i Series Inverter Generators
i2500W / i5000W
Read this manual carefully before use and keep it for future reference. Failure to do so
may result in injury, property damage and may void the warranty.
Products covered by this manual may vary in appearance, assembly, inclusions,
specifications, description or packaging.
V 2.0
Advertisement
Table of Contents
Related Manuals for Bohmer-AG i5000W
Summary of Contents for Bohmer-AG i5000W
- Page 1 Series Inverter Generators i2500W / i5000W Read this manual carefully before use and keep it for future reference. Failure to do so may result in injury, property damage and may void the warranty. Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description or packaging.
-
Page 2: Table Of Contents
Series Contents Contents Important safety information Quick start guide i2500W Parts Diagram Panel Diagram Quick start guide i5000W Parts Diagram Panel Diagram Before Starting Starting Stopping Checks and maintenance Spark plug Air filter Oil change Fuel filter Maintenance schedule... -
Page 3: Important Safety Information
i Series Important safety information • Do not attempt to modify the product In any way. • Service regularly and only use replacement parts supplied by the manufacturer. • Only use fresh, clean and good quality fuel in the engine. •... -
Page 4: Quick Start Guide I2500W
i Series Quick start guide i2500W The following steps describe the quickest method to get your generator up and running, however it is essential you fully read the manual to ensure you are familiar with the general safety features, precautions and functions necessary to operate your generator, failure to do so may result in injury, damage to your generator or personal items. -
Page 5: Panel Diagram
i Series Before use, you must ensure the oil is topped up with 10W-40 semi synthetic to the upper limit or the generator’s safety mechanisms will not allow the engine to start. UPPER LEVEL Panel Diagram 7. AC outlets 11. Low oil warning light 8. -
Page 6: Quick Start Guide I5000W
Series Quick start guide i5000W The following steps describe the quickest method to get your generator up and running, however it is essential you fully read the manual to ensure you are familiar with the general safety features, precautions and functions necessary to operate your generator, failure to do so may result in injury, damage to your generator or personal items. -
Page 7: Panel Diagram
i Series Before use, you must ensure the oil is topped up with 10W-40 semi synthetic to the upper limit or the generator’s safety mechanisms will not allow the engine to start. UPPER LEVEL Panel Diagram Economy switch Power ON / OFF switch AC sockets Low oil warning light DC terminal... -
Page 8: Before Starting
i Series Before Starting Add fuel: 1. Open the filler cap 2. Fill with unleaded petrol up to the filter 3. Replace filler cap Add oil: Note: The generator will automatically shut down if insufficient oil is detected. 1. Place generator on a level surface 2. -
Page 9: Starting
i Series Starting 1. Set the Economy switch to off 2. Connect your devices: • AC: Connect device’s plug to 3-pin plug outlet • DC: Connect your device’s black wire to the black negative terminal, the red wire to the red positive terminal. The DC output can be used to charge the battery (electric start models only) 3. -
Page 10: Checks And Maintenance
i Series Checks and maintenance Spark plug 1. Remove spark plug cap and unscrew 3. Check the gap using a gauge. The gap should be between 0.7-0.8mm. the spark plug using the tool. 2. Carefully clean any carbon build-up 4. Adjust as necessary then reinstall the plug and cap taking care not to on the tip. -
Page 11: Oil Change
i Series Oil change 1. Undo the oil bung 2. Place a pan under the generator 3. Tip the unit forward to allow oil to drain through the filler hole 4. Add new 10W-40 semi synthetic oil to the upper limit of oil cap 5. -
Page 12: Fuel Filter
i Series Fuel filter 1. Switch off the fuel tap 3. Clean sediment cup and filtering mesh 2. Remove sediment cup and filtering 4. Install sediment cup and filtering mesh mesh Maintenance schedule After first 5 First month or Every 3 months Every 6 months Every year or Component/Task... -
Page 13: Troubleshooting
i Series Troubleshooting Issue Probable Cause Solution Check / refuel as No fuel in the tank necessary Check and top up as Not enough engine oil necessary Engine will not start Check spark plug. Clean / No spark replace as necessary Fuel not reaching Clean fuel sediment cup carburettor... -
Page 14: Specifications
Series Specifications i2500W i5000W 2000 W 3000 W Max Output Rated Output 1800 W 2800 W 240 V 240 V Rated AC Voltage 12 V 12 V Rated DC Voltage 120 CC 212 CC Engine Displacement 10 L 12 L Fuel Capacity 0.6 L... -
Page 15: Ce Declaration Of Conformity
i Series CE Declaration of Conformity Böhmer-AG We hereby declare that the machine described below complies with the relevant basic safety and health requirements of the EU Directives, both in its basic design and construction as well as in the version put into circulation by us. This declaration shall cease to be valid if the machine is modified without our prior approval.
