Tmax
DOC. N.° 1SDH000664R0001
-
B1084
Adattatore per sistema sbarre 60mm
Adaptor for 60 mm busbar system
Adapter für Sammelschienensystem 60mm
Adaptateur pour système de jeux de barres 60 mm
Adaptador para sistema de barras de 60 mm
T4 P
T5 P
T4 F
M5x85
M5x85
x4
x4
3x12
T5 400 F
T5 630 F (I max = 520A)
x3
M8x20
3x12
3x12
Advertisement
Related Manuals for ABB Tmax Series
Summary of Contents for ABB Tmax Series
- Page 1 Tmax DOC. N.° 1SDH000664R0001 B1084 Adattatore per sistema sbarre 60mm Adaptor for 60 mm busbar system Adapter für Sammelschienensystem 60mm Adaptateur pour système de jeux de barres 60 mm Adaptador para sistema de barras de 60 mm T4 P T5 P T4 F M5x85 M5x85...
- Page 2 MIN 5 MAX 10 MIN 15 MAX 30 12 Nm 12 Nm 12 Nm CH 6...
- Page 3 <440 V 30 0 25 ≥ 440 V 0 25 <500 V ≥ 500 V 45 40 25 ≤690 V 750 V 130 160 50 50 MAX 570...
- Page 4 P ONLY 2,5 Nm M5x85 M5x105 P ONLY...
- Page 5 P ONLY T4-T5 400 F T4-T5 400 F...
- Page 6 T4-T5 400 F 18 Nm 28 Nm 2,5 Nm T4-T5 400 F Ue≥500V...
- Page 7 T4 P ONLY EXAMPLE WITH AUX T5 P EXAMPLE...
- Page 8 T4 P 26.75 52.5 MIN5 MAX 113.2 WITH FLANGE 166.5 64.5 CON MOSTRINA WITHOUT FLANGE 34.25 166.5 60.5 SENZA MOSTRINA 17.5 59.5 COMPARTMENT DEPTH ≤ PROFONDITA' QUADRO 198.5 T4 F 26.75 52.5 MIN5 MAX 113.2 17.5 WITH FLANGE 59.5 166.5 64.5 CON MOSTRINA WITHOUT FLANGE...
- Page 9 T5 P 26.75 69.75 MIN5 MAX 146.7 19.5 34.25 WITH FLANGE 166.5 64.5 CON MOSTRINA 46.5 46.5 WITHOUT FLANGE 166.5 60.5 59.5 SENZA MOSTRINA 139.5 COMPARTMENT DEPTH PROFONDITA' QUADRO ≤ 198.5 26.75 T5 F 139.5 69.75 MIN5 MAX 147.7 59.5 WITH FLANGE 166.5 64.5...
- Page 10 * Consultare ABB per le prescrizioni di installazione. * Contact ABB for installation instructions. * Detaillierte Einbauanweisungen bei ABB erfragen. * Consulter ABB pour les prescriptions d’installation. * Consultar a ABB sobre las modalidades de instalación. For more information please contact: ABB S.p.A. ABB SACE Division...
