Status Display - HBM TIM40 Mounting Instructions

TIM40
9

Status display

Status
LED
Status
Link
Act
H1
H2
A2590−2.0 en
Function Color/status
Transmission of Green
measured values
Red
Flashing red
Link status Green
Ethernet Flashing
communication green
CAN Bus: Run
PROFIBUS:
Operation mode
CAN Bus: Error
PROFIBUS:
Status
Link Act H1 H2
Meaning
Transmission of measured values OK
Transmission of measured values not
OK
Parameter inconsistent or incorrect
Link status
Transmission / reception activity
For more information refer to
Chapter 11
25
HBM
