GSM: 90%;
Time 17:01 22.7.
JABLOTRON 100:
Status:
Section 1: Unset;
Section 2: Unset;
UNSET
Section 3: Unset;
(control of the
Section 4: Unset, Error;
whole system)
Section 5: Unset;
Section 6: Unset;
Authorization:
Section 7: Unset;
All
Section 8: Unset;
GSM: 90%;
Time 17:01 22.7.
JABLOTRON 100:
SET 1 3 5 7
Status:
Section 1: Set;
(control of
selected system
Section 3: Set;
sections)
Section 5: Set;
Section 7: Set with an active zone,
Authorization:
GSM: 90%;
All
Time 17:01 22.7.
JABLOTRON 100:
UNSET 2 4 6 8
Status:
(control of
Section 2: Unset;
selected system
Section 4: Unset;
sections)
GSM: 90%;
Authorization:
Time 17:01 22.7.
All
9.7
Controlling the system via F-Link or J-Link
F-Link and J-Link SW are used for local and remote programming of the whole system or user editing; provide
an overview of section statuses and section control. It's possible to control sections and PG outputs using
segments of the virtual keypad according to the configuration of keypads which are physically present
in the system. Control is also possible from the "Section" tab in the "status" column or from the lower status bar.
The system records system control according to authorization upon user authorization in the software.
JA-101K(-LAN)(-LAN3G) and JA-106K(-3G)
Security System Control Panels
GSM signal quality
Time and date of handing over the SMS to the GSM
network
Installation name in accordance with the Initial setup tab
Status:
Name and status of Section 1
Name and status of Section 2
Name and status of Section 3
Name and status of Section 4
Name and status of Section 5
Name and status of Section 6
Name and status of Section 7
Name and status of Section 8
GSM signal quality
Time and date of handing over the SMS to the GSM
network
Installation name in accordance with the Initial setup tab
Status:
Name and status of Section 1
Name and status of Section 3
Name and status of Section 5
Name and status of Section 7
GSM signal quality
Time and date of handing over the SMS to GSM
Installation name in accordance with the Initial setup tab
Status:
Name and status of Section 2
Name and status of Section 4
GSM signal quality
Time and date of handing over the SMS to GSM
49 / 110
MLJ51410
