Introduction
2.1 Converter variants
Component Rated output
power
FSB 3.0 kW
(with single fan)
4.0 kW
FSC 5.5 kW
(with single fan)
FSD 7.5 kW
(with two fans)
11 kW
15 kW
FSE 18.5 kW (HO)
(with two fans)
22 kW (LO)
22 kW (HO)
30 kW (LO)
This variant refers to the Flat Plate converter with a flat plate heatsink.
1)
"HO" and "LO" indicate high overload and low overload respectively. You can set the HO/LO mode through relevant
2)
parameter settings.
Single phase AC 230 V variants
The single phase AC 230 V converters are available in the following frame sizes.
Component
FSAA
(without fan)
FSAB
(without fan)
FSAC
(with single fan)
FSAD
(with single fan)
FSC
(with single fan)
20
Rated Rated
input output
current current
8.6 A 7.3 A
11.3 A 8.8 A
15.2 A 12.5 A
20.7 A 16.5 A
30.4 A 25 A
38.1 A 31 A
45 A 38 A
2)
54 A 45 A
54 A 45 A
72 A 60 A
Rated out- Rated input
put power current
0.12 kW 2.3 A
0.25 kW 4.5 A
0.37 kW 6.2 A
0.55 kW 7.7 A
0.75 kW 10 A
1.1 kW 14.7 A
1.5 kW 19.7 A
2.2 kW 27.2 A
3.0 kW 32 A
2.2 kW 27.2 A
3.0 kW 32 A
Output current Article number
at 480 V at
unfiltered
4kHz/40°C
7.3 A 6SL3210-5BE23-0UV0
8.24 A 6SL3210-5BE24-0UV0
11 A 6SL3210-5BE25-5UV0
16.5 A 6SL3210-5BE27-5UV0
21 A 6SL3210-5BE31-1UV0
31 A 6SL3210-5BE31-5UV0
34 A 6SL3210-5BE31-8UV0
40 A
40 A 6SL3210-5BE32-2UV0
52 A
Rated out- Article number
put current
unfiltered
0.9 A 6SL3210-5BB11-2UV1
1.7 A 6SL3210-5BB12-5UV1
2.3 A 6SL3210-5BB13-7UV1
3.2 A 6SL3210-5BB15-5UV1
4.2 A 6SL3210-5BB17-5UV1
6.0 A 6SL3210-5BB21-1UV1
7.8 A 6SL3210-5BB21-5UV1
11 A 6SL3210-5BB22-2UV1
13.6 A 6SL3210-5BB23-0UV1
11 A 6SL3210-5BB22-2UV0
13.6 A 6SL3210-5BB23-0UV0
Operating Instructions, 10/2019, A5E34559884-012
filtered
6SL3210-5BE23-0CV0
6SL3210-5BE24-0CV0
6SL3210-5BE25-5CV0
6SL3210-5BE27-5CV0
6SL3210-5BE31-1CV0
6SL3210-5BE31-5CV0
6SL3210-5BE31-8CV0
6SL3210-5BE32-2CV0
filtered
6SL3210-5BB11-2BV1
6SL3210-5BB12-5BV1
6SL3210-5BB13-7BV1
6SL3210-5BB15-5BV1
6SL3210-5BB17-5BV1
6SL3210-5BB21-1BV1
6SL3210-5BB21-5BV1
6SL3210-5BB22-2BV1
6SL3210-5BB23-0BV1
6SL3210-5BB22-2AV0
6SL3210-5BB23-0AV0
SINAMICS V20 Converter
