Page 1 NetEco 6000 V600R008C00 Device Installation and Commissioning Guide Issue Date 2019-03-10 HUAWEI TECHNOLOGIES CO., LTD.
Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
Page 3: About This Document
For details about southbound devices connected to the NetEco that are not described in this document, see iManager NetEco V600R007C90 Device Installation and Commissioning Guide. For details about NetEco product software commissioning, see iManager NetEco 6000 V600R008C00 Product Documentation. The figures provided in this document are for reference only.
Page 4: Change History
Added the "Creating a Temperature Sensor on the NetEco" section. Issue 01 (2018-03-21) This issue is the first official release. Issue Draft A (2017-11-27) This issue is used for first office application (FOA). Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 5: Table Of Contents
3.7.1 Installing the VCN500..............................34 3.7.2 Installing an IPC6325 Camera ............................35 3.7.3 Installing an IPC6225 Camera ............................40 3.8 Installing the Access Management System ........................43 3.8.1 Installing an A8802RS/A8804RS Access Controller ....................43 Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 6 4.3.4.7 Connecting Cables to the Location-type Water Sensor ....................89 4.3.5 Connecting the Access Management System Cable ...................... 90 4.3.5.1 Connecting a Monitoring Cable to the A8802RS or A8804RS Access Controller ..........90 Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 7 6.3.2.4 Adding a Camera on the VCN500 ..........................148 6.3.2.5 Configuring Camera Parameters on the NetEco.......................149 6.3.2.6 Registering with the OCX Plug-in ..........................151 6.3.2.7 Adding a Camera Using Automatic Discovery ......................155 6.3.3 Adding a Smart Cooling Product ..........................157 Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 8 6.4.2.3.1 Setting Monitoring Parameters for an Ambient Temperature and Humidity Sensor ..........214 6.4.2.3.2 Creating a Temperature and Humidity Sensor on the NetEco ................215 6.4.2.4 Adding a Water Leakage Sensor ..........................217 6.4.2.4.1 Creating a Water Leakage Sensor on the NetEco ....................217 Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 9 7.1.1.6 Routine Maintenance for the Region-type Water Sensor and Water Detection Cable ...........255 7.1.1.7 Routine Maintenance for the Location-type Water Sensor and Water Detection Cable ........255 7.1.2 Semi-Annual Maintenance ............................255 7.1.2.1 Routine Maintenance for the Switch .........................255 Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd. viii...
Page 10 8.4 How to log In to the ECC800 WebUI ..........................297 8.5 How to Change the Preset Password for the ECC500 Collector ...................300 8.6 How Do I Change the NetEco IP Address?........................303 Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 11 NetEco 6000 Device Installation and Commissioning Guide Contents 8.7 How Can I Commission a Device That Connects Through the ECC500 RS485 Port? ..........305 A Acronyms and Abbreviations..................310 Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 12: Safety Precautions
1.1 General Safety Precautions This section describes safety precautions for installing, operating, and maintaining a smart module. Declaration Huawei will not be liable for any consequences of the following scenarios:  Running in conditions not specified in this manual. ...
Page 13: Grounding Requirements
Only trained and qualified personnel are allowed to remove safety facilities and inspect the equipment.  Only personnel certified or authorized by Huawei are allowed to replace or change the equipment or components (including software).  Installation personnel must report faults or errors that might cause serious safety issues to related owners.
Page 14: Power Cable
To prevent electrostatic-sensitive components from being damaged by the static on human bodies, you must wear a well-grounded ESD wrist strap when touching the device or handling boards or application-specific integrated circuits (ASICs). Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 15: Battery Safety
Wear rubber gloves and a protective coat to guard against electrolyte overflow.  When handling a battery, ensure that its electrodes are upward. Placing the battery upside down or tilting the battery is prohibited. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 16 If the electrolyte leaks, immediately use the following substances to neutralize and absorb the leaked electrolyte:  NaHCO  When using substances to neutralize and absorb electrolytes, strictly follow the guidelines provided by the battery manufacturer. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 17: Mechanical Safety
To prevent injury, when moving the chassis outwards, be aware of unfixed or heavy objects on the chassis.  At least two persons are required to move the chassis. When lifting it, keep your back straight and move smoothly to avoid injury. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 18: Others
24 hours.  Handle cables with caution, especially at a low temperature. Do not drop the cables directly from the vehicle. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 19: Installation Preparations
Put them in a dry and cool environment without exposure to sunlight or electromagnetic radiation. 2.2 Personnel Requirements Only trained and qualified personnel who fully understand basic safety precautions are allowed to install and operate a Smart Module. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 20: Tools And Instruments
NetEco 6000 Device Installation and Commissioning Guide 2 Installation Preparations Huawei will not be liable for any consequence caused by the violation of this document. The requirements are as follows:  Customers' installation personnel must be trained by Huawei and understand how to install and operate a Smart Module.
Page 21 Electrician's knife Impact tool Insulation tape Needle-nose pliers Diagonal pliers RJ45 crimping tool Crimping tool Wire stripper Hydraulic pliers Wire clippers Cable tie Multimeter Electroprobe Brush Claw hammer Vacuum cleaner Hacksaw Handsaw Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 22 Table 2-2 Transportation and unpacking tools Tool Name, Specifications, and Appearance Pallet truck Diesel forklift Lifting rope (bearing Lever (bearing capacity ≥ 400 kg) capacity ≥ 400 kg) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 23: Installation Description
System Networking Figure 2-1 Device networking When the number of AI/DI ports for the ECC500 collector or the ECC800 collector is insufficient, collect the device to the independent deployment AI/DI unit. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 24 Ensure that the collector and the NetEco are installed in the same network segment. Recommended sequence of installing devices: devices inside the rack > devices outside the rack > in-room devices. The installation sequence can be adjusted based on the actual condition onsite. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 26: Installing A Server
Materials: RH2288H or RH5885 server, guide rail, rubber plug The RH2288H server is used as an example in this section to describe how to install the server. Procedure Step 1 Install guide rails. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 27 Step 2 Place the server on the guide rails and slide it along the guide rails into the cabinet. Step 3 Align the two mounting ears of the server with the rack rail of the cabinet and tighten the screws on the mounting ears. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 28 Step 4 Connect the server power cables to the PDU2000. The server uses dual power supplies. Connect the two power cables to different PDU2000s. Figure 3-5 Connecting server power cables ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 29: Installing Lan Switches
If a 24-port LAN switch is configured, one power modules or two power modules need to be installed for the LAN switch onsite. Insert the power modules into the power slots of the 24-port LAN switch, and tighten the captive screws on the power supply panel. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 30: Installing An Ecc500/Ecc800 Collector
Step 3 Secure the ECC collector in the network cabinet by clockwise tightening the M6 screws on the left and right mounting ears. Figure 3-8 Installing an ECC collector Step 4 Connect the ECC collector power cable to the PDU2000. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 31: Installing An Independent Deployment Ai/Di Unit
33 U positions in the front and rear door frames. Table 3-1 Mapping between the number of temperature sensors and the installation positions Number of temperature sensors Installation positions 22U, 33U 11U, 22U and 33U Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 32 Ensure that the temperature sensors are installed on the side without a PDU2000 on the cabinet rear.  Keep the temperature sensors facing the inside of the cabinets to ensure accurate measurement of cabinet interior temperatures. Figure 3-10 The appearance of the NTC Temperature sensor Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 33: Installing The Hydrogen Detection System
