GPRINTER BABY380 User Manual

Portable Thermal Printer

Safety warning

Only the supplied AC power adapter and lithium battery is allowed
to use, otherwise it may cause device damage, battery leakage, fire,
and even explosion.
Do not put the battery into a fire or apply direct heat to it or
disassemble it, otherwise cause the battery leakage, fire, and even
explosion.
Please remove the battery from the printer and store separately if
the printer will not be used for a long period of time, otherwise cause
the battery leakage.
As the battery's liquid is corrosive, if there any case of operational
mistakes to cause leakage, please wash immediately with plenty of
clean water if skin or clothes contact it carelessly. If entering eyes,
wash with plenty of clean water at once and seek medical advice.

Safety notice

Do not touch the paper tear-off knife.
The print head is a heated part, please do not touch the print head
and other parts around it during or after the printing process.
Do not touch the print head and plug-in parts to avoid print head
damage.
Do not open the top cover when printing, otherwise may cause
printer work failure.
In order to get good print quality, and extend the device service life,
we suggest that using the recommended thermal paper roll or which
is the same quality of.
Do not print when it's out of paper, which will seriously damage the
print head and rubber roller.
Make sure printer power is turned off when connecting and
disconnecting the power cable or data cable.
Do not let water or conducting material (eg. Metal) into the printer,
please turn off the power immediately if happened.
Please make sure to charge the battery for 60% or above and then
remove the battery from the printer and store separately if the printer
will not be used for a long period of time.
Please keep this manual for your reference.

Main Features:

Label & receipt printer 2-in-1.
Two kinds of Interface optional: USB+Bluetooth (standard ),
USB+WiFi (optional)
USB+Bluetooth: BT3.0 and BLE4.0, support Android and iOS system.
USB+WIFI: AP/STA/AP+STA mode to set up the networks.
Compatible with ESC/POS printing commands, support NV logo
download printing, various 1D bar code and QR code.
Low power consumption, good print quality, 50km mechanism lifespan.
Support GB18030 Simplified Chinese, Big5 traditional Chinese,
Korean, international character set and extended code pages.
LED can be showed abnormal condition of the printer, battery capacity
status, charging and connection status ect.
Freely offer DLL, SDK, Demo for developing.
Portable Thermal Printer
Unpacking
After unpacking the unit, please check that all the necessary
accessories are included in the package.
User's manual
Printer
Lithium battery
USB cable
Power adapter
Technique Spec
Print mode Label mode
Print method Direct line thermal
203DPI
Dot density
Print speed 60mm/s (max)
Interface
USB+Bluetooth 4.0, USB+Wi-Fi
Print width Max
72mm
Label size Max 72mm*220mm
Buffer
DRAM: 128KB FLASH:128KB
Print commands TSPL
Cover open detect Microswitch
Paper sensor
Photo electricity
Paper back-feed Not available
Code page
Barcode
Character fonts
(GB18030+Big5+Korean)/Japanese, ANK
Paper type Adhesive thermal paper Thermal paper roll
Paper width
45~79mm
Paper diameter
50mm±0.5mm
Paper cutting way
Top paper out, tear-off
Lithium battery
7.4V 2200mAh
Power adapter
Input: AC220V output: DC 9V/1A
Charge period
3h-5h
Work
Temperature: 5～45℃, Humidity: ≤93% RH
Environment
Storage
Temperature: 5～50℃, Humidity: ≤93% RH
Environment
131mm*107mm*58mm
Dimension
Weight 430g (including battery)
Mechanism 50km
Portable Thermal Printer
1pcs
1pcs
1pcs
1pcs
1pcs
Receipt printer
60mm/s
72mm
Unlimited
NV FLASH: 60KB
ESC
79mm
