SERVICE
COLOR MONITOR
COLOR MONITOR
LB15VS/
LB17LS/LB17KS
LB17LT/LB17KT
Manual
CONTENTS
8. Block Diagram
9. Wiring Diagram
10. PCB Layout
11. Schematic Diagrams

Advertisement

loading

Related Manuals for Samsung LB15VS

Summary of Contents for Samsung LB15VS

  • Page 1: Table Of Contents

    COLOR MONITOR LB15VS/ LB17LS/LB17KS LB17LT/LB17KT SERVICE Manual COLOR MONITOR CONTENTS 1. Precautions 2. Product Specifications 3. Disassembly & Reassembly 4. Alignment & Adjustments 5. Troubleshooting 6. Exploded View & Parts List 7. Electrical Parts List 8. Block Diagram 9. Wiring Diagram 10.

  • Page 2: Precautions

    / or other hazards. Product safety is under review continuously and new instructions are issued whenever appropriate. Components identified by on schematics and parts lists must be sealed by a soldering iron after replacement and adjustment. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 3 “anti-static” can together, or lifting your foot from a carpeted floor can generate electrical charges sufficient to damage ESDs. generate enough static electricity to damage an ESD. Indicates ESDs on the Schematic Diagram in this manual. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...

  • Page 4: Product Specifications

    2 Product Specifications 2 Product Specifications 2-1 LB15VS Specifications Item Description Picture Tube: 15-Inch (38 cm): 13.8-inch (35 cm) viewable, Full-square flat-face tube, 90˚ Deflection, Semi- tint, Non-glare, Invar shadow mask, Anti-static silica coating, 0.28 mm Dot pitch Scanning Frequency...
  • Page 5 Operating Temperature : 32°F ~ 104°F (0°C ~ 40°C) Humidity : 10 % ~ 80 % Storage Temperature : -4°F ~ 113°F (-20°C ~ 45°C) Humidity : 5 % ~ 95 % • Designs and specifications are subject to change without prior notice. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 6 Blue H/V Sync Sense 0 DDC Return Green GND-R GND-G GND-G Sense 1 GND-B Reserved DC 5V Blue GND-Sync/Self-raster Sense 2 DDC Data V-Sync H-Sync GND-B V-Sync DDC Clock H-Sync Figure 2-1. Male Type Figure 2-2. Male Type LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 7 2 Product Specifications 2-4 Timing Chart This section of the service manual describes the timing that the computer industry recognizes as standard for comput- er-generated video signals. 2-4-1 LB15VS Table 2-1 Timing Chart Mode VESA (LE15V* Only) 800/85 Hz 640/85 Hz...
  • Page 8 B : Horizontal sync width O : Frame time total P : Vertical sync width C : Back porch D : Active time Q : Back porch R : Active time E : Front porch S : Front porch LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...

  • Page 9: Disassembly & Reassembly

    3 Disassembly and Reassembly 3 Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the LB15VS/LB17LS/LB17KS/LB17LT/LB17KT CDT monitors. WARNING: This monitor contains electrostatically sensitive devices. Use caution when handling these components. 3-1-1 LB15VS Cautions: 1.
  • Page 10 4. Disconnect 3 ground from the shield video and carefully remove the silicon glue on the CDT socket with a razor. Caution : CDT socket may be easily damaged. Please use caution when remoning the silicon glue. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 11 1. Release the snaps on the rear stand and pull the stand backwards from the monitor and remove 2 screws from the rear top shield. 2. Insert the opining jig into the grooves at each side and press until it cilcks and lift up the rear cover. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 12 6. Disconnect function wire connecter from the MAIN board. Remove 4 screws from the front cover. 7. Remove CDT from the front cover. 3-2 Reassembly Reassembly procedures are in the reverse order of disassembly procedures. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...

  • Page 13: Alignment & Adjustments

    Test the unit again in all directions. If the monitor again fails to meet specifications in every direction, contact your Regional After Service Center for possible CDT replacement. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 14 Use control bar after selecting size B+ in the left Menu to adjust the horizontal size of the display, Pattern to 267mm(Tolerance : ±4mm.)(15”) Pattern to 312mm(Tolerance : ±4mm.)(17”) Run the All Mode save in the Right Menu. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 15 Use control bar after selecting “V-LINEARITY BAL” in left menu to optimize the image. 4 mm 4-2-4 Trapezoid Adjustment Figure 4-4. Parallelogram CONDITIONS Scanning frequency: 54 kHz/85 Hz : 15” 68 kHz/85 Hz : 17” Display image: Crosshatch pattern LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 16 Use the directions in sections 4-3-2 through 4-3-3 to adjust the color coordinates for: 9300K to x = 0.283 ± 0.02, y = 0.298 ± 0.02 6500K to x = 0.313 ± 0.02, y = 0.329 ± 0.02 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 17 3. Click on the << or >> boxes next to R_CUT and B_CUT to adjust the R-Bias to x = 0.312 ± 0.02 and the B-Bias to y = 0.329 ± 0.02. 4-3-4 (b) GAIN (WITHOUT ABL) ADJUSTMENT LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 18 68 kHz/85 Hz : 17” Display image: White flat field Brightness: Cut off point at 24 ft-L Contrast: Maximum PROCEDURE Measure luminance at nine points on the display screen (see figure below). Figure 4-9. Luminance Uniformity Check Locations LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 19 4. Adjust the purity magnet rings on the PCM assembly to display a pure green pattern. Optimum setting: x = 0.285 ± 0.015, y = 0.600 ± 0.015 5. Repeat steps 4 and 5 using a red pattern and then again, using a blue pattern. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...