Procedure Step 1 Install four expansion bolts (M6x60) to the specified positions, align the four mounting ears of the hydrogen detection system with the expansion bolts, and tighten the M6 nuts. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 34 Figure 3-13 Figure 3-14. Pay attention to the negative and positive polarities of the power supply. If the polarities are connected incorrectly, the device may be burned. Figure 3-13 Connecting cable 1 Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 35: Installing An Sdlh-94R Dry Contact-Type Smoke Detector
Step 1 Take out the smoke detector base and mark mounting holes for the base in the appropriate position. Step 2 Drill holes and install expansion tubes. Install the smoke detector base to the top of the room. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 36: Installing An Infrared Sensor
Step 1 Take out the infrared sensor base and mark mounting holes for the base in the appropriate area. Step 2 Drill holes and install expansion sleeves as shown in Figure 3-16. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 37 Step 4 Secure the infrared sensor to the base, as shown in Figure 3-17 Figure 3-18. Determine the method for installing the infrared sensor based on the shape of the base selected. Figure 3-17 Installing an infrared sensor (method 1) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 38: Installing A Ws332M2-5 Ambient Temperature And Humidity Sensor
Step 2 Press down the strip on the ambient temperature and humidity sensor. Align the strip with the hole in the sensor base, and then secure the ambient temperature and humidity sensor to the base. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 39: Installing A Region-Type Water Sensor
A water sensor consists of a water detection cable, water detector, and conversion cable. The water detection cable is laid out on the floor, connecting to the water detector placed near the collector by the conversion cable. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 40 (1) Conversion cable end B, connecting to (2) Water detection cable end A, connecting the water detection cable to the conversion cable The water detection cable and conversion cable are interconnected through the male and female connectors. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 41 One fastener is provided for a 1 m long water detection cable. When securing the water detection cable to the concrete floor, use the cable nail clips delivered with  the cable to secure the cable. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 42 Figure 3-25 Securing a water detection cable If multiple water detection cables need to be connected in series, connect the male connector of one cable to the female connector of another cable. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 43: Installing The Location-Type Water Sensor
(2) DIN guide track  Touch grounded devices or pipes to eliminate ESD before taking the location-type water sensor module.  Place it gently. Protect it against mechanical impact and collision. Keep it dry. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 44 Step 4 Tear off the protection paper on the rear of the fastener, then securely attach the fastener to the floor. Figure 3-28 Installing a fastener 15 fasteners are furnished with the device. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 45: Installing The Video Management System
Figure 3-30 Placing the VCN500 Step 3 Tighten the captive screws on the mounting ears using a Phillips screwdriver, and then close the mounting ear buttons. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 46: Installing An Ipc6325 Camera
The camera described in this section can be installed only on a suspended ceiling if on-ceiling installation is required. Procedure Step 1 (Optional) Use a Phillips screwdriver to remove the transparent cover, install the SD card. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 47 35 mm holes in the specified positions marked by the stickers. Use a claw hammer to install an expansion bolt into the hole. Figure 3-33 Ceiling installation Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 48 Step 4 Connect the cables to the tails of the camera, perform insulation operations on the cables (see Connect Cables), and put the cables through the cable entry on the wall. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 49 2 in the figure. After the adjustment is complete, tighten the screws on the chipset. You can rotate the chipset by 90° to facilitate image adjustment. After the adjustment is complete, rotate the chipset by 90° counterclockwise to the specified angle. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 50 Step 6 Lightly press the inner cover, and fix it to the chipset. Then align the transparent cover with the base through the tapped holes, close the transparent cover, and use a Phillips screwdriver to tighten the screws. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 51: Installing An Ipc6225 Camera
A camera and tools for installing it have been prepared.  A network cable for connecting the camera to the switch has been prepared.  The switch has been normally powered on. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 52 Paste the drilling sticker in the camera installation position and ensure that the center of the sticker overlaps the center of the cable outlet on the wall. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 53 In the preceding method, the tails pass through the wall. If you do not want the tails to pass through the wall, pass the tails through the cable outlets on the base. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 54: Installing The Access Management System
If a twisted pair is connected between the access controller and the card reader, it is recommended that the distance between them do not exceed 30 m.  Install double-door and quadruple-door access controllers by referring to this section. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 55: Imanager Neteco
Step 1 Unlock the access controller with the delivered key. Figure 3-43 Unlocking an access controller Step 2 Use four screws to install the access controller on the wall. Figure 3-44 Installing an access controller ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 56: Installing An In-Room Double-Door Magnetic Lock
(1) Door frame (2) Cutout template (3) Door panel Step 3 Remove the hoisting strip using the delivered hex key. Four hex socket screws need to be removed in this step. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 57 Step 4 Secure the hosting strip using the delivered screws, as shown by (1) in Figure 3-47. Pay attention to the direction of the hoisting strip, and ensure that the bulging surface of the magnetic lock faces the magnet. Figure 3-47 Installing a magnetic lock Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 58 When securing the magnet to the door panel, do not over-tighten the screws so that the rubber pad is elastic. The rubber pad will adjust the magnet to a correct position because of its elasticity. Figure 3-49 Installing the magnet (1) Rubber pad Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 59: Installing An In-Room Single-Door Magnetic Lock
Figure 3-50. Figure 3-50 Marking mounting holes (1) Door frame (2) Cutout template (3) Door panel Step 3 Remove the hoisting strip using the delivered hex key. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 60 Step 4 Secure the hosting strip using the delivered screws, as shown by (1) in Figure 3-52. Pay attention to the direction of the hoisting strip, and ensure that the bulging surface of the magnetic lock faces the magnet. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 61 Step 5 Remove the small cover from the magnetic lock, and route the cable out of the cable hole, as shown in Figure 3-53. Figure 3-53 Connecting cables (1) Cable outlet Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 62 When securing the magnet to the door panel, do not over-tighten the screws so that the rubber pad is elastic. The rubber pad will adjust the magnet to a correct position because of its elasticity. Figure 3-55 Installing a magnet (1) Rubber pad Step 8 (Optional) Adjust the magnet. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 63: Installing A Fingerprint And Card Reader With A Keypad
Step 4 Route the cable of the fingerprint and card reader with a keypad through the cable hole in the baseplate, as shown by (4) in Figure 3-57. The fingerprint and card reader with a key pad is connected to the access actuator by a network cable. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 64: Installing A Fingerprint And Card Reader
Step 1 Remove the screws (set aside) from the fingerprint and card reader and remove the baseplate, as shown by (1) in Figure 3-59. Step 2 Mark the mounting holes using a marker, and drill holes using a hammer drill. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 65 Step 5 Check that cables are correctly connected. Step 6 Secure the fingerprint and card reader to the baseplate, as shown by (5) and (6) in Figure 3-59. Figure 3-59 Installing a fingerprint and card reader Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 66: Installing A Card Reader With A Keypad
