1 Introduction
This manual is applicable to ADTS542F/552F/553F and 554F, referred to as ADTS, and
provides safety and installation information for the Air Data Test Set, compatible with
the requirements of first line operation.
A touchscreen (ADTS Touch) is used to control all required functions. The ADTS Touch
can be positioned on the ADTS or used as a hand held mobile unit via a cable or
®
Bluetooth
program remotely while conveniently seated in the aircraft. The ADTS Touch can be
powered when positioned on the ADTS, or using a cable connection to the ADTS or
battery powered.
The manufacturer has designed this equipment to be safe when operated using the
procedures detailed in this manual.
For details of calibration requirements for the ADTS, refer to User Manual K0553.
For details of available manufacturer specified parts, refer to the current revision of the
product data sheet.
Service/maintenance and repair will be carried out at GE authorised service centres.
1.1 Intended use
Test and calibration of aircraft aeronautical pressure instruments located indoor in a
hanger or calibration laboratory or outdoor on a runway, refer to User Manual K0553
for further information.
WARNING
THIS EQUIPMENT IS NOT RATED FOR USE IN POTENTIALLY EXPLOSIVE
ATMOSPHERES. USING THIS EQUIPMENT IN A POTENTIALLY EXPLOSIVE
ATMOSPHERE COULD LEAD TO SERIOUS INJURY OR DEATH.
If the equipment is used in a manner not specified by this document and K0553 the
protection provided by the equipment may be impaired.
1.2 Safety
Examine all equipment to be used, paying particular attention to electrical leads and
connectors and pneumatic pipes and connectors. DO NOT use any equipment that is
known to be or suspected to be damaged or faulty.
1.3 Power supply
Single phase
1.4

Power supply connection

Do not apply electrical power outside the values stated.
Make sure that the power supply is off before connecting the power cable.
K0554 Revision A
wireless technology. This allows a person to complete the entire test
110/230 VAC, 50/60Hz
115 VAC, 400Hz
200 VA MAX