  • Page 20: Troubleshooting

    Check and replace D606. IC601 Pin 1 waveform is Check and replace IC601. right? Check and replace IC201, C627 Voltage is 13 V ± IC301, IC401, Q590, Q490, 0.5V? and 12V regulator circuit. Normal operation? Replace main board. Verify voltages. Done LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 21 Make no H/V Sync. (power off mode) LED blinks? Check IC201 Pin 40. Check IC201 Pin 5/Pin 6 and +12 V line off? Q624, Q625 operation. IC601 Pin 1 output Refer to 5-1-1 no power voltage exists? supply. Done LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 22 78 Vpp (Q401, Collector) 5-1-4 S Correction Failure Check S1 ~ S3 signal. S1~S3 signals are correct at Check and replace IC201. each frequency block? Check and replace Q451, Q452, Q453, Q458, Q457, Q456, Q455, D451, D452, D453. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 23 IC401 Pin 24 output duty Check and replace IC201, varies with different B+ IC401. 1300 Vpp (Q490, Collector) offset DAC values? Q490 collector Check and replace Q411, waveform is right? Q412, Q413, and Q414. Check components around D405 and L411. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 24 5-1-10 Tilt Failure ( Only 17” Function) Check tilt connector connection IC201 Pin 20 output duty varies Check and replace IC201. with different DAC values? Q323 Base output varies Check and replace Q323. with different DAC values? Check and replace Q321 and Q322. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 25 IC301 Pin 6 output exists? components around IC301. Check DY connector connection. 5-1-12 V Size or Position Variation Failure IC401 Pin 23 output varies Check and replace IC201 and with different DAC values? IC401. Check and replace IC301. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 26 IC102 Pin 22 input exists and Check and replace IC102. varies with different patterns? Check CN201. T501 Pin 8 output exists? Check and replace T501. IC201 Pin 26 output exists and varies with different Check and replace IC201. patterns? Done LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 27 5 Troubleshooting 5-1-15 Dynamic Focus Failure ( Only 17” Function) WAVEFORMS IC401 Pin 32 output is Replace the IC401. right? 0.58 Vpp (IC401, #32) Some parts around Q551 Replace failed part. are right? T561 Pin 6 input is 50.0 V (T561, #6) Check and replace C443.
  • Page 28 Check +12V, +80V line. inputs are right? Check and replace IC103. Cathode DC levels are Check +80V line. right? Check and replace IC103. 20.0V (IC103, #2,4,6) Check G2 wire, G2 voltage is right? CRT socket board and FBT. Change CRT. Done LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 29 5 Vpp (IC201, #13, 14) IC201 Pin 13 and 14 Check C202, C203 and X201. inputs are right? Check and replace IC201 and IC201 Pin 18 input is right? R225. All in/output values are Replace IC201. right? Done 5-10 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 30 1.00 V (IC101, #1) IC101 Pin 11 and 12 Check IC201 Pin 41 and 42. inputs are right? IC101 Pin 19, 20 and 21 Check and replace IC101. outputs are right? 1.00 V (IC101, #19,20,21) Check and replace IC101. Done LB15VS/LB17LS/LB17KS/ 5-11 LB17LT/LB17KT...
  • Page 31 S/W button? Check IC201. 5-1-20 Degaussing Failure Check degaussing connector. RL601 operation is right? Check D-coil and TH601. Q621 base input is right? Check and replace Q621. IC201 Pin 10 output is right? Check and replace IC201. Done 5-12 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 32 R, G, B cathode voltage. 5-2-2 Shut Down Blinking LED’s? Check power supply. Check horizontal, vertical deflection system and check Scan failure? power supply secondary voltages. Video failure? Check video board. Check and replace IC201. Done LB15VS/LB17LS/LB17KS/ 5-13 LB17LT/LB17KT...
  • Page 33 Check IC101 Pin 14, 15 and 16. cathodes? Check IC102. G2 voltage is right? Check T501. Heater voltage is right? Check D622, Q623 and R131. G1 voltage is right? Check D504, Q512 and T501. Replace CRT. Done 5-14 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 34 G2 voltage is right? Check T501. Blank pulse at Pin 3 of Check IC401. IC401? 20.00V (CRT Socket, G1) V_FLB pulse at Check Q511. collector of Q511? Valid the vertical pulse Check CN102 and CN201. on CRT socket G1? Done LB15VS/LB17LS/LB17KS/ 5-15 LB17LT/LB17KT...
  • Page 35 5 of CN202. Signals are right? Check video cable Signals at Pin 28 and 29 of Check IC201. IC201 are right? Signals at Pin 1 and 2 of Check IC401 IC401 are right? Check circuits on main board. Done 5-16 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 36 5 Troubleshooting 5-2-6 Misconvergence Adjust convergence. Convergence is now Done within spec.? Readjust convergence. Convergence is now Done within spec.? Change CRT and readjust convergence. Done LB15VS/LB17LS/LB17KS/ 5-17 LB17LT/LB17KT...
  • Page 37 Dynamic focus circuit is Refer to 5-1-15 dynamic right? focus failure. Replace the CRT and verify focus. 5-2-8 Purity Failure Degause Purity is correct? Done Degaussing circuit is Refer to 5-1-20 degaussing correct? failure. Replace CRT and verify purity. 5-18 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...