The card reader with a keypad is connected to the access actuator by a network cable. Step 5 Check that cables are correctly connected. Step 6 Secure the card reader with a keypad to the baseplate, as shown by (5) and (6) in Figure 3-61. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 67: Installing A Exit Button
It is recommended that the product be installed 1.4–1.6 m close to the equipment room door and 1.6 m above the floor. Procedure Step 1 Remove the emergency door release button. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 68 Figure 3-63 Marking mounting holes (unit: mm) Step 3 Drill holes using a hammer drill, and route cables out of the cable hole. Step 4 Install the emergency door release button. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 69 Install the glass panel of the emergency door release button, as shown by (2) and (3) in Figure 3-64. Tighten screws for the emergency door release button using a Phillips screwdriver, as shown by (4) in Figure 3-64. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 70: Connecting Monitoring Cables To Devices
The RH2288H V3 server applies to NetEco Lite. The RH2288H V3, RH5885 V3, and 2288H V5 servers apply to NetEco Pro.  Figure 4-1 Ports on the RH2288H V3 rear panel Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 71 Used for connecting to the SMS modem or interface commissioning. Ports on the RH5885 V3 rear panel Figure 4-2 Ports on the RH5885 V3 rear panel Table 4-2 RH5885 V3 port description Interface Description Type Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 72 Used for connecting to the LAN switch. eth0 and eth1 interface comprise a bond, which is used for providing external services. eth1 GE  If southbound and northbound network isolation is interface Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 73: Installing The Sms Modem
SMS modem. Figure 4-4 Ports on the SMS modem (1) Connecting to the SIM card (2) Connecting to the antenna (3) Connecting to the power cable (4) Serial port Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 74 To install the SMS modem driver, see the specifications delivered with the SMS modem. You need to install the driver only when the installation of the driver is required in the specifications delivered with the SMS modem. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 75: Scenarios For Connecting The Lan Switch
An Ethernet optical port supports auto-sensing to 1000 Mbit/s. It sends and receives service data at 1000 Mbit/s or 10 Gbit/s. Console port The console port is connected to a console for on-site configuration. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 76: Connecting A Monitoring Cable To The Neteco
4.2.2 Connecting a Monitoring Cable to the NetEco Connect monitoring cables to the RH2288H V3/RH5885 V3/2288H V5 server, 24-port switch, and ECC500 collector Figure 4-6 RH2288H V3 server wiring diagram (ECC500 collector) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 77 NetEco 6000 Device Installation and Commissioning Guide 4 Connecting Monitoring Cables to Devices Figure 4-7 RH5885 V3 server wiring diagram (ECC500 collector) Figure 4-8 2288H V5 server wiring diagram (ECC500 collector) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 78 Connect monitoring cables to the RH2288H V3/RH5885 V3/2288H V5 server, 24-port switch, and ECC800 collector Figure 4-9 RH2288H V3 server wiring diagram (ECC800 collector) Figure 4-10 RH5885 V3 server wiring diagram (ECC800 collector) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 79 Server Signal Cable Connection Description Figure 4-12 Figure 4-13 show how signal cables are connected without and with southbound and northbound network isolation respectively. Figure 4-12 Signal cable connection without southbound or northbound network isolation Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 80: Connecting The Video Management System Cable
If the other type of power module is used onsite, the actual scenario prevails. Procedure Step 1 Connect one end of the network cable to the GE1 port on the VCN500. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 81: Connecting A Monitoring Cable To A Camera
4.2.4 Connecting the Smart Cooling Product Monitoring Cable Prerequisites A network cable used for monitoring is prepared. Context When NetCol5000C-65kW&80kW, NetCol5000-A042/A035/A020/C030/C070/C150 connect to the NetEco over Modbus-TCP, connect cables by referring to this section. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 82 For NetCol5000C-65kW&80kW, open the rear door, and connect one end of the network cable to the FE port on the main control panel of the smart cooling product. Figure 4-15 NetCol5000C-65kW&80kW main control panel (1) Main control panel Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 83 For NetCol5000-A042, NetCol8000-C070, and NetCol8000-C150, open the rear door, and connect one end of the network cable to the FE_1 port on the main control module of the smart cooling product. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 84 NetEco 6000 Device Installation and Commissioning Guide 4 Connecting Monitoring Cables to Devices Figure 4-18 Position of the NetCol5000-A042 main control module (1) Main control module Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 85 (1) Main control module Figure 4-20 Main Control Module (1) FE_1 port Step 2 Connect the other end of the network cable to the Ethernet port on the LAN switch. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 86: Connecting The Ups Monitoring Cable
4.2.5.2 Connecting the UPS5000G-A Monitoring Cable Prerequisites A network cable used for monitoring is prepared. Procedure Step 1 Connect one end of a network cable to the FE port of the UPS5000-A. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 87 NetEco 6000 Device Installation and Commissioning Guide 4 Connecting Monitoring Cables to Devices Figure 4-22 UPS5000-A-30 kVA/40 kVA functional components and control signal ports (1) FE port Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 88 Figure 4-24 FE port on the UPS monitoring module of the 300 kVA UPS and models with higher capacities (1) FE port Step 2 Connect the other end of the network cable to the Ethernet port on the switch. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 89: Connecting The Ups5000-E Or Ups5000-S Monitoring Cable
Step 2 Connect the other end of the network cable to the Ethernet port on the LAN switch. ----End 4.2.7 Connecting a Monitoring Cable to TP483000D Prerequisites A network cable used for monitoring is prepared. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 90: Connecting A Monitoring Cable To A Cim01C2
Wire stripper − Crimping tool − RJ11 crimping tool − Electrician's knife − Polyvinyl chloride (PVC) insulation tape Preparing a Cord End Terminal Figure 4-26shows how to prepare a cord end terminal. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 91 The method of preparing a dry contact monitoring cable is similar to the method of preparing the RS485 monitoring cable. Prepare cord end terminals on both ends of each required core wire based on the number of dry contacts. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 92: Port Description For Ecc500 Collector
RS485 communication card. Table 4-6 Description of indicators on the front panel of the RS485 communication card Silk Screen Color Meaning Status Description Green Power indicator Steady on The power supply is normal. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 93 Silk Screen Port Description COM1, COM2, Connect to intelligent equipment, such as the PDU8000, UPS, and and COM3 cooling equipment.  1: A  2: B  4: A  5: B Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 94 The internal circuit design of the RS485 communication card allows its COM port to support two-wire RS485 and four-wire RS422, eliminating the need to cascade cables, as shown in Figure 4-30. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 95: Ai/Di Expansion Card
AI/DI expansion card. Table 4-8 Description of indicators on the front panel of the AI/DI expansion card Silk Screen Color Meaning Status Description Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 96  12V/0.3A Provides a 12 V DC output for supplying less than 300 mA power to devices such as the audible and visual alarms.  12 V DC, 300 mA  Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 97: Connecting A Monitoring Cable To An Independent Deployment Ai/Di Unit
A maximum of two independent deployment AI/DI units can be cascaded to the COM4 or COM5  port on the ECC500.  When the number of AI/DI ports for the ECC500 collector is insufficient, collect the device to the independent deployment AI/DI unit. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 98: Connecting Sensors Cable
Step 2 Short-circuit core wires 1 and 8 on the other end of the network cable. Step 3 Connect the core wires of the network cable to the cables for the smoke sensor, based on the mappings in Table 4-10. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 99: Connecting A Monitoring Cable To The Infrared Sensor
