Integra MEDIACLAVE 10 Quick Start Manual

Media sterilizer
Hide thumbs Also See for MEDIACLAVE 10:
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Quick Start Guide
This quick start guide is intended to provide a quick overview of your MEDIACLAVE's
(MC) key features and to offer basic instructions for getting started. For detailed
information, please refer to the operating instructions (OI) that can be found at
www.integra-biosciences.com

Intended use

This is a general-purpose laboratory instrument. Any use of this instrument in a medical or IVD setting
is the sole responsibility of the user. MEDIACLAVE 10/30 is used for the preparation and sterilization
of media and can easily be converted to a water bath (or for MC10 only to an autoclave for media
sterilization in glassware).

Safety information

Regardless of the listed safety notes, all locally applicable regulations must be observed.
1) This product may only be operated in a secure, protected network with trustworthy clients.
2) MEDIACLAVE may only be used by properly trained personnel in a manner specified by
INTEGRA Biosciences.
3) In error case the instrument must not be used, e.g. if the pressure value is not displayed or above
1.7 bar or hot steam is released from the safety valve. There is the risk of burns or explosion.
The instrument must be immediately switched off and separated from electricity supply. Stay
away from the device.
4) Observe the hazard warnings on the device. Caution is required when opening ports or the vessel
lid (potential risk of delay in boiling). Always wear safety goggles and oven gloves.
5) The hoses may get hot. Do not touch the hoses during operation.
6) Servicing work and repairs may only be performed by INTEGRA Biosciences or an authorized
after-sales service member.
7) It is mandatory that a service is carried out at least once a year or after 1000 sterilization cycles
(whatever is reached first).

Getting started

Install the instrument on a horizontal surface according to the IQ (PN 136951) and OQ (PN
136952) documents.
d
e
f
g
k
Switch on the device. In the MAIN MENU, three options are accessible:
136968_V01_QSG_MEDIACLAVE_10_30_EN.docx
in different languages.
a
b
c
h
i
j
• SELECT PROGRAM: To define and execute a program.
• MAINTENANCE: To drain or fill the vessel, automatically clean the
device and perform the safety valve tests.
• SYSTEM PARAMETER: To configure general device parameters,
make a backup to USB, etc..
MEDIACLAVE 10/30 Media Sterilizer
a. Safety cover
b. Safety valve
c. Dispense port
d. Vessel lid
e. Temperature probe for media
f.
Adding port
g. Safety cover lock
h. Operating panel
i.
Main switch
j.
USB port
k. Printer (optional)
Switch on/off:
Press the main switch.
1/6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MEDIACLAVE 10 and is the answer not in the manual?

Questions and answers

Related Manuals for Integra MEDIACLAVE 10

Summary of Contents for Integra MEDIACLAVE 10

  • Page 1 This is a general-purpose laboratory instrument. Any use of this instrument in a medical or IVD setting is the sole responsibility of the user. MEDIACLAVE 10/30 is used for the preparation and sterilization of media and can easily be converted to a water bath (or for MC10 only to an autoclave for media sterilization in glassware).
  • Page 2 Language selection Navigate to SYSTEM PARAMETER and LANGUAGE SELECTION. Select a language and press SAVE. Set other system parameters to your requirements. Preparing a media preparation program • Check, if the white pivot pin disk inside the cuvette is pushed fully downwards and place the magnetic stirrer bar on the pivot pin inside at the cuvette bottom.
  • Page 3 • Close the vessel lid by turning the grips clockwise around the attachment point. The grips of the vessel lid (1) must be aligned above the black stickers (2). • Close the safety cover and keep it pressed down until it is locked by the bolt after pressing START.
  • Page 4 MEDIACLAVE must not be disposed of with unsorted municipal waste. Dispose of MEDIACLAVE in accordance with the regulations in your area governing disposal of devices. Manufacturer INTEGRA Biosciences AG INTEGRA Biosciences Corp. CH-7205 Zizers, Switzerland Hudson, NH 03051, USA T +41 81 286 95 30...
  • Page 5 136968_V01_QSG_MEDIACLAVE_10_30_EN.docx...
  • Page 6 136968_V01_QSG_MEDIACLAVE_10_30_EN.docx...
