    English FLIP-OVER SAW DW743N, DW743K Congratulations! EC-Declaration of Conformity You have chosen a D WALT tool. Years of experience, thorough product development and Machinery Directive innovation make D WALT one of the most reliable partners for professional power tool users. Technical Data DW743N DW743N DW743K...

  • Page 12: Personal Safety

    English 3) Personal Safety gloves for handling saw blades and rough material. Saw blades should be carried in a holder wherever practicable. a ) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of •...

  • Page 13: Package Contents

    English Additional Safety Rules for Bench Saws Follow the fitting instructions supplied with good quality plugs. Recommended fuse: 13 A. Using an Extension Cable • Do not use saw blades with a body thickness greater or a width of tooth smaller than the thickness of the riving knife.
  • Page 14 English Guard release lever Push stick storage 5. Rotate the wheel   43  counterclockwise whilst holding down the head until the  44  "U"-shaped bracket  can be disengaged from its seating (Fig. I2). Operating handle 6. Swing and push the height adjuster up. Hand indentations Foot 7.

  • Page 15: Prior To Operation

    English 2. Loosen the rotating table clamp   3  . The handle allows a ratchet-type action when full 5. If adjustment is required, proceed as follows: rotation of the handle is not possible. a. Adjust the fence so that it is parallel to the blade by checking the distance between the  14 ...

  • Page 16: General Handling

    English Clamping the Workpiece (Fig. U–W, BB) 5. Keep both hands away from the path of the saw blade. WARNING: A workpiece that is clamped, balanced and secure before a cut may become 6. Switch the machine on and allow the saw blade to reach full speed. unbalanced after a cut is completed.

  • Page 17: Maintenance

    English Connecting - Bench saw Position BLADE DESCRIPTIONS 1. Connect one hose to the small diameter outlet and one to the large diameter using the APPLICATION DIAMETER TEETH corresponding spouts. Construction saw Blades (thin kerf with anti-stick rim) 2. Blank off the middle opening of the 3-way connector. General Purpose 250 mm 30 (Series 60)
  • Page 18 English...
  • Page 19 English...