  • Page 38: Exploded View & Parts List

    6 Exploded View & Parts List 6 Exploded View and Parts List You can search for updated part codes through ITSELF web site. URL : http://itself.sec.samsung.co.kr/ 6-1 LB15VS LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 39 6 Exploded View & Parts List 6-2 LB17KS LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 40 6 Exploded View & Parts List 6-3 LB17KT LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 41 6 Exploded View & Parts List 6-4 LB17LS/LB17LT LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...

  • Page 42: Electrical Parts List

    7 Electrical Parts List 7 Electrical Parts List You can search for updated part codes through ITSELF web site. URL : http://itself.sec.samsung.co.kr/ 7-1 LB15VS Main PCB Parts Level Code No. Loc. No. Description Specification Remarks LB15VS SN-LB15VS SDI,NORMAL BH94-01019A ASSY PCB MAIN-SN...
  • Page 43 R-CARBON 100KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R205 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R206 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R213 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R214 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R216 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R217 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R218 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R219 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R241 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 44 300OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001129 R601 R-CARBON(S) 330KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001129 R602 R-CARBON(S) 330KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001178 R401 R-CARBON(S) 680OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001352 R610 R-CARBON 62OHM,5%,1/8W,AA,TP,1.8X3.2MM 2002-001099 R514 R-COMPOSITION 68KOHM,5%,1/2W,AA,TP,3.0X9.0MM 2002-001103 R605 R-COMPOSITION 300Kohm,5%,1/2W,AA,TP,3.7x10.0mm 2002-001103 R606 R-COMPOSITION 300Kohm,5%,1/2W,AA,TP,3.7x10.0mm 2002-001105 R515 R-COMPOSITION 36Kohm,5%,1/2W,AA,TP,3.3x9mm 2003-000437 R407 R-METAL OXIDE(S) 1.5ohm,5%,2W,AF,TP,4x12mm LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 45 C-FILM,LEAD-PPF 150nF,5%,250V,TP,19x16x7.5,7.5 2309-000106 C405 C-FILM,LEAD-OTHER 2.2nF,5%,1.6KV,TP,23x16x9,7.5m 2309-000106 C406 C-FILM,LEAD-OTHER 2.2nF,5%,1.6KV,TP,23x16x9,7.5m 2401-000039 C301 C-AL 1000uF,20%,16V,GP,TP,10x16,5 2401-000039 C622 C-AL 1000uF,20%,16V,GP,TP,10x16,5 2401-000039 C627 C-AL 1000uF,20%,16V,GP,TP,10x16,5 2401-000039 C631 C-AL 1000uF,20%,16V,GP,TP,10x16,5 2401-000603 C208 C-AL 1UF,20%,50V,GP,TP,5X11,2 2401-000603 C209 C-AL 1UF,20%,50V,GP,TP,5X11,2 2401-000603 C437 C-AL 1UF,20%,50V,GP,TP,5X11,2 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 46 JP15 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP16 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP17 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP18 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP19 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP20 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP21 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 47 HEAT SINK-FBT A1050S,T1.0,T1.0,-,- BP96-00072A HS590 ASSY HEAT SINK P H/S TR,SPRING,IRF630B,OIL SILICON BH61-00004A SPRING ETC-TR CDA,CDB,SUS304,-,-,-,-,-,T0.5,-,-,- BH62-00016A HEAT SINK-TR A1050S,T1.0,-,DP17MO 7-2 LB15VS Video PCB Parts Level Code No. Loc. No. Description Specification Remarks BH94-01021A ASSY PCB VIDEO-SN LB15VS7L/EDC,NETHERLANDS 0204-002420 CIS3...
  • Page 48 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V,TP,2.2x3. 2301-000010 C116 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 2301-000010 CB05 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 2301-000010 CG05 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 2301-000010 CR05 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 2301-000148 C102 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm 2301-000188 C117 C-FILM,LEAD-PEF 1nF,5%,100V,TP,10.5x12.5x6.5,5 2305-000149 C115 C-FILM,LEAD-PEF 100nF,5%,100V,TP,12x12.5x6.5,5 2401-000384 C114 C-AL 10uF,20%,100V,GP,TP,6.3x11,5mm 2401-001334 C104 C-AL 0.47UF,20%,50V,GP,TP,5X11,2.5 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 49 JP108 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP_15 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH41-00281A MP1.0 PCB-VIDEO LB17K,FR-1,1,1.0,1.6T,82.3*123.5,LIBRA,6,VIDEO BH71-40300A GT101 PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN 7-3 LB15VS Others Level Code No. Loc. No. Description Specification Remarks BH90-00587A ASSY COVER REAR LE15VS,EDC BH63-00123A COVER-REAR LE15VS,ABS V0,IV16 BH90-00598A ASSY STAND...
  • Page 50 Specification Remarks 3309-000002 MAGNET-SHEET 5x20x80mm,UL94V-0,2 6502-001019 CABLE CLAMP DAMC-10,ID9.9,T7.1,NYLON6.6,GRAY BH03-10014A CDT-SN M36KUM35X02,-,15,0.28,-,MS-GUN,-,-,-,-,-,VLMF,4 BH68-30003C LABEL-00,HIGH,VOLTAGE SS,ART 100G,30*33,YEL BH96-00362A ASSY D-COIL P 15INCH,BH27-00152A,BH96-00356A,LB15VS BH91-01009A ASSY CHASSIS-SC LB17LS7L/EDC,NEHTERLANDS,450V BH99-00004N HS103 ASSY HEAT/SINK BH62-00006A,SCREW+NUT,LM2470,OIL SILICON 1201-002155 IC-VIDEO AMP LM2470TA,TO-220,9P,-,-,-,PLASTIC,90V,4.3W,-20to+100C,-,-,-,-,-,ST 6006-001008 SCREW-MACHINE WSP,BH,+,M3,L10,ZPC(YEL),SWRCH 6021-000118 NUT-HEXAGON...
