Now is a good time to install accessories such as wire management, CPU holders, keyboard trays, or anything
else that fastens to the bottom of your desk. This section will cover Accessories that are included with this
Frame. For additional accessories, refer to the instructions that came with those accessories.
© UPLIFT Desk • 800-349-3839 • 512-614-3152 • info@upliftdesk.com • upliftdesk.com
Step 12
Plug the Leg closest to the Control box (C7) directly
into the white port marked "M1" which is on the same
end as the Power cable.
Plug the other leg into the Leg cable (C10), and then
plug the Leg cable into the white port on the Control
box marked "M2".
Now, plug the Keypad (C8) into the Control box port
labeled "HS".

ACCESSORY INSTALLATION

Desk Cable Management:

Use the included Cable mounts (H9) to organize your
wires, keep a clean presentation, and prevent any wires
from snagging on anything when adjusting height. The
Cable mounts work best when stuck directly to the
metal desk frame. Attach Cable mounts to the inside
of frame parts. You might want to save some for once
you have everything on your desk plugged in.
Note: Before securing all wires, check that the Frame
screw under the Control box is tight.

Installing Wire Management Tray:

Install the Wire management tray (C12) to help wrangle
your wires. Imagine where all of your wires will be once
your desk is entirely set up with all your peripherals.
We recommend placing an outlet strip into the Wire
management tray, and plugging everything on your
desk into that outlet strip to allow for cords to travel
along with the desk and only have one cable running
to a wall outlet.
Once you know where you want the tray, make a pen-
cil mark at each hole location and attach it to your
desktop using two #10x5/8'' Wood screws (H14).
If you own a drill, you can make pilot holes to make this
a little easier. Use it with a 1/8" diameter drill bit and,
ensuring that you DO NOT DRILL DEEPER THAN 1/2",
drill pilot holes where you've made your marks.
