Summary of Contents for Argos FUTON 656/0032
- Page 20 Futon Bunk Bed 758/4512 Assembly Instructions - Please keep for future reference IMPORTANT NOTE: The top surface of the mattress should not come above this line. Dimensions Width - 200cm Depth - 99/174cm Height - 165cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 06/11/13...
- Page 21 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Because of the size of this unit, • Assemble this product on a flat • We do not it is recommended to assemble it surface. recommend the in the room intended for use.
- Page 22 Components - Parts Please check you have all the parts listed below Sticker “1” Sticker “2” Sticker “3” Back end post x 2 Front left-hand end post Front right-hand end post (Ø5 x 165cm) (Ø5 x 165cm) (Ø5 x 165cm) Sticker “4”...
- Page 23 Components - Parts (cont.) Please check you have all the parts listed below Sticker “13” Sticker “14” Slats (with webbing attached) x 24 Left ladder side rail Right ladder side rail (94 x 1.6 x 2.5cm) (150 x Ø2.5cm) (150 x Ø2.5cm) Ladder step x 4 Ladder brace Futon clamp x 2...
- Page 24 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 25 Assembly Instructions Step 1 Assembling end panels Lay all parts flat on a soft surface on the floor to avoid damaging any of the parts. Note: Identify and correctly position the end posts RIGHT-HAND END PANEL & looking for the Sticker “1”...
- Page 26 Assembly Instructions Step 2 Attaching rails Note: Determine your preferred bunk bed entry position. Then attach the front safety rail with the entry space positioned on the left or right. Identify the correct rails for assembly and with the help of an assistant attach the lower tubes of upper back safety rail...
- Page 27 Assembly Instructions Step 3 Attaching slats With the help of an assistant, line up the slats onto upper rails & . Push firmly down to lock it into position. Check that they cannot be removed by slightly pulling upwards. Extend the end of the webbing on the slats and secure to bottom edge of side safety rails...
- Page 28 Assembly Instructions Step 6 Step 5 Assembling front futon frame Position the front futon frame as shown and secure it to futon mechanisms & with bolts , washers and nuts . Tighten bolts and nuts using allen and spanner Position the futon clamps as shown and carefully hook one end...
- Page 29 Assembly Instructions Step 7 Assembling ladder Sticker “14” Referring to diagram, Sticker “13” attach the ladder steps to ladder side rails & using bolts , spring washers , curved washers and plastic washers . Tighten all bolts using allen key Note: Identify and correctly position the ladder side...
- Page 30 Assembly Instructions Step 9 Securing the ladder Attach the ladder brace to ladder side rail & front right-hand post using bolts . Tighten bolts using allen key Step 10 Fixing to wall Wall This unit must be fixed to a wall. Move the bunk bed into position on the wall.
- Page 31 Operation Instructions Step 1 Folding the futon Slightly pull up the futon from the front edge. Push it in to fold the futon frame. Then carefully put down the futon as shown. Warning: Keep hands away from hinges, folding mechanisms & edges to prevent possible entarpment or...
