or by removing the appropriate fuse at the
fuse box. Turning the power off using the light switch is not
sufficient to prevent electrical shock.
5. Do not use outdoors.
6. Do not let power supply cords touch hot surfaces.
7. Do not mount near gas or electric heaters.
8. Use caution when servicing batteries. Battery acid can cause
burns to skin and eyes. If acid is spilled on skin or in eyes, flush
acid with fresh water and contact a physician immediately.
9. Equipment should be mounted in location and at heights where
it will not readily be subject to tampering by unauthorized
personnel.
10. The use of accessory equipment not recommended by the
manufacturer may cause an unsafe condition.
11. Do not use this equipment for other than intended use.
12. All servicing should be performed by qualified personnel only.
13. Allow battery to charge for 24 hours before first use.
UNPACK THE FIXTURE
Check the contents of the box. You should receive:
1- Mounting plate
1- Fixture
2- Light heads assembly
1- Hardware package
NOTE: First turn off electricity.
Wall Mounting
1. Remove mounting plate from fixture by prying with screwdriver.
(see Fig.1)
2. Insert screwdriver to make appropriate keyhole slots open on
mounting plate.
If you are
SAVE THESE INSTRUCTIONS
3. Pass white (neutral) and either black 120V or orange 277V hot,
wire leads through center hole of mounting plate, make
electrical connections in junction box, see electrical connection
below. You may use hanging hook to hang fixture while making
connection. Cap off unused hot lead.
4. Mount mounting plate to junction box with screw provided
8#32 X 1" long.
5. Connect red lead to battery positive terminal.(see Fig. 2)
6. Snap on fixture to mounting plate.
7. Restore power and press test button. Battery powered bulbs
will come on. AC light will turn off.
Ceiling Mounting
1. Remove mounting plate
screwdriver.(see Fig. 3)
2. Open top cover and knockout on the top of fixture.
3. Secure the mounting plate to tube with nut.
4. Pass white (neutral) and either black 120V or orange 277V hot,
wire leads through center hole of mounting plate. make electrical
connections in junction box, see electrical connection below. You
may use hanging hook to hang fixture while making connection.
Cap off unused hot lead
5. Connect red lead to battery positive terminal.(see Fig. 4)
6. Snap on fixture to mounting plate.
7. Restore power and press test button. Battery powered bulb will
come on. AC light will turn off.
ELECTRICAL CONNECTIONS
Connect white wire lead from fixture to white (neutral) wire supply
feed from circuit. Connect
(depending on supply voltage), wire lead from fixture to black (hot)
wire from supply circuit. Use U.L. Listed wire connectors suitable
for the size, type, and number of conductors. No loose strands or
loose wires should be present. Secure wire connectors with U.L.
listed electrical tape.
Relamping
1. Insert screwdriver into the slot between lens and light head body
and then push gently to remove lens.
2. Install bulb
CAUTION:
DO NOT EXCEED RECOMMENDED MAXIMUM
WATTAGE.(6V 5W)
from fixture by prying
black 120V or orange 277V,
VU6
with