  • Page 51 1N4148,75V,150MA,DO-35,TP 0401-000005 D522 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D523 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D533 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D608 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D621 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D629 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0402-000006 D451 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000006 D452 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000006 D453 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 7-10 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 52 10OHM,5%,1/4W,AA,TP,2.4X6.4MM 2001-000116 R555 R-CARBON 820OHM,5%,1/4W,AA,TP,2.4X6.4MM 2001-000221 R418 R-CARBON 1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000241 R224 R-CARBON 1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000273 R324 R-CARBON 100KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R205 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R206 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R213 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R214 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R216 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM LB15VS/LB17LS/LB17KS/ 7-11 LB17LT/LB17KT...
  • Page 53 6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000908 R311 R-CARBON 62KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000995 R535 R-CARBON 820OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-001006 R230 R-CARBON 82OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-001053 R312 R-CARBON(S) 1.5OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001077 R633 R-CARBON(S) 150OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001078 R405 R-CARBON(S) 15KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001079 R327 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001079 R328 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001086 R305 R-CARBON(S) 18KOHM,5%,1/2W,AA,TP,2.4X6.4MM 7-12 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 54 100nF,80-20%,50V,Y5V,TP,2.2x3. 2202-002037 C607 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V,TP,2.2x3. 2202-002037 C616 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V,TP,2.2x3. 2301-000010 C403 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 2301-000016 C413 C-FILM,LEAD-PEF 22nF,5%,100V,TP,7.2x4.5x9.0mm, 2301-000016 C534 C-FILM,LEAD-PEF 22nF,5%,100V,TP,7.2x4.5x9.0mm, 2301-000106 C535 C-FILM,LEAD-PEF 1.5nF,0.05,100V,TP,10.5*12.5*6 2301-000110 C536 C-FILM,LEAD-PEF 1.8nF,5%,100V,TP,7x3.0x6.5mm,5 2301-000148 C433 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm 2301-000148 C435 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm LB15VS/LB17LS/LB17KS/ 7-13 LB17LT/LB17KT...
  • Page 55 1kV,+50-10%,-,-,RADIAL 6042-000001 EY301 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY302 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY401 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY402 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY403 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY601 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY602 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY603 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY604 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 7-14 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 56 0502-000465 TR-POWER KTD2058,NPN,25000mW,TO-220IS,ST,100-200 0502-001225 TR-POWER ST2310FX(566B),NPN,55000mW,ISOWATT218FX,ST,6.5-9.5 BH61-00004A SPRING ETC-TR CDA,CDB,SUS304,-,-,-,-,-,T0.5,-,-,- BH61-70003A SPRING ETC CVT4857,STS304-W1/2H,W3.8,-,L30,L30,-,T0.5,DEGRE,W3.8,STS304-W1/2H BH62-00015A HEAT SINK-FBT A1050S,T1.0,T1.0,-,- BP96-00067A HS451 ASSY HEAT SINK P H/S TR,SCREW+NUT,IRF630B,OIL SILICON 6006-001008 SCREW-MACHINE WSP,BH,+,M3,L10,ZPC(YEL),SWRCH 6021-000118 NUT-HEXAGON 1C,M3,ZPC(YEL),SM20C BH62-30024A HEAT SINK-TR SPC,T1,SN,CFX1577L LB15VS/LB17LS/LB17KS/ 7-15 LB17LT/LB17KT...
  • Page 57 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000429 RG04 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000429 RR04 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000660 R102 R-CARBON 33KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000734 R108 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000800 R101 R-CARBON 5.1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000969 RB01 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000969 RB02 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000969 RG01 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000969 RG02 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 7-16 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 58 JP104 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP105 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP106 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP107 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP108 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP_17 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH41-00281A MP1.0 PCB-VIDEO LB17K,FR-1,1,1.0,1.6T,82.3*123.5,LIBRA,6,VIDEO BH71-40300A GT101 PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN LB15VS/LB17LS/LB17KS/ 7-17 LB17LT/LB17KT...
