INSTALLING THE RISER ONTO A WASHER
1
INSTALLING RISER BODY
• Use an open-end wrench to remove the 4 washer
leveling legs.
• Locate the 4 plastic spacers (A) and match them
to their locations on the riser. Snap into place.
2 INSTALLING LEVELING LEG
BRACKETS
• Secure both leveling leg brackets to the bottom
of the riser with the 18 short mounting screws
(9 per leveling leg bracket). After attaching the
screws, fully screw in the 4 leveling legs. Do not
tighten the lock nuts at this time.
31-3000212 Rev. 0
Installation Instructions
• Align top of riser body with bottom of washer and
ensure the riser hose is on the same side as the
back of the washer. Using a 5/8" socket wrench
(deep well or extension required). Install all 4 bolts
through the bottom of the riser and into the empty
leveling leg holes in the washer. DO NOT tighten.
• After all 4 bolts are in place, securely tighten.
3 LEVELING UNIT
• Carefully upright the washer and move it close
to its final location.
• Make sure that the washer is level by placing
a level on top. Check side to side and front to
back.
• Use and open ended wrench to adjust the legs
in and out. Tighten the lock nut against the
bottom of the pedestal.
NOTE: To minimize vibration, the locking nuts
must be tight.
