Step 4 — Parameter Groups & Default Values (Continued)
80 — KEYPAD/DISPLAY (Continued)
Modbus Groups
0602H 80.03
0603H 80.04
0604H 80.05
0605H 80.06
MN04002001E
Description
Manufacturer Model
Information
Present Fault Record
Second Most Recent
Fault Record
Third Most Recent
Fault Record
Range
08: MVX001#0-4
(460V 3ph 1 hp)
09: MVX002#0-4
(460V 3ph 2 hp)
10: MVX003#0-4
(460V 3ph 3 hp)
11: MVX005#0-4
(460V 3ph 5 hp)
12: MVX007#0-4
(460V 3ph 7-1/2 hp)
13: MVX010#0-4
(460V 3ph 10 hp)
14 – 19: Reserved
20: MVXF25#0-1
(115V 1ph 1/4 hp)
21: MVXF50#0-1
(115V 1ph 1/2 hp)
22: MVX001#0-1
(115V 1ph 1 hp)
23 – 49: Reserved
50: MVX001#0-5
(575V 3ph 1 hp)
51: MVX002#0-5
(575V 3ph 2 hp)
52: MVX003#0-5
(575V 3ph 3 hp)
53: MVX005#0-5
(575V 3ph 5 hp)
54: MVX007#0-5
(575V 3ph 7-1/2 hp)
55: MVX010#0-5
(575V 3ph 10 hp)
00: No Fault occurred
01: Over-current (oc)
02: Over-voltage (ov)
03: Overheat (oH)
04: Overload (oL)
05: Overload 1 (oL1)
06: Overload 2 (oL2)
07: External Fault (EF)
08: CPU Failure 1 (CF1)
09: CPU Failure 2 (CF2)
10: CPU Failure 3 (CF3)
11: Hardware Protection Failure
(hpF)
12: Over-current During Accel (OCA)
13: Over-current During Accel (OCd)
14: Over-current During Steady
State (OCn)
15:Ground Fault or Fuse Failure
(GFF)
16: Reserved
17: 3 Phase Input Power Loss
18: External Pause Function (bb)
19: Auto Adjust Accel/Decel Failure
(cFA)
20: Software Protection Code (codE)
14
User
Default Settings
##
00
00
00