Infrared sensor terminals Core wire 3 (green-white) +12V Core wire 8 (brown) Core wire 6 (green) ALARM Core wire 7 (brown-white) ALARM None (reserved, cable connection not TAMPER required, only insulation required) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 100: Connecting A Monitoring Cable To A Ws332M2-5 Ambient Temperature And Humidity Sensor
Step 1 Connect one end of the network cable to the RJ45 port on the tie line. Step 2 collector.Connect the other end of the network cable to the COM4/12V or COM5/12V port on the ECC500 collector. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 101: Connecting The Access Management System Cable
COM1 to COM3 ports on the ECC500 collector. Fingerprint and card reader (with a keypad) refers to the fingerprint and card reader with a keypad or  the fingerprint and card reader. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 102: Imanager Neteco
Strip the other end of the network cable and connect it to the access controller terminal, as shown in the preceding figure. If the network is non-standard, connect it by referring to the cable sequence in the following table. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 103 The following figure shows the cable connections to the access controller and card reader with a keypad, using the cord end terminal to crimp the cable. Figure 4-35 Connecting cables to the card reader with a keypad Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 104 The cable installation sequences shown in the following figure are for reference only. If any differences exist between the wiring diagram and this figure, the wiring diagram prevails. Figure 4-36 Connecting cables to the double-door magnetic lock and emergency door release button Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 105  The CH2 and CH4 terminals on the right can be connected to the door status sensor. If the door status sensor is not connected, short-circuit the ST and GND terminals. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 107: Related Information
Table 4-15 Card reader and key terminal definition Terminal Identity Definition Key input R-AL Card reader pry signal input R-BP Control card reader buzzer R-LED Control card reader LED lights R-D1 Card reader data 1 Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 108 Lock the power input + 12 V Lock the power input - Battery + Battery - +12V The controller + 12 V DC power DC input Controller DC power input- The controller 11 V AC power input Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 109 Black(7Cores: Red, Black, Yellow, Green, the access controller Orange, White, Blue), 9A, Non-shielding Cable, UL 14180327 Terminal Block, 4-Pin, Screw Fixed, 24–12 AWG, Pitch 5.08 mm, Male and Female Using Together, Only for Power Supply Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 110: Setting Monitoring Parameters For The Shengjiu_Ms899 Electronic Door Lock
When connecting the door status sensor to an ECC500 collector, you need to perform the following steps to prepare a special monitoring cable. Procedure Step 1 Open the door status sensor, connect two cables, as shown in Figure 4-40. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 111: Connecting The Smart Cooling Product Monitoring Cable
Step 1 Connect one end of the network cable to the communications port on the NetCol5000 side panel.  The COM port of NetCol5000C-65kW&80kW is on the main control panel at the smart cooling product rear doors. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 112 NetEco 6000 Device Installation and Commissioning Guide 4 Connecting Monitoring Cables to Devices Figure 4-41 NetCol5000C-65kW&80kW main control panel (1) Main control panel Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 113 Both the COM ports of NetCol5000-A042 and NetCol5000-A025 are on the main control modules at the smart cooling product rear doors. The NetCol5000-A042 is used as an example to show the position of the main control module. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 114 Figure 4-43 COM port on the main control module (1) COM port  Open the smart cooling product rear door, remove the filter, and connect the network cable to the COM port on the NetCol5000-A035. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 115 J73 on the main control module in NetCol5000-A020/NetCol5000-C030. The following figure shows the pin sequence of the network cable that connects to the J73 communications port. Figure 4-45 Pin sequence of a network cable Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 116 NetEco 6000 Device Installation and Commissioning Guide 4 Connecting Monitoring Cables to Devices Figure 4-46 NetCol5000-A020/NetCol5000-C030 communications port J73 (1) J73 (teamwork bus port and host monitoring port) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 117 (4) S2 DIP switch of the main control board Table 4-22 Operations of the DIP switch Dial Default Value Operations Switch Remaining in OFF Remaining in OFF Remaining in ON Remaining in ON Remaining in OFF Remaining in ON Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 118: Connecting The Netcol8000 Monitoring Cable
The following figure shows the pin sequence of the network cable. Figure 4-48 Pin sequence of a network cable Procedure Step 1 Open the NetCol8000 front door to expose the main control board inside the electric control box. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 119 4 Connecting Monitoring Cables to Devices Figure 4-49 Main control board of the NetCol8000-A050 (1) The main control board Figure 4-50 Main control board of the NetCol8000-A100 (1) The main control board Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 120 Figure 4-52 Main control board of the NetCol8000-C150 (1) The main control board Step 2 Connect one end of a network cable to the teamwork communications port 1 or 2 on the NetCol8000 main control board. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 121 (4) S2 DIP switch of the main control board Table 4-23 Operations of the DIP switch Dial Default Value Operations Switch Remaining in OFF Remaining in OFF Remaining in ON Remaining in ON Remaining in OFF Remaining in ON Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 122: Connecting The Ups Monitoring Cable
A network cable used for monitoring is prepared. Procedure Step 1 Connect one end of the network cable to the COM_1 or COM_2 port on the Modbus expansion card of the UPS2000-G. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 123: Connecting The Ups5000-A Monitoring Cable
4.3.7.2 Connecting the UPS5000-A Monitoring Cable Prerequisites A network cable used for monitoring is prepared. Procedure Step 1 Connect one end of a network cable to the COM port of the UPS5000-A. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 124 NetEco 6000 Device Installation and Commissioning Guide 4 Connecting Monitoring Cables to Devices Figure 4-55 UPS5000-A-30 kVA/40 kVA functional components and control signal ports (1) COM port Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 125 Figure 4-57 port on the UPS monitoring module of the 300 kVA UPS and models with higher capacities (1) COM port Step 2 Connect one end of the network cable to the COM port on the ECC collector. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 126: Connecting The Pdc Monitoring Cable
Type-PDU2000-32-1PH-20/4-M1 Prerequisites A network cable used for monitoring is prepared. Procedure Step 1 Connect one end of the network cable to the COM1 port or the COM2 port on the PDU2000. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 127: Connecting A Monitoring Cable To An Hpxpdu2000-16-3Ph-24-6-M1
A network cable used for monitoring is prepared. Procedure Step 1 Connect the monitoring cable. Connect one end of the network cable to port COM1 or COM2 on the PDU2000. Figure 4-60 shows the ports on the PDU2000. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 128: Scenarios For Connecting The Ecc800 Collector
Procedure Step 1 For details about how to connect monitoring cables to the ECC800, see the Intelligent Micro-Module Management System Wiring Diagram, visit http://e.huawei.com/, search for Smart Modular Data Center Quick Reference Guide and download it. The onsite wiring diagram of the management system prevails. The method described in this section is for reference only.
Page 130: Checking The Installation
There are excessive hair bands, lines, and other wastes. All the configured filler panels are installed. The ESD wrist strap is inserted into the ESD installation hole. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 131: Checking The Installation Of Components In The Cabinet
The ground bars and PGND bars are connected to one grounding conductor. The OT terminals at both ends of the power cables or ground cables are crimped securely. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 133: Adding Devices
NetEco Software Installation and Commissioning Guide.  For single-server scenarios, see the iManager NetEco 6000 Product Documentation. For double-server scenarios, see the iManager NetEco 6000 High Availability System Product  Documentation. Table 6-1 Encryption algorithms...
