- Page 1 CUGGL BEDRAIL NATURAL CUGGL BEDRAIL BLUE CUGGL BEDRAIL PINK I M PORTANT! KEEP THE I N STRUCTI O N FOR FURTHER REFERENCE 707/7768 706/2326 702/7079 Important Age:18 months - 5 years 03456 400 800 Issue1-31/03/17...
- Page 2 Exploded diagram for single bedrail Fabric Metal Frame Hinge System Bottom Tube Right Tube Left Tube...
- Page 3 It is recommended only to use the bedrail for children between 18 months and 5 years. Only use the bedrail when the child is able to climb in and out of bed unaided. The bedrail should not be used as a substitute for a cot, as it cannot provide the same level of safety as a cot.
- Page 4 Assembling Your Bedrail Step 1: Unfold the bedrail, slide the plastic in place and lock it. ( See figure 1 ) Figure1 Step 2: Fixed the bottom tube ( C1 & C2 ) together, and then get through the fabric. （ See figure 2 ） Figure2...
- Page 5 Step 3: Put the left tube ( B1 ) into the connected plastic, then get through the fabric and assemble the B1 to left hinge system till the button locked in place. （ See figure 3 ） Figure3 Step 4: Fix the right hinge system ( D ) to bedrail till button locked in place. Put the right tube ( B2 ) into the connected plastic, then get through the fabric and assemble the B2 to right hinge system till button locked in place.
- Page 6 Step 5: Slide the plastic behind button. （ See figure 5 ） Figure5...
- Page 7 Installing Your Bedrail Step 1: Adjust the straps length according to the width. Be careful: to let the straps in flat and straight, not twist. ( See figure 6 ） Figure6 Put on the mattress, make the steel plate in place as stopper against the mattress and bed.
- Page 8 WARNING: Step 2: To prevent the risk of strangulation it is essential to ensure that when the bedrail is fitted into position, there is a gap of at least 250 mm( 10in ), between each end of the bed and the corresponding end of the bedrail.
- Page 9 Folding Your Bedrail for Storing Step 1: Remove the left/right tube Press the upper button in place and then remove the left/right tube from hinge. Press the under button in place and then remove them from bottom tube. ( See figure 12 ） Press Remove tube Press...
- Page 10 Care & Maintenance Fabric composition: 100% Polyester. Periodically check the bedrail for signs of damage, wear and/or for missing components. Do not use if any part is missing, worn or damaged. Check the bedrail regularly to make sure all hardware and mountings are tight and secure.