  • Page 59 BH68-00572C OVER LABEL RATING-01 ALL,SS,PE,T0.05,90*65,BLK,POLYESTER,EDC BH92-01161N ASSY BOX LE17LS7L/EDC BH68-00329A LABEL BAR CODE-02 ALL,MPRII,DOM,EXPORT,MOJO 90G,WHT BH69-00573A S/M793S(LE17LS),W/W,CB-SW4,YEL,A-1,W452*D486*H435 BH92-01217H ASSY ACCESSORY LB15VS,17LS,17KS,EDC,NETHERLANDS BH96-00341H UNIT/ACCESSORY ASSY ACCESSORY LB15VS,17LS,17KS,EDC,NETHERLANDS DT,EU,FP3/YES,IEC320 C13/C14,250/250V,10-16/10A,BLK,1830MM,-,H05VV-F 3X0.75MM^2, 3903-000042 ACCESSORY CBF-POWER CORD 6902-000110 ACCESSORY BAG PE LDPE,T0.05,L356,W240,TRP,28,2,PE MARK BH68-70418A...
  • Page 60 1N4148,75V,150MA,DO-35,TP 0401-000005 D621 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D629 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0402-000006 D451 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000006 D452 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000006 D453 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000012 D603 DIODE-RECTIFIER UF4007,1KV,1A,DO-41,TP 0402-000012 D626 DIODE-RECTIFIER UF4007,1KV,1A,DO-41,TP 0402-000128 D301 DIODE-RECTIFIER 1N4002GP,100V,1A,DO-41,TP 0402-000208 D403 DIODE-RECTIFIER EK-04,40V,1A,DO-41,TP LB15VS/LB17LS/LB17KS/ 7-19 LB17LT/LB17KT...
  • Page 61 100KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R205 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R206 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R213 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R214 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R216 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R217 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R218 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R219 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R241 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 7-20 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 62 1.5OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001077 R633 R-CARBON(S) 150OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001078 R405 R-CARBON(S) 15KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001079 R327 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001079 R328 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001086 R305 R-CARBON(S) 18KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001088 R401 R-CARBON(S) 1KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001088 R513 R-CARBON(S) 1KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001088 R628 R-CARBON(S) 1KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001099 R501 R-CARBON(S) 2.7KOHM,5%,1/2W,AA,TP,2.4X6.4MM LB15VS/LB17LS/LB17KS/ 7-21 LB17LT/LB17KT...
  • Page 63 1.5nF,0.05,100V,TP,10.5*12.5*6 2301-000110 C536 C-FILM,LEAD-PEF 1.8nF,5%,100V,TP,7x3.0x6.5mm,5 2301-000148 C433 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm 2301-000148 C435 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm 2301-000174 C302 C-FILM,LEAD-PEF 15nF,5%,100V,TP,7.2x4.0x7.5mm, 2301-000284 C614 C-FILM,LEAD-PEF 47nF,5%,100V,TP,8.5x12.5mm,5mm 2301-000294 C521 C-FILM,LEAD-PEF 56nF,5%,100V,TP,9.5x12.5mm,5mm 2301-000312 C304 C-FILM,LEAD-PEF 8.2nF,5%,100V,TP,6x12.5mm,5mm 2301-001049 C331 C-FILM,LEAD-PEF 150nF,5%,100V,TP,10.5x5x14.5,5 2301-001293 C404 C-FILM,LEAD-PPF 4.4NF,5%,630V,TP,18X6.5X12.5MM,7.5 7-22 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 64 ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY602 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY603 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY604 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY605 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY606 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000002 EY404 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 6042-000002 EY405 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 6042-000002 EY406 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H 6042-000002 EY441 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H LB15VS/LB17LS/LB17KS/ 7-23 LB17LT/LB17KT...
  • Page 65 A1050S,T1.0,T1.0,-,- BP96-00067A HS451 ASSY HEAT SINK P H/S TR,SCREW+NUT,IRF630B,OIL SILICON 6006-001008 SCREW-MACHINE WSP,BH,+,M3,L10,ZPC(YEL),SWRCH 6021-000118 NUT-HEXAGON 1C,M3,ZPC(YEL),SM20C BH62-30024A HEAT SINK-TR SPC,T1,SN,CFX1577L BP96-00072C HS590 ASSY HEAT SINK P H/S TR,SPRING,IRF634B,OIL SILICON BH61-00004A SPRING ETC-TR CDA,CDB,SUS304,-,-,-,-,-,T0.5,-,-,- BH62-00016A HEAT SINK-TR A1050S,T1.0,-,DP17MO 7-24 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 66 390OHM,5%,1/2W,AA,TP,2.4X6.4MM 2201-000019 C105 C-CERAMIC,DISC 10nF,+80-20%,500V,Y5V,TP,13.5x4mm,5 2201-000119 C106 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 2201-000119 C109 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 2201-000119 C131 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 2201-000119 C132 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 2201-000152 C151 C-CERAMIC,DISC 10NF,+80-20%,1KV,Y5V,TP,20X4MM,5 2201-000152 C152 C-CERAMIC,DISC 10NF,+80-20%,1KV,Y5V,TP,20X4MM,5 2201-000370 C101 C-CERAMIC,DISC 0.22NF,10%,50V,Y5P,TP,4X3.5MM,5 2201-002110 C141 C-CERAMIC,DISC 1.8nF,10%,1kV,Y5P,TP,10x5mm,5 LB15VS/LB17LS/LB17KS/ 7-25 LB17LT/LB17KT...
