Register your product and get support at
ENG Quick Start Guide
N.V. Electronics Philips
CED320
1
a
b
c
e
English
reserved. rights All
Connector Connect to
Koninklijke 2008 ©
1
Black wire A metal surface of the car
Overview of parts
These are the supplierd parts needed to connect
and install this unit.
2
Yellow wire The +12V car battery which
a Carry case with front panel stored inside
b Trim plate 3
Orange/
white wire
c Standard connector
4
Red wire
d Rubber cushion
e Removal keys x 2 pcs
f Screw x 4 pcs
Connect wires: ISO connectors
1 5
Pull out the ISO connectors from the car Green and
dashboard and connect them to the bigger
green/black
end of the supplied standard connector.
wires
6
2 White and
Connect the other end of supplied standard
connector to the unit.
white/black
wires
3
Do the other connections, if applicable.
7
Gray and
gray/black
wires
Connect wires: without ISO
8
Purple and
connectors
purple/
black wires
1
Cut off the bigger end of the supplied stan-
dard connector.
3
Connect the supplied standard connector to
2
Check the car's wiring carefully, then connect
the unit.
them to the standard connector.
4 Do the other connections, if applicable.
2a
2b
d
f
Connect parking brake cable
First connect the black ground
(earth) lead, then connect the
Connect reverse driving cable
yellow and red power supply
leads.
is live at all times.
Attach the front panel
Illumination switch
1 Attach the trim plate.
The +12V power terminal
2
Insert the left side of the panel in the chassis
which is live in the accessory
until it is correctly engaged.
(ACC) position of the ignition
3
Press the right side of the panel until the
switch
mechanism locks it into place.
If there is no accessory posi-
tion, connect to the +12V car 4
Close the front panel.
battery terminal that is always
live. Be sure to connect the
Mount in the dashboard
black ground (earth) lead to a
metal surface of the car fi rst.
Note
Left speaker (Rear)
For proper operation of the DVD player, the
•
chassis must be mounted within 20 degree
Left speaker (Front) horizontal. Ensure that the unit is mounted
within this limitation.
Right speaker (Front)
1
If the car does not have an on-board drive or
navigation computer, disconnect the negative
terminal of the car attery.
Right speaker (Rear)
• If you disconnect the car battery in
a car that has an on-board drive or
navigation computer, the computer may
lost its memory.
• If the car battery is not disconnected,
to avoid short-circuit, ensure that bare
wires do not touch each other.
2
Ensure that car dashboard opening is within
these measurements:
3
Remove the two transport screws on the
top of the unit.
4
Remove the mounting sleeve with the
removal keys.
5
Install the sleeve into the dashboard and
bend the tabs outward to fi x the sleeve.
• If the unit is not fi xed by sleeve but by
the supplied screws, skip this step.
8
1
2
7
3
4
6
5
6 4
Place the rubber cushion over the end of the
Select [TIME MODE], then press
bolt.
»
The time mode options are displayed:
7
Slide the unit into the dashboard until a click »
[12 HOUR MODE]
sound is heard.
»
[24 HOUR MODE]
8
Reconnect the negative terminal of the car
5
Sselect a mode, then press SEL.
battery.
6
Press to return to previous menu and
select [TIME ADJUST], then press
7
Press or to enter clock, then press SEL.
Detach the front panel
The front panel can be detached and taken with
you to deter theft.
Tune to a radio station
1
Press SOURCE to select Tuner.
Note
2
Press or to select band.
Before installing the unit, detach the front
• »
[FM] or [AM] is displayed.
panel.
3
Press or to tune to a radio station
manually.
1
Press to release the panel.
• To search for radio station automatically,
2
Open the panel, then push the right side press or
panel toward the left side to disengage it
from the chassis.
3
Take off the panel and store it in the supplied Play discs
carry case to protect it from dirt or damage.
1
Press to open the front panel.
2
Insert the disc into the disc slot with label
Turn on
side facing up.
»
Play resumes from the point where it was
1
Press the knob to turn on the unit.
last stopped.
»
The unit plays the last listened program:
3
To remove the disc, press the button.
DVD, Tuner, USB or SD/MMC Card (if there is
»
When the disc is ejected, the unit switches
USB device or SD/MMC card connected).
to TUNER mode automatically.
• To turn off the unit, press the knob for
4
more than 2 seconds. Close the front panel.
»
• When the unit is idle for over 5 minutes, it After a few seconds, the screen turns on.
goes to standby mode and displays screen
» For video discs, if a menu appears: press
saver.
or to select an item, then press
play.
»
For discs that contain MP3s, WMAs, or
Set clock
JPEGs: , press or
picture, then press
1
Press MENU.
2
Press the navigation buttons to select [SET-
TINGS], then press SEL on the remote
control.
3
Select [SYSTEM], then press .
ANTENNA
SUB OUT
PARKING
REAR LINE OUT R
REAR LINE OUT L
FRONT LINE OUT R
FRONT LINE OUT L
CAMERA IN
VIDEO OUT 2
VIDEO OUT 1
CAMERA
Insert USB device
.
1
Slide down the USB socket cover.
2
Insert the USB device into the USB socket.
» The unit star ts playing from the USB
device automatically.
.
Insert SD/MMC card
1
Press to open the front panel.
2
Insert the SD or MMC card into the card
slot.
»
The unit starts playing from the SD/MMC
card automatically.
for 3 seconds.
to start
to select a folder/track/
to start play.