Page 134: Basic Operations Before Adding Devices
You can create Park, NetecoSite, FusionModule500, Modular, and Site under Subnet. Procedure Step 1 Choose Configuration > Configuration Management > Data Center Planning from the main menu. The Data Center Planning window is displayed. Step 2 Add managed domains. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 135 Plan Power Total power designed for Range: floating point number of 1-10000000 (kW) the created management (accurate to three decimal places) domain Description Description about the Range: 0-255 characters created management domain Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 137 Supply the created management supply from the drop-down list box. Mode domain Voltage Voltage mode of the Select 110V, 220V, or 380V from the Type(VAC) created management drop-down list box. domain Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 138: Adding A Module
You have logged in to the NetEco client by web browser  You have created an equipment room or NetEco site in Data Center Planning. For detailed operations, see Creating a Domain. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 139 Table 6-5 or retain the default values, and then click , as shown in Figure 6-2. The parameters with * are mandatory. Table 6-5 Setting modular parameters Name Description Required list Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 140 A total of five airflow types, such as the Vertical Under-Floor Air-Distribution, Horizontal Displacement Air-Distribution and Side Displacement Air-Distribution. Height Set to 2000 by default. Chooses the 2000 number or the 2200 number in the dropdown box. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 141 6-3. Figure 6-3 Deleting one module page In the displayed Confirm dialog box, click Yes.  Delete multiple modules in batches. Click on the toolbar to display the Figure 6-4 page. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 142: Scenarios For Connecting The Server
 Personal data such as phone numbers and Email addresses are anonymized in the NetEco GUI and encrypted in the NetEco during batch data transmission to ensure data security. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 143 Step 4 Click Apply to save the settings.  Click Test to check the connection between the NetEco and the SMS modem.  Click Reset to reset interworking parameters of the SMS modem. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 144: Scenarios For Connecting The Lan Switch
Step 2 Open Internet Explorer, and choose Tools > Internet Options. Step 3 Select the Advanced tab, check that Use TLS 1.1 and Use TLS 1.2 are selected, and then click OK. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 145 Click Continue to this website (not recommended) to go to the normal login page. The operation does not affect WebUI functions but has potential risks. Therefore you are advised to update the security certificate as soon as possible. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 146 CIM, refer to this section. On the CIM WebUI home page, choose Monitoring > CIM System > Running Parameter > Parallel Configuration, and select Parallel. Figure 6-9 Setting parameters for the parallel system Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 147 After the intelligent battery monitoring system is initially connected, if the SOC and SOH of CIM differ too much from those of the UPS, set SOC correction value and SOH correction value based on the reference values in the UPS. Figure 6-12 Setting basic information Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 148: Creating A Cim01C2 Collector On The Neteco
The following operations describe how to manually create a CIM01C2. Procedure Step 1 Choose Configuration > Configuration Management > Data Center Planning from the main menu. The Data Center Planning window is displayed. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 149 Step 6 Specify parameters based on Table 6-7. The CIM01C2 complying with the MODBUS-TCP protocol is used as an example. The following table lists the parameters. Figure 6-14 Setting CIM01C2 MODBUS-TCP parameters Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 150 NetEco is changed on the server. 4. Click OK. Step 7 Click Connection Test to start the connection test. Step 8 After the connection test is successful, click in the toolbar to save the device information. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 151: Cim And Bim Networking
  Blinking at super short intervals: The indicator is on for 0.05s and then off for 0.05s alternately. Figure 6-15 CIM (1) Networking switch (2) ALM indicator (3) RF_Z indicator Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 152: Adding The Video Management System
The camera IP address and the VCN service IP address must be in the same network segment.  For details about northbound IP address, see section Overview of Southbound and Northbound Network Isolation in iManager NetEco 6000 Product Documentation. 6.3.2.1 Configuring VCN500 Server Parameters 6.3.2.1.1 Changing IP Addresses of VCN500 Servers Context A default IP address is configured for a VCN500 server before delivery.
Page 153 Log in to the OMU portal of the VCN as the Admin user. Choose Maintenance > Unified Configuration. Select the server that the camera needs to access, set Module name to SCU and Parameter type to System property, and click Search. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 154: Changing The Preset Password For The Vcn500 Servers
Step 2 Click Change Password at the upper right corner, as shown in Figure 6-18. Figure 6-18 Changing a password Step 3 Enter Old Password, New Password, and Confirm Password and click Save. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 155: Commissioning Ipc6325 Cameras
Choose Settings > Network Configuration > Network Parameters, and set IP address, Subnet mask, and Gateway IP address for the camera according to the site plan. Set camera stream type, primary stream, and secondary stream 1 parameters. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 156 NetEco 6000 Device Installation and Commissioning Guide 6 Adding Devices Set coding protocol to H.265. Figure 6-20 Setting primary stream parameters Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 157: Commissioning Ipc6225 Cameras
Windows 7: Internet Explorer 8/9/10/11. Chrome 32+, and FireFox 35+ Windows 8: Internet Explorer 10/11, Chrome 32+, and FireFox 35+   Windows 10: Internet Explorer 11, Chrome 32+, and FireFox 35+ Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 158 IP address, Subnet mask, and Gateway IP address for the camera according to the site plan. Step 4 Set camera stream type, primary stream, and secondary stream 1 parameters. Set coding protocol to H.265. Figure 6-22 Setting primary stream parameters Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 159: Adding A Camera On The Vcn500
Obtain the HW_IVS_Client.exe file from the software CD-ROM delivered with the VCN. 1. Log in to the VCN OMU Portal, choose Local Configuration > Basic Method 2 Configuration, and view Current version. 2. Log in to http://support.huawei.com/enterprise/. Choose TECHNICAL Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 160: Configuring Camera Parameters On The Neteco
The Camera Management window is displayed. Step 2 In the navigation tree on the left, click Parameter Configuration. The Parameter Configuration page is displayed. Step 3 Specify parameters in the right pane based on Table 6-8. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 162: Registering With The Ocx Plug-In
Only after you register with the OCX plug-in, you can play videos recorded by the camera on the NetEco in real time. Procedure Step 1 Open Internet Explorer and choose Tools > Internet Options. Step 2 Click Security, as shown in Figure 6-24. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 163 Step 3 Add the IP address of the client to the trusted site list. Select Trusted sites and click Sites. Add the IP address of the client to the trusted site list, as shown in Figure 6-25. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 164 Ignore the message. Choose Trusted sites > From definition rank. The Security setting – trusted stand region dialog box is displayed, as shown in Figure 6-26. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 165 Restart Internet Explorer and enter the IP address to be accessed by the client. The page for watching videos is displayed. Click Install according to the prompt message. After the OCX plug-in is installed, you can watch the videos. If videos are not displayed, contact Huawei technical support.