  • Page 67 BRASS,D2.36!,HEAT/SINK,SN 7-10 LB17KS Others Level Code No. Loc. No. Description Specification Remarks BH90-00592A ASSY COVER REAR LE17JS,EDC BH63-00130A COVER-REAR LE17KS,ABS HB,IV16 BH90-00598A ASSY STAND LE17JS/LE15VS,EDC BH96-00272A ASSY STAND P LE17KS,ABS HB IV16 6902-000109 BAG PE HDPE,T0.015,L430,W350,TRP,28,2,PE MARK 7-26 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 68 BH68-00572C OVER LABEL RATING-01 ALL,SS,PE,T0.05,90*65,BLK,POLYESTER,EDC BH92-01161B ASSY BOX LE17KSBB*/EDC BH68-00530A LABEL BOX-01 LABEL-BARCODE,CE+TCO03,MOJO 90G,WHT BH69-00570A S/M793DF(LE17KS),W/W,CB-SW4,YEL,A-1,W452*D506*H435 BH92-01217H ASSY ACCESSORY LB15VS,17LS,17KS,EDC,NETHERLANDS BH96-00341H UNIT/ACCESSORY ASSY ACCESSORY LB15VS,17LS,17KS,EDC,NETHERLANDS 3903-000042 ACCESSORY CBF-POWER CORD DT,EU,FP3/YES,IEC320 C13/C14,250/250V,10-16/10A,BLK,1830MM,-,H05VV-F 3X0.75MM^2, 6902-000110 ACCESSORY BAG PE LDPE,T0.05,L356,W240,TRP,28,2,PE MARK BH68-70418A ACCESSORY...
  • Page 69 1N4148,75V,150MA,DO-35,TP 0401-000005 D523 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D533 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D608 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D621 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D629 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0402-000006 D451 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000006 D452 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000006 D453 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000012 D603 DIODE-RECTIFIER UF4007,1KV,1A,DO-41,TP 7-28 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 70 820OHM,5%,1/4W,AA,TP,2.4X6.4MM 2001-000221 R418 R-CARBON 1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000241 R224 R-CARBON 1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000273 R324 R-CARBON 100KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R205 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R206 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R213 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R214 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R216 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R217 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM LB15VS/LB17LS/LB17KS/ 7-29 LB17LT/LB17KT...
  • Page 71 62KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000995 R535 R-CARBON 820OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-001006 R230 R-CARBON 82OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-001053 R312 R-CARBON(S) 1.5OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001077 R633 R-CARBON(S) 150OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001078 R405 R-CARBON(S) 15KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001079 R327 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001079 R328 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001086 R305 R-CARBON(S) 18KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001088 R401 R-CARBON(S) 1KOHM,5%,1/2W,AA,TP,2.4X6.4MM 7-30 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 72 100nF,80-20%,50V,Y5V,TP,2.2x3. 2202-002037 C616 C-CERAMIC,MLC-AXIAL 100nF,80-20%,50V,Y5V,TP,2.2x3. 2301-000010 C403 C-FILM,LEAD-PEF 100nF,5%,100V,TP,11.5x12.5mm,5 2301-000016 C413 C-FILM,LEAD-PEF 22nF,5%,100V,TP,7.2x4.5x9.0mm, 2301-000016 C534 C-FILM,LEAD-PEF 22nF,5%,100V,TP,7.2x4.5x9.0mm, 2301-000106 C535 C-FILM,LEAD-PEF 1.5nF,0.05,100V,TP,10.5*12.5*6 2301-000110 C536 C-FILM,LEAD-PEF 1.8nF,5%,100V,TP,7x3.0x6.5mm,5 2301-000148 C433 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm 2301-000148 C435 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm 2301-000174 C302 C-FILM,LEAD-PEF 15nF,5%,100V,TP,7.2x4.0x7.5mm, LB15VS/LB17LS/LB17KS/ 7-31 LB17LT/LB17KT...
  • Page 73 ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY302 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY401 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY402 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY403 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY601 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY602 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY603 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY604 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY605 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 7-32 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 74 0502-000465 TR-POWER KTD2058,NPN,25000mW,TO-220IS,ST,100-200 0502-001225 TR-POWER ST2310FX(566B),NPN,55000mW,ISOWATT218FX,ST,6.5-9.5 BH61-00004A SPRING ETC-TR CDA,CDB,SUS304,-,-,-,-,-,T0.5,-,-,- BH61-70003A SPRING ETC CVT4857,STS304-W1/2H,W3.8,-,L30,L30,-,T0.5,DEGRE,W3.8,STS304-W1/2H BH62-00015A HEAT SINK-FBT A1050S,T1.0,T1.0,-,- BP96-00067A HS451 ASSY HEAT SINK P H/S TR,SCREW+NUT,IRF630B,OIL SILICON 6006-001008 SCREW-MACHINE WSP,BH,+,M3,L10,ZPC(YEL),SWRCH 6021-000118 NUT-HEXAGON 1C,M3,ZPC(YEL),SM20C BH62-30024A HEAT SINK-TR SPC,T1,SN,CFX1577L LB15VS/LB17LS/LB17KS/ 7-33 LB17LT/LB17KT...
