B. Braun Perfusor Space Service Manual page 31

1.0
Error Code
26 1201 different version FuP to KuP
Software
27 1202 E_ERROR_STEPMOTOR_1 Phase
not ok
28 1203 E_ERROR_STEPMOTOR_2 Current
value not 0x55
29 1204 E_ERROR_STEPMOTOR_3
K_SM_CLK defect
30 1205 E_ERROR_STEPMOTOR_4 Phase
not ok
31 1206 E_ERROR_STEPMOTOR_5
Current value not 0
32 1207 E_ERROR_STEPMOTOR_6 Current
value not 0x55
33 1208 E_ERROR_STEPMOTOR_7 Current
value not 0xAA
34 1209 E_ERROR_STEPMOTOR_8 Phases
not 0
35 1210 E_ERROR_DCMOTOR_1
36 1211 E_ERROR_DCMOTOR_2
37 1212 E_ERROR_DCMOTOR_3
38 1213 E_ERROR_DCMOTOR_4
39 1214 E_ERROR_DCMOTOR_5
40 1215 no V_MOT
41 1216 overvoltage test fail
42 1217 no V_MOT
43 1218 undervoltage test fail
44 1220 syringeholder defect
45 1221 syringe change timeout
46 1237 ... 1238 Internal Error
47 1239 plunger plate sensor defect
48 1240 ... 1254 Internal Error
Table 2 - 3 Device alarms of the control microprocessor (Part 2 of 2)
Perfusor® Space, 1.0 gb
Definition
Software
Drive motor, lead screw
Motor drive
Recognition of direction of
rotation
Motor drive
Recognition of direction of
rotation
Motor drive
Recognition of direction of
rotation
Motor drive
Recognition of direction of
rotation
Motor drive
Recognition of direction of
rotation
Motor drive
Recognition of direction of
rotation
Motor drive
Recognition of direction of
rotation
Piston brake drive motor def.
Claw drive in drive head defective
Piston brake light barrier def.
Voltage transformer defective
Syringe holder or potentiometer
def.
Pressure measurement in drive
head
Unit Diagnosis / Calibration
Possible Cause
Update unit software
Exchange processor PCB
Carry out calibration
Carry out calibration
Carry out calibration
Carry out calibration
Carry out calibration
Carry out calibration
Carry out calibration
Exchange processor PCB
Replace syringe holder
Exchange processor PCB
Replace drive head
2
Fault Clearance
2 - 7
