Maintenance

This chapter describes basic maintenance procedures you can perform on the PXI-1031 and

PXI-1031DC chassis.

Caution

DC Fuse Replacement (PXI-1031DC Only)

The PXI-1031DC is protected against over-current by a 30 A fuse on the rear of the chassis, as

shown in Figure 1-3,

with a Wickmann 162.6385.530, Littlefuse 257 030, or equivalent. To remove the fuse, pull

straight out from the chassis.

Clean dust from the chassis exterior (and interior) as needed, based on the operating

environment. Periodic cleaning increases reliability.

The information in this chapter is designed for use by qualified service personnel. Read the Read

Me First: Safety and Electromagnetic Compatibility document included with your kit before

attempting any procedures in this chapter.

Caution

damage. Service the chassis only in a static-free environment. Observe standard

handling precautions for static-sensitive devices while servicing the chassis. Always

wear a grounded wrist strap or equivalent while servicing the chassis.

Disconnect the power cables prior to servicing the chassis.

Rear View of the PXI-1031DC

Many components within the chassis are susceptible to static discharge

Chassis. The fuse should only be replaced