  • Page 75 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000800 R101 R-CARBON 5.1KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000969 RB01 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000969 RB02 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000969 RG01 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000969 RG02 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000969 RR01 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000969 RR02 R-CARBON 75OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-001066 RB06 R-CARBON(S) 110OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001066 RG06 R-CARBON(S) 110OHM,5%,1/2W,AA,TP,2.4X6.4MM 7-34 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 76 JP104 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP105 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP106 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP107 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP108 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH39-40305U JP_17 CBF HARNESS 52MM,AWG22(0.6PI),-,-,AWG22(0. BH41-00281A MP1.0 PCB-VIDEO LB17K,FR-1,1,1.0,1.6T,82.3*123.5,LIBRA,6,VIDEO BH71-40300A GT101 PIN-HINGE BRASS,D2.36!,HEAT/SINK,SN LB15VS/LB17LS/LB17KS/ 7-35 LB17LT/LB17KT...
  • Page 77 CUSHION LE17LS,EPS M50,FST BH69-40380A PACKING-PAD DW-2,500X2200X200,-,CGK5527 BH92-01163S ASSY BOX BH68-00329A LABEL BAR CODE-02 ALL,MPRII,DOM,EXPORT,MOJO 90G,WHT BH69-00576A BOX-00,MONITOR S/T78E(LE17LT) W/W,CB-SW4,YEL,A-1,W452*D486*H435 BH92-01173B ASSY LABEL BH68-00565A LABEL LABEL RATING-00 ALL,SS,PE,T0.05,90*65,BLK,POLYESTER,NO SILK BH68-00573E OVER LABEL RATING-01 ALL,SAMTRON,PE,T0.05,90*65,BLK,POLYESTER,EDC BH92-01217J ASSY ACCESSORY LB17LT,17KT,EDC,NETHERLANDS 7-36 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 78 1N4148,75V,150MA,DO-35,TP 0401-000005 D523 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D533 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D608 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D621 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0401-000005 D629 DIODE-SWITCHING 1N4148,75V,150MA,DO-35,TP 0402-000006 D451 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000006 D452 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000006 D453 DIODE-RECTIFIER 1N4007GP,1KV,1A,DO-41,TP 0402-000012 D603 DIODE-RECTIFIER UF4007,1KV,1A,DO-41,TP LB15VS/LB17LS/LB17KS/ 7-37 LB17LT/LB17KT...
  • Page 79 820OHM,5%,1/4W,AA,TP,2.4X6.4MM 2001-000221 R418 R-CARBON 1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000241 R224 R-CARBON 1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000273 R324 R-CARBON 100KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R205 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R206 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R213 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R214 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R216 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000281 R217 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM 7-38 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 80 62KOHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-000995 R535 R-CARBON 820OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-001006 R230 R-CARBON 82OHM,5%,1/8W,AA,TP,1.8X3.2MM 2001-001053 R312 R-CARBON(S) 1.5OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001077 R633 R-CARBON(S) 150OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001078 R405 R-CARBON(S) 15KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001079 R327 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001079 R328 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001086 R305 R-CARBON(S) 18KOHM,5%,1/2W,AA,TP,2.4X6.4MM 2001-001088 R401 R-CARBON(S) 1KOHM,5%,1/2W,AA,TP,2.4X6.4MM LB15VS/LB17LS/LB17KS/ 7-39 LB17LT/LB17KT...
  • Page 81 100nF,5%,100V,TP,11.5x12.5mm,5 2301-000016 C413 C-FILM,LEAD-PEF 22nF,5%,100V,TP,7.2x4.5x9.0mm, 2301-000016 C534 C-FILM,LEAD-PEF 22nF,5%,100V,TP,7.2x4.5x9.0mm, 2301-000106 C535 C-FILM,LEAD-PEF 1.5nF,0.05,100V,TP,10.5*12.5*6 2301-000110 C536 C-FILM,LEAD-PEF 1.8nF,5%,100V,TP,7x3.0x6.5mm,5 2301-000148 C433 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm 2301-000148 C435 C-FILM,LEAD-PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm 2301-000174 C302 C-FILM,LEAD-PEF 15nF,5%,100V,TP,7.2x4.0x7.5mm, 2301-000284 C614 C-FILM,LEAD-PEF 47nF,5%,100V,TP,8.5x12.5mm,5mm 2301-000294 C521 C-FILM,LEAD-PEF 56nF,5%,100V,TP,9.5x12.5mm,5mm 7-40 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 82 ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY402 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY403 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY601 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY602 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY603 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY604 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY605 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000001 EY606 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 6042-000002 EY404 EYELET ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H LB15VS/LB17LS/LB17KS/ 7-41 LB17LT/LB17KT...
