Parker 650 Series Easy Start Manual

Ssd drives
Hide thumbs Also See for 650 Series:

Advertisement

Table of Contents

Easy Start Guide
Parker SSD Drives
650 Series Frequency Inverter
available from Parker.InverterDrive.com
This guide is intended to compliment the user manual provided by the manufacturer.
It is provided as a basic introduction to the product for Inverter Drive Supermarket customers.
It should not be used as a replacement for the manual issued by the manufacturer.
This product is not a safety device. All safety considerations including but not
limited to Emergency Stop provision should be assessed separately and are
outside the scope of this guide.
v1.0
20110321

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 650 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Parker 650 Series

Summary of Contents for Parker 650 Series

  • Page 1 Easy Start Guide Parker SSD Drives 650 Series Frequency Inverter available from Parker.InverterDrive.com This guide is intended to compliment the user manual provided by the manufacturer. It is provided as a basic introduction to the product for Inverter Drive Supermarket customers.

  • Page 2: Table Of Contents

    Easy Start Guide Parker SSD Drives 650 Series Inverter Contents Page 1 Contents Page 2 Power and Motor Connections (Single Phase) Page 3 Power and Motor Connections (Three Phase) Page 4 Motor Connections - Star and Delta Page 5 Parameters - Overview...

  • Page 3: Power And Motor Connections (Single Phase)

    Easy Start Guide Parker SSD Drives 650 Series Inverter 1. Power and Motor Connections (Single Phase) Before commencing, confirm that the Inverter and all cables are completely isolated from the power supply, have been isolated for at least 5 minutes and that the motor is not turning.

  • Page 4: Power And Motor Connections (Three Phase)

    Easy Start Guide Parker SSD Drives 650 Series Inverter 2. Power and Motor Connections (Three Phase) Before commencing, confirm that the Inverter and all cables are completely isolated from the power supply, have been isolated for at least 5 minutes and that the motor is not turning.

  • Page 5: Motor Connections - Star And Delta

    Easy Start Guide Parker SSD Drives 650 Series Inverter 3. Motor Connections - Star and Delta Dual voltage induction motors typically include The selection of Star or Delta is not optional terminal boxes with six points. The points can and must match the supply voltage.

  • Page 6: Parameters - Overview

    Easy Start Guide Parker SSD Drives 650 Series Inverter 4. Parameters - overview The Inverter contains a number of settings The parameters contain critical information which can be changed to tailor it for use in a essential to the correct operation of the wide range of applications.

  • Page 7: How To Set "Boost" - Parameter P13

    Easy Start Guide Parker SSD Drives 650 Series Inverter 6. How to set “Boost” - Parameter P13 Boost is an important parameter to set to get The procedure involves running the motor off- the best possible motor performance. load at it’s rated speed and making a note of Correctly set, it significantly improves torque at output current.
  • Page 8 Easy Start Guide Parker SSD Drives 650 Series Inverter 6.2 How to use “Motor no-load current” to set Boost correctly. 6.2.1 Reduce motor speed to 10%. Press the “E” (escape) key twice to return to the speed display. Then press and hold the down key to reduce the speed from 100% to 10%.

  • Page 9: How To Set A Parameter Value

    Easy Start Guide Parker SSD Drives 650 Series Inverter 7. How to set a Parameter value 7.1 Press and hold the “M” (Menu) key for 1 second. This example demonstrates the steps required to set parameter 6 (P6) which is motor full-load current.
  • Page 10 Easy Start Guide Parker SSD Drives 650 Series Inverter 7.5 Use the Menu, up and down keys to change the value. Press the Menu key to select the first digit. The selected digit will flash to indicate that it can be changed.

  • Page 11: How To Operate The Inverter (Local Mode)

    Easy Start Guide Parker SSD Drives 650 Series Inverter 8. How to operate the Inverter (Local mode) 8.1 Use the up and down keys to set the required speed. The display will change to show the current speed reference in percent.

  • Page 12: How To Switch From Local (Keypad) Control To

    Easy Start Guide Parker SSD Drives 650 Series Inverter 9. How to switch from Local (keypad) control to Remote (terminal) control and back 9.1 Press and hold the stop button. When the drive is in Local control mode a small hand symbol is shown on the right side of the display.

  • Page 13: How To Connect And Configure A Potentiometer For Remote Speed Control

    Easy Start Guide Parker SSD Drives 650 Series Inverter 10. How to connect and configure a Potentiometer for remote speed control If the up and down speed control buttons on A Potentiometer of 10kOhm rating should be the keypad are unsuitable for the application, a used.

  • Page 14: How To Connect And Configure A Run/Stop Switch

    Easy Start Guide Parker SSD Drives 650 Series Inverter 11. How to connect and configure a Run/Stop switch The default settings of the Inverter enable Note that once this procedure is complete, the Run/Stop operation via the red and green Run/Stop buttons on the keypad can no longer buttons on the keypad.

  • Page 15: How To Connect And Configure A Fwd/Rev Switch

    Easy Start Guide Parker SSD Drives 650 Series Inverter 12. How to connect and configure a Fwd/Rev switch The default settings of the Inverter enable Section 11 explains how to enable remote Run/Stop operation via the red and green Run/Stop via a external switch.

  • Page 16: How To Reset The Inverter To Factory Defaults

    Easy Start Guide Parker SSD Drives 650 Series Inverter 13. How to reset the Inverter to Factory Defaults 13.1 Power-on with up and down keys pressed With the power supply to the drive off, press and hold the up and down arrow keys and switch the power supply on.
  • Page 17 Easy Start Guide Parker SSD Drives 650 Series Inverter 14. Notes This guide has been produced by The Inverter Drive Supermarket Ltd. Page 16 All content, including but not limited to graphics, text and procedures copyright © The Inverter Drive Supermarket and must not be reproduced or altered without prior written permission.