Page 166: Adding A Camera Using Automatic Discovery
The Camera Management window is displayed. Step 2 In the left navigation tree, choose Discovery Camera. Step 3 On the Discovery camera page, add a camera by following the instructions provided in Figure 6-27. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 167 Name, and IP Address. 2. Click Search. To reset the search criteria, click Reset. Refresh the camera list On the Discovery Camera page, click Refresh. The camera information in the list is refreshed. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 168: Adding A Smart Cooling Product
000001. To ensure the access security, change the password upon first login. Step 3 Choose Comm Settings > Modbus Settings. Step 4 Set monitoring parameters. Table 6-10 Parameter description 1 Parameter Setting Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 169: Imanager Neteco
NetEco should be consistent with the address of the smart cooling product. Step 5 Go back to the home screen and choose Settings > Comm Settings > IP Settings. Step 6 Set parameters. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 170: Creating An Smart Cooling Product On The Neteco
To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-28 in the right pane based on the following table. The NetCol5000 complying with the MODBUS-TCP protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 171 6 Adding Devices Figure 6-28 Configuring parameters for the NetCol5000 MODBUS-TCP Table 6-12 MODBUS-TCP device parameter description Parameter Description Name Device name IP address Set the IP address of the device. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 172 4. Click OK. Step 7 Click Connection Test to start the connection test. Step 8 After the connection test is successful, click in the toolbar to save the device information. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 173: Adding A Ups
The UPS2000-G preset user name is admin, and the password is Changeme. Change the password after you log in for the first time for the system security. Select Configure. Select SNMPv3 as SNMP version and enter 161 for SNMP port, as shown in Figure 6-29. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 174 Record the User Name, MD5 password, and DES password for using when creating a UPS2000-G on the NetEco. You are advised to set MD5 Password and DES Password to different values. Figure 6-31 Setting SNMP parameters_03 Click Add in SNMP Trap and Permission Settings. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 175: Setting Ups5000 Monitoring Parameters (Over Snmp)
UPS WebUIs may vary slightly depending on the UPS software version. Perform operations based on the actual WebUI.  The non-encryption algorithm used in UPS5000 poses potential risks. Therefore, exercise caution when deciding to use the non-encryption algorithm. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 176 Record the values of User name, MD5 Password, and DES Password because they are required when you create a UPS5000 on the NetEco. You are advised to set MD5 Password and DES Password to different values. Click Add in SNMP Trap. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 177: Setting Ups5000 Monitoring Parameters (Over Modbus Tcp)
You have obtained the IP address, subnet mask, and default gateway planned for the UPS5000.  The UPS5000 is powered on. Context Before connecting the UPS5000 to the NetEco, set monitoring parameters, such as the IP address, on the UPS5000. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 178 Choose Monitoring > Comm. Config. > RS485 Settings, and verify that Address is set to 1 for the UPS5000. Choose Monitoring > CIM Param. > Basic Param., and verify that CIM logical start addr is set to 2 for the UPS5000. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 179: Creating A Ups On The Neteco
To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-37 in the right pane based on the following table. The UPS5000 complying with the MODBUS-TCP protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 180 Port Set this parameter to the port through which the device connects to the collector. The port number is 502 by default. You can modify the port number based on requirements. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 181 Modifying community per three months is advised. Write Community Set this parameter to the write community set on the device. (set to private by default) Modifying community per three months is advised. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 182 Step 8 After the connection test is successful, click in the toolbar to save the device information. For UPS, if a battery monitor unit (BMU) is connected, the BMU will be automatically created. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 183: Adding A Pdu
In Trap Config. page, click Add, set Trap Des. Address to the IP address of the NetEco server and set Trap Port to 162. Select SNMP Version to SNMPv3. After setting the parameters, click OK. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 184: Creating A Pdu On The Neteco
To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-39 in the right pane based on the following table. The PDU complying with the SNMPv3 protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 185 Parameter Description Name Device name IP Address Set this parameter to the device IP address. Port Set this parameter to the port number of the device. (set to 161 by default) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 186: Adding A Power Module
Before connecting TP483000D to the NetEco, set the IP address on the large-capacity power system. Procedure Step 1 Choose Setting Wizard > Comm Para on the TP483000D WebUI. Step 2 Set IP Address, Subnet Mask, and Gateway based on the planned data. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 187: Creating A Power Module On The Neteco
Step 7 Specify parameters shown in Figure 6-40 in the right pane based on the following table. The power module complying with the SNMP v3 protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 188 Parameter Description Name Device name IP Address Set this parameter to the device IP address. Port Set this parameter to the port number of the device. (set to 161 by default) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 189: Adding A Rpdu
Step 1 Use a PC with an IP address in the same network segment as that of the PDU2000. Enter http://192.168.1.45 in the address bar, and press Enter on the keyboard. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 190: Creating A Rpdu On The Neteco
To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-41 in the right pane based on the following table. The RPDU complying with the SNMP protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 191 Set this parameter to the port number of the device. (set to 161 by default) Read Community Set this parameter to the read community set on the device. (set to public by default) Modifying community per three months is advised. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 192 Timeout duration for connection test (set to 3s by default) Step 7 Click Connection Test to start the connection test. Step 8 After the connection test is successful, click in the toolbar to save the device information. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 193: Scenarios For Connecting The Ecc500 Collector
Step 2 (Optional) Install a security certificate when logging in to the page. Click Continue to this website (not recommended), as shown in Figure 6-42. Figure 6-42 Prompt message indicating an incorrect certificate Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 194 ECC500 V6 collector based on the assigned parameters for the ECC500 V6 collector, as shown in Figure 6-44. Figure 6-44 Setting ECC500 V6 collector IP address Step 5 Click Submit. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 195: Setting Pass-Through Parameters For The Ecc500 V6 Collector
The NetEco system provides a Huawei-preinstalled default certificate for commissioning the connections between network elements and the NetEco. The default certificate cannot ensure information transmission security, and must be replaced by a valid certificate from Huawei if the secure communication mode is to be enabled.
Page 196: Setting Snmp Parameters For The Ecc500 V6 Collector
Step 3 Select SNMPv3 as SNMP Version, enter 161 for SNMP Port Number, as shown in Figure 6-45. Figure 6-45 Setting SNMPv3 parameters (01) Step 4 Click Add in SNMPv3, as shown in Figure 6-46. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 197 Step 6 After you set the parameters, click Confirm. Step 7 Click Submit, as shown in Figure 6-47. Figure 6-47 Setting the SNMPv3 parameters (03) Step 8 Click Add in SNMP Trap, as shown in Figure 6-48. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 198 Step 10 Select SNMPv3 for SNMP Version and a user name for SNMPv3. Step 11 After you set the parameters, click Confirm. Step 12 Click Submit, as shown in Figure 6-49. Figure 6-49 Setting the SNMPv3 parameters (05) ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 199: Setting Rs485 Parameters For The Ecc500 V6 Collector
When COM1 Data Bit is set to 7, set COM1 Parity to Odd or Even. The value range of COM1 TimeOut is 200–10,000 ms.  Figure 6-50 Setting RS485 port parameters Step 2 (Optional) Configure the slots on the ECC500 V6 collector. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 200 V port V port number number 3211 3212 3213 3214 3215 3216 3217 3218 3219 3220 3221 3222 3223 3224 3225 3226 3227 3228 3229 3230 ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 201: Creating An Ecc500 V6 Collector On The Neteco
Step 6 Select Collector and drag the icon to the inside of the cabinet. To delete a device, click the device and choose Delete under Step 7 Specify parameters in the right pane based on the following table. Figure 6-52 shows these parameters. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 202 Set this parameter to the port number of the device. (set to 161 by default) Security Name Set this parameter to the user name added in SNMPv3 on the WebUI of the device. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 203: Adding Sensors
AI/DI_1 port of the MUE05A4 card of an ECC500 V6 collector. Set the parameters based on the actual port connected to the DSS onsite. Procedure Step 1 Log in to the WebUI of the ECC500 V6 collector. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 204 Step 5 Select Door Sensor for AI/DI_1 Sensor Type from the drop-down list, as shown in Figure 6-54. Figure 6-54 Setting the sensor type of a dry contact Step 6 Set AI/DI_1 Power Supply to On. Step 7 Click Submit. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 205: Setting Smoke Sensor And Water Leakage Sensor Parameters On The Ecc
