- Page 1 Jade™ X7 Portal Scanner Quick Reference Guide...
- Page 2 U.S. and the E.U. All other brand and product names may be trade- marks of their respective owners. Jade is a trademark of Datalogic S.p.A. or of Datalogic Group companies, registered in many countries, including the U.S. and the E.U.
-
Page 3: Table Of Contents
Scanner Features .............................2 Operation .................................3 Power-on ..............................3 Scanning ..............................4 Control Panel ............................4 Maintenance ..............................5 Cleaning ..............................5 Spillage ..............................6 Debris Tray/Window ........................6 LED and Audio Indicators ..........................7 Arch Indicators ............................7 Audio Indicators ............................8 Datalogic USA, Inc. Limited Factory Warranty ....................9 Quick Reference Guide... - Page 4 Contents NOTES Jade™ X7 Portal Scanner...
-
Page 5: Jade™ X7
Introduction This Quick Reference Manual explains the basic features and functions of the portal scanner. This manual covers more than one model of the Jade X7 product. Your model may differ slightly from the images shown. Alternate diagrams are shown when necessary to explain the differences between models. -
Page 6: Scanner Features
Introduction Scanner Features The major parts of the scanner are shown below. Access to the Lower Assembly is dependent upon how the system integrator or manufacturer has designed your checkstand. Ideally, entry panels have been built in that allow easy visibility and access to the necessary parts and features. Figure 2. -
Page 7: Operation
Prior to powering on the Jade unit, the installer should ensure that the Jade unit has been grounded to earth ground. Some models have a Grounding Screw (shown Figure 3 below). Reference the Jade X7 PRG for complete grounding and installa- tion instructions. CAUTION... -
Page 8: Scanning
Operation Scanning The surface from the conveyor belt and beneath the arches up to, and including the transition plate constitutes the effective scanning area. Imager/cameras distributed throughout the arches “curtain” the area within that zone for scanning items on five sides. The sixth side (bottom) of an item is scanned by the upward-facing optics (bottom scanner) beneath the transition plate. -
Page 9: Maintenance
Maintenance Maintenance Cleaning The scanner will provide dependable service for many years. The following maintenance procedures will keep your scanner operating at peak performance. Whenever needed, gently clean the transparent surfaces of the arches, the bottom scanner debris tray and the transition plate glass using paper towels or lint-free cleaning tissues dampened with a non- abrasive, mild, water-based glass cleaner (as shown in the inset). -
Page 10: Spillage
Maintenance Spillage Inevitably, packages placed on the conveyor belt will break open or bottles will leak. In anticipation of this problem, the scanner has been designed to channel the flow of spillage through less-vulnerable Figure 5 areas. shows how a leakage is routed by the Debris Tray/Window toward the outside of the unit, then through a drain hole into a container placed to collect it. -
Page 11: Led And Audio Indicators
LED and Audio Indicators LED and Audio Indicators The scanning system provides onboard LED indicators (one multi-color “illuminating logo” per arch). The system may offer additional custom LEDs, audio sounds and other indicators which are unique to your installation. Be sure to check the documentation for the checkstand and other equipment for fur- ther information. -
Page 12: Audio Indicators
LED and Audio Indicators Audio Indicators Audio indications are WAV files stored in the system that are played by the scanner. The table below shows factory default settings. If your system is programmed to sound audio indications, but no indications can be heard when expected, installation of external speakers might be required. -
Page 13: Datalogic Usa, Inc. Limited Factory Warranty
Datalogic service center, with shipping charges prepaid. Datalogic shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Datalogic ser- vice center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations. - Page 14 DAMAGES. Risk of Loss Customer shall bear risk of loss or damage for product in transit to Datalogic. Datalogic shall assume risk of loss or damage for product in Datalogic’s possession. In the absence of specific written instruc- tions for the return of product to Customer, Datalogic will select the carrier, but Datalogic shall not thereby assume any liability in connection with the return shipment.
- Page 16 Data- logic S.p.A. and/or its affiliates. • Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.