  • Page 83 A1050S,T1.0,T1.0,-,- BP96-00067A HS451 ASSY HEAT SINK P H/S TR,SCREW+NUT,IRF630B,OIL SILICON 6006-001008 SCREW-MACHINE WSP,BH,+,M3,L10,ZPC(YEL),SWRCH 6021-000118 NUT-HEXAGON 1C,M3,ZPC(YEL),SM20C BH62-30024A HEAT SINK-TR SPC,T1,SN,CFX1577L BP96-00072C HS590 ASSY HEAT SINK P H/S TR,SPRING,IRF634B,OIL SILICON BH61-00004A SPRING ETC-TR CDA,CDB,SUS304,-,-,-,-,-,T0.5,-,-,- BH62-00016A HEAT SINK-TR A1050S,T1.0,-,DP17MO 7-42 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 84 390OHM,5%,1/2W,AA,TP,2.4X6.4MM 2201-000019 C105 C-CERAMIC,DISC 10nF,+80-20%,500V,Y5V,TP,13.5x4mm,5 2201-000119 C106 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 2201-000119 C109 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 2201-000119 C131 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 2201-000119 C132 C-CERAMIC,DISC 100NF,+80-20%,50V,Y5V,TP,8X3MM,5 2201-000152 C151 C-CERAMIC,DISC 10NF,+80-20%,1KV,Y5V,TP,20X4MM,5 2201-000152 C152 C-CERAMIC,DISC 10NF,+80-20%,1KV,Y5V,TP,20X4MM,5 2201-000370 C101 C-CERAMIC,DISC 0.22NF,10%,50V,Y5P,TP,4X3.5MM,5 2201-002110 C141 C-CERAMIC,DISC 1.8nF,10%,1kV,Y5P,TP,10x5mm,5 LB15VS/LB17LS/LB17KS/ 7-43 LB17LT/LB17KT...
  • Page 85 HDPE,T0.015,L430,W350,TRP,28,2,PE MARK BH60-00030A FASTENER-BAND PN17LT,ST+PVC,P0.4,-,150,YELLOW,-,-,- BH61-00049A STAND-BASE LE17KS,ABS HB,IV16 BH61-00050A STAND-TOP LE17KS,ABS HB,IV16 BH61-40002A FOOT-RUBBER -,NR,PMS428U,GA4237,-,-,- BH63-30103A FELT-STAND MCM1755,FELT,T1.0,W10,L4 BH68-20366A LABEL-MARK STAND ,ART PAPER 100(S),WHT BH68-70306A CARD-STAND CVM4967PWS(SKD),WONSTROW,CHAIN BH90-00608A ASSY COVER REAR LE17KT/JT/LT BH63-00130C COVER-REAR LE17,ABS HB,IV16,SAMTRON 7-44 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 86 CUSHION LE17KS,EPS M50,DF BH69-40380A PACKING-PAD DW-2,500X2200X200,-,CGK5527 BH92-01149D ASSY BOX LE17KT BH68-00530A LABEL BOX-01 LABEL-BARCODE,CE+TCO03,MOJO 90G,WHT BH69-00577A BOX-00,MONITOR S/T78DF(LE17KT) W/W,CB-SW4,YEL,A-1,W452*D506*H435 BH92-01173B ASSY LABEL BH68-00565A LABEL LABEL RATING-00 ALL,SS,PE,T0.05,90*65,BLK,POLYESTER,NO SILK BH68-00573E OVER LABEL RATING-01 ALL,SAMTRON,PE,T0.05,90*65,BLK,POLYESTER,EDC BH92-01217J ASSY ACCESSORY LB17LT,17KT,EDC,NETHERLANDS LB15VS/LB17LS/LB17KS/ 7-45 LB17LT/LB17KT...
  • Page 87 7 Electrical Parts List Memo 7-46 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 88 VIDEO BOARD VIDEO OUTPUT SIGNAL VIDEO INPUT IC103(LM2470) VIDEO PRE-AMP + OSD SOCKET IC101(LM1236) H/V SYNC HEATER MAIN BOARD H-SYNC, V-SYNC H/V SIZE REG. H-SYNC1 VER. DY VER. OUTPUT 17"Only V-SYNC1 CN401 FROM IC401 IC301 (SVT9325) T501 210V E/W_OUT UP, DOWN HORZ./VER.
  • Page 89 9 PCB Diagrams 9 Wiring Diagram H_FLB CLAMP V_BLK 6.3V 6.3V KEY1 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 90 10 PCB Layout 10 PCB Layout 10-1 LB15VS/LB17LS/LB17KS/LB17LT/LB17KT Main PCB Layout Loc. No. Description Loc. No. Description DIODE ZD202 DIODE-ZENER 75.1 40.5 ZD203 DIODE-ZENER 73.6 60.2 D201 DIODE-SWITCHING 60.6 60.0 ZD204 DIODE-ZENER 75.1 34.5 D601 DIODE-BRIDGE 198.6 63.5 ZD211 DIODE-ZENER 32.5...
  • Page 91 10 PCB Layout 10-2 LB15VS/LB17LS/LB17KS/LB17LT/LB17KT Video PCB Layout Loc. No. Description DIODE DB01 DIODE-SWITCHING 110.5 66.0 DB02 DIODE-SWITCHING 118.5 68.5 DB03 DIODE-SWITCHING 28.0 45.5 DB04 DIODE-SWITCHING 20.5 48.2 DB05 DIODE-SWITCHING 24.5 18.0 DG01 DIODE-SWITCHING 110.5 46.0 DG02 DIODE-SWITCHING 118.5 61.0...
  • Page 92 11 Schematic Diagrams 11 Schematic Diagrams This Document can not be used without Samsung’s authorization. LB15VS/LB17LS/LB17KS/LB17LT/LB17KT 11-1 Main Schematic Diagram CN204 6.3V slcon2p KEY1 SCHEMATIC DIAGRAM 17" only OEM PROJECT OEM Only R325 R327 R328 CN203 CN205 Project Name: LIBRA...
  • Page 93 78 Vpp (Q401, Collector) 1300 Vpp (Q490, Collector) 0.44 Vpp (IC401, #24) 50 Vpp (IC301, #6) 12 Vpp (Q590, Gate) 150 Vpp (Q590, Drain) 0.58 Vpp (IC401, #32) 5 Vpp (IC201, #13, 14) 5.00V (Q511, Collector) 2.5 Vpp (IC401, #23) 11-2 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
  • Page 94 11 Schematic Diagrams This Document can not be used without Samsung’s authorization. LB15VS/LB17LS/LB17KS/LB17LT/LB17KT 11-2 Video Schematic Diagram PROJECT: Libra project MODEL: LB17KS/LS,LB15VS 5V_V 5V_V 15"Only 5V_V crt_sock10p BD104 BD103 1.2uH 1.2uH C109 GREEN 100nF BLUE C110 C111 C114 C115 ZD102...
  • Page 95 11 Schematic Diagrams 1.00V (IC101 #5,6,7) 1.00V (IC101 #19,20,21) 1.00 V (IC101, #24) 1.00 V (IC101, #19,20,21) 1.00 V (IC101, #1) 10.0 V (R,G,B, Video) 20.00V (CRT Socket, G1) 11-4 LB15VS/LB17LS/LB17KS/ LB17LT/LB17KT...