Step 2 Choose Monitoring > MUE05A Expansion Card > MUE05A4 > Running Parameter > AI/DI_1 Port Settings. Step 3 Select Enable for AI/DI_1 Sensor. Step 4 Click Submit, as shown in Figure 6-55. Figure 6-55 Setting port enabling of a dry contact Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 206: Setting Device Monitoring Parameters Of An No/Nc Dry Contact On The Ecc
AI/DI_1 port of the MUE05A4 card of an ECC500 V6 collector. Set the parameters based on the actual port connected to the skylight controller onsite. Procedure Step 1 Log in to the WebUI of the ECC500 V6 collector. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 207 NO: indicates a normally open dry contact. The dry contact will report an alarm in the normally closed state.  NC: indicates a normally closed dry contact. The dry contact will report an alarm in the normally open state. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 208: Creating An Icon For A Door Status Sensor On The Neteco
The Property Panel dialog box is displayed, as shown in Figure 6-59. You can drag in the toolbox to create an icon for a door status sensor. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 209 Step 5 In the Basic Properties pane in the Property Panel dialog box, click ... following the Attributeto configure data for the door status sensor icon. Step 6 On the displayed Select Data page, select Managed Object and Attribute. Then, click OK. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 211: Creating The Water Sensor On The Neteco
The Toolbox dialog box is displayed. Step 3 Drag to the required position in the view. The Property Panel dialog box is displayed, as shown in Figure 6-63. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 212 Step 4 Click ... following the Attribute . In the Select Data dialog box, select managed objects and indicators. Step 5 Click OK. Step 6 Click ... following the Current Alarm. Select alarms to be bound to the icon. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 214: Modifying Alarm Names For Dry Contacts On The Neteco
Query the version of the ECC500 V6 access package as follows: Log in to the PowerEcho, choose NetEco Management > NetEco/Mediation software Installation > Installed Mediation Software, and view the version number in the list. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 215 If the dry contact is connected through an independent deployment AI/DI unit, see Table 6-25 Table 6-26 for the mapping. − If the dry contact is connected through an AI/DI expansion card, see Table 6-27 the mapping. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 216 AI/DI unit Extended Info Measurement Slot Number Port Number Communicati Tab Name on Object of the RS485 of the RS485 ons Address the NetEco Card Card of the independent deployment AI/DI unit Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 217 COM5 Info/MUE06A6 Extended COM4 Info/MUE06A7 Extended COM5 Info/MUE06A8 Table 6-26 Mapping between independent deployment AI/DI unit communications address and DIP switch Communications Address of the independent deployment AI/DI unit 7 (default) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 218: Modifying Performance Counters For Dry Contacts On The Neteco
You have logged in to the NetEco client.  You have the operation rights for Data Center Planning.  You have created an ECC500 collector in the Date Center Planning page. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 219: Adding Temperature Sensors
Step 1 Log in to the WebUI of the ECC500 V6 collector. Step 2 Choose Monitoring > MUE06A1 > Running Parameters > AI/DI_1 Port Settings. Step 3 Select Enable for AI/DI_1 Sensor. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 220 Step 5 Check whether AI/DI_1 Sensor Type is automatically identified as NTC. Figure 6-69 Setting the sensor type of an NTC sensor Step 6 Set AI/DI_1 Power Supply to On. Step 7 Click Submit. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 221: Setting Device Ip Addresses Of Temperature Sensors
The device address for the independent deployment AI/DI unit can only be set to 1 or 2.   Record the preset device IP addresses because you need to type the information in the NetEco system when adding a temperature sensor to the NetEco. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 222: Creating A Temperature Sensor On The Neteco
To delete a device, click the device and choose Delete under Step 7 Specify parameters shown in Figure 6-71 in the right pane based on the following table. NTC is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 223 AI/DI unit. Fill in the actual value by referring to Setting RS485 Parameters for the ECC500 V6 Collector. Device address The device address is configured using the DIP switch of the independent deployment AI/DI unit. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 224: Viewing A Temperature Map On The Neteco
Step 1 Choose Monitor > Topo > Data Center View from the main menu, and click the management domain for which a temperature sensor has been deployed in the navigation tree on the left. Step 2 Click to view the temperature map. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 225: Adding An Ambient Temperature And Humidity Sensor
DataBit, StopBit, and Parity on the sensor are consistent with those for the collector port. Procedure Step 1 Hold down Set on the display panel of the ambient temperature and humidity sensor for 2 seconds. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 226: Creating A Temperature And Humidity Sensor On The Neteco
To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-73 in the right pane based on the following table. The T/H sensor complying with the MODBUS-RTU protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 227 To learn ports on the ECC collector, see Setting RS485 Parameters for the ECC500 V6 Collector. Device Address Set this parameter to the address set on the device. Timeout period Timeout duration for connection test (set to 3s by default) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 228: Adding A Water Leakage Sensor
Step 6 Specify parameters shown in Figure 6-74 in the right pane based on the following table. The water leakage sensor complying with the MODBUS-RTU protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 229: Imanager Neteco
ECC500 V6 Collector. Device Address Set this parameter to the address set on the device (set to 1 by default). Timeout period Timeout duration for connection test (set to 3s by default) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 230: Adding A Hydrogen Sensor
Table 6-32 Mapping between Hydrogen Sensor communications address and DIP switch Communicati ons Address BaudRate, DataBit, StopBit and Parity on hydrogen sensor can not be set, the default setting is 9600, 8, 1 and None. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 231: Creating A Hydrogen Sensor On The Neteco
To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-75 in the right pane based on the following table. The hydrogen detector complying with the MODBUS-RTU protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 232 Timeout duration for connection test (set to 3s by default) Step 7 Click Connection Test to start the connection test. Step 8 After the connection test is successful, click in the toolbar to save the device information. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 233: Adding The Access Management System
6.4.3.3 Creating an A8802RS/A8804RS Access Controller on the NetEco Prerequisites  You have logged in to the NetEco client.  You have the operation rights for Access Control Management and Data Center Planning. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 234 Select an access controller and drag its icon to the management domain. To delete a device, click the device and choose Delete under The A8802RS access controller shown in Figure 6-76 is used as an example. Figure 6-76 Setting access controller parameters Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 235: Formatting An Access Controller
This topic describes how to format access control cards, historical records, timezones, and holidays. Prerequisites  You have logged in to the NetEco client by web browser  You have the operation rights for Access Control Management. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 236: Setting Monitoring Parameters For The Newabel Chd200G Fingerprint Controller
You have the operation rights for Data Center Planning.  You have created a management domain for the device to be added on the Data Center Planning page.  You have created an access controller on the NetEco. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 237 Step 5 Select the device to be added and drag its icon to the management domain. To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-78 in the right pane based on the following table. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 238 ECC500 V6 Collector. Device Address Set this parameter to the address set on the device (set to 1 by default). Timeout period Timeout duration for connection test (set to 3s by default). Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 239: Creating An Electronic Door Lock On The Neteco
Step 5 Select the device to be added and drag its icon to the management domain. To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-79 in the right pane based on the following table. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 240 To learn ports on the ECC collector, see Setting RS485 Parameters for the ECC500 V6 Collector. Device Address Set this parameter to the address set on the device. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 241: Adding A Smart Cooling Product
The NetCol5000 preset user name is Admin, and the password is 000001. To protect the access security, change the password after logging in to the NetCol5000 for the first time. Step 3 Press Comm Settings. Step 4 Set Baud Rate and Com address. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 242: Creating A Smart Cooling Product On The Neteco
Step 6 Specify parameters shown in Figure 6-80 in the right pane based on the following table. The NetCol5000 smart cooling product complying with the MODBUS-RTU protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 243 To learn ports on the ECC collector, see Setting RS485 Parameters for the ECC500 V6 Collector. Device Address Set this parameter to the address set on the device. Timeout period Timeout duration for connection test (set to 3s by default) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 244: Adding A Ups
Parameters for the ECC500 V6 Collector. For the UPS2000, the default values of BaudRate, DataBit, StopBit, and Parity are 9600, 8, 1, and None, respectively. If the parameters are changed, the actual parameter values prevail. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 245: Creating A Ups On The Neteco
