Thank you for choosing this Friedland product. Please use the following
instructions to ensure correct installation and use. Keep these notes in a safe place for
.
future reference
Checking pack contents
Unpack your push and identify the
following parts:
Bell Push/Converter
CR2032 battery for bell push
2 x fixing screws for push
Bell wire (for use with a wired push)
Adhesive pad
You will need:
A 4mm cross-head screwdriver
A small flat bladed screwdriver
Quick start
You need to do the following to get started:
Open the bell push/converter
Fit the push battery
Follow the programming procedure for your
Libra+ chime.
Libra+ Converter/Push
Safety
Before proceeding with the installation,
please note the following safety warnings:
¬ Always follow the manufacturer's advice
when using power tools and wear suitable
protective equipment (e.g. safety goggles)
when drilling holes etc.
¬ Before drilling holes in walls, check for
hidden electricity cables and water pipes,
the use of a cable/pipe locater maybe
advisable if in doubt.
¬ When connecting the landscape
push/converter to other manufacturers'
equipment, check manuals and if necessary
consult the manufacturer regarding suitability
for the intended use.