To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-81 in the right pane based on the following table. The UPS2000 complying with the MODBUS-RTU protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 246 To learn ports on the ECC collector, see Setting RS485 Parameters for the ECC500 V6 Collector. Device address Set this parameter to the address set on the device. Timeout period Timeout duration for connection test (set to 3s by default) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 247: Adding A Pdu
Indicates the device address planned for the PDU8000. The devices with the same address cannot connect to the same port. When creating a PDU8000 on the NetEco, set Device address to the same value. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 248: Creating A Pdu On The Neteco
To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-82 in the right pane based on the following table. The PDU complying with the MODBUS-RTU protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 249 To learn ports on the ECC collector, see Setting RS485 Parameters for the ECC500 V6 Collector. Device Address Set this parameter to the address set on the device. Timeout period Timeout duration for connection test (set to 3s by default) Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 250: Adding A Rpdu
Step 7 Set RS485 port parameters for the collector based on the values of BaudRate, DataBit, StopBit, and Parity of the device. For ECC settings, see 6.4.1.4 Setting RS485 Parameters for the ECC500 V6 Collector. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 251: Creating A Rpdu On The Neteco
To delete a device, click the device and choose Delete under Step 6 Specify parameters shown in Figure 6-83 in the right pane based on the following table. The RPDU complying with the MODBUS-RTU protocol is used as an example. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 252 Set this parameter to the address set on the device. Timeout period Timeout duration for connection test (set to 3s by default) Step 7 Click Connection Test to start the connection test. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 253: Scenarios For Connecting The Ecc800 Collector
IP > gateway gateway address assigned by the network WAN_1 administrator. Step 3 Set NetEco communications parameters on the ECC800 WebUI. Table 6-46 NetEco parameters Path Parameter Default Setting Value Value Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 254: Creating An Ecc800 Collector On The Neteco
The Data Center Planning window is displayed. Step 2 Click in the upper left area of the Data Center Planning page to switch to the Uncreated Device Information page. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 255 For devices that are synchronized to the NetEco through the ECC800 for the first time, their names are different on the NetEco and web-based ECC800 client and are all the default names. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 256: Setting The Transparent Transmission Function For The Ecc800 Collector
If the port is set for the first time, you are prompted to set an authentication password. On the Set Authentication Password tab page, set Authentication password and Confirm authentication password and click Submit. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 257 Step 10 In this example, a Polymer temperature and humidity (T/H) sensor is added in the equipment room of the root node. Select the device to be added and drag its icon to the management domain. Step 11 Set management attributes. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 258 Step 13 Choose Configuration > Transmission Channel Management > Energy Controller Transparent Channel Settings. Step 14 Click Modify after selecting the IP address of the ECC800 connected to the NMS. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 259 On the ECC800 WebUI, Enable Security Authentication is set to Disable.  If Connection mode is set to Security protocol, enter the value of Confirm password that has been set on the ECC800 WebUI, and click Confirm. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 260: Device Maintenance
1s). poor contact ECC500, runs with the properly, and The ALM ECC500, is has normal indicator is faulty, or has power input. off. no power input. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 261 1s and independent card, or then off for deployment independent 1s). AI/DI unit deployment The ALM are normal. AI/DI unit is indicator is faulty or has off. abnormal power supply. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 262 AI/DI unit fails to communicate with the host. The ALM Check and indicator is clear the on, indicating alarm. that there is a critical or major alarm. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 263: Routine Maintenance For Vcn
VCN indicator. indicator is documents. steady green. 7.1.1.3 Routine Maintenance for the Smoke Detector Table 7-3 Routine Maintenance for the Smoke Detector Item Mainte Method Expected Exception Handling nance Result Interva Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 264: Routine Maintenance For The Hydrogen Detection System
Check whether Monthly The hydrogen Troubleshoot by following the hydrogen collector is working instructions in documents collector has properly, and no delivered with the hydrogen generated alarm is generated. collector. alarms. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 265: Routine Maintenance For The Infrared Sensor
1 m/s. If the red indicator turns on, the sensor enters the alarm state. If the indicator turns off, the sensor enters the monitoring state again. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 266: Routine Maintenance For The Region-Type Water Sensor And Water Detection Cable
7.1.2 Semi-Annual Maintenance 7.1.2.1 Routine Maintenance for the Switch Table 7-8 Routine maintenance for the switch Item Maintenan Method Expected Exception Handling ce Interval Result Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 267: Imanager Neteco
 Steady red: The switch does not run properly after being registered, or alarms indicating that the power supply, fan, or temperature is abnormal are generated. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 268: Routine Maintenance For Temperature Sensors
7.1.2.4 Routine maintenance for the camera Table 7-11 Routine maintenance for the camera Item Method Expected Exception Handling nten Result ance Inte rval Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 269: Routine Maintenance For The Access Control System
7.1.2.6 Routine maintenance for the double-door or four-door access controller Table 7-13 Routine maintenance for the double-door or four-door access controller Item Maintenance Method Expected Exception Interval Result Handling Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 271: Parts Replacement
Install mounting ears on a new ECC. Place the new ECC cautiously along the guide rails in the network cabinet. Push the new ECC into the cabinet until the mounting ears and cabinet side post are level. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 272: Replacing An Rs485 Or Ai/Di Expansion Card
7.2.2 Replacing an RS485 or AI/DI Expansion Card Prerequisites  An RS485 or AI/DI expansion card needs to be replaced.  Spare RS485 or AI/DI expansion cards of the same model are available and functional. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 273: Replacing An Ecc800 Main Control Module
Step 9 Reconnect the cables to the new module based on the labels. Step 10 Reconnect the ECC500 power supply. ----End 7.2.3 Replacing an ECC800 Main Control Module Context Do not operate with power on. Take appropriate insulation measures. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 274 ECC800 main control module to remove the main control module. Figure 7-3 Removing the ECC800 main control module Remove the Micro SD card and SIM card from the corresponding slots on the side of the ECC800 main control module. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 275: Replacing The Independent Deployment Ai/Di Unit
Step 1 Disconnect power supply from the independent deployment AI/DI unit. Then, remove cables that connect the independent deployment AI/DI unit, label the cables, and record where the labeled cables were connected. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 276: Replacing Sensors
Step 1 Cut the cable ties on the temperature sensor using diagonal pliers, and remove the network cable from the temperature sensor. Step 2 Install the spare temperature sensor, bind it to the original position using cable ties, and connect cables to it. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 277: Replacing The Hydrogen Detection System
Step 3 Use a Phillips screwdriver to loose nuts on the mounting ears and remove the faulty hydrogen detection system. Step 4 Align the four mounting ears of the new hydrogen detection system with the expansion bolts, and tighten the M6 nuts. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 278 Step 5 Install components and connect cables as shown in Figure 7-7 Figure 7-8. Pay attention to the negative and positive polarities of the power supply. If the polarities are connected incorrectly, the device may be burned. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 279: Replacing A Smoke Detector
A smoke detector needs to be replaced.  A spare smoke detector of the same model is available and functional. Procedure Step 1 Rotate the smoke detector to remove it from the base. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 280: Replacing An Infrared Sensor
Step 4 Connect the signal and power cables for the new infrared sensor according to the information you recorded. Step 5 Mount the new infrared sensor on the support buckle and adjust the sensor angle. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 281: Replacing A T/H Sensor
A water sensor consists of a water detection cable, water detector, and conversion cable. The water detection cable is laid out on the floor, connecting to the water detector placed near the collector by the conversion cable. Figure 7-10 shows the components. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 282 Remove the conversion cable at the conversion port for the water sensor and conversion cable. Connect a new water sensor to the conversion cable, as shown in Figure 7-11. Secure the new water sensor. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 283: Replacing A Location-Type Water Sensor And Water Detection Cable
7.2.5.7 Replacing a Location-type Water Sensor and Water Detection Cable Prerequisites  The water sensor needs to be replaced.  A spare water sensor of the same model is available and functional. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 284: Replacing The Management System
7.2.6.1 Replacing a VCN500 Prerequisites  Recommended tools: Phillips screwdriver, flat-head screwdriver  A VCN500 needs to be replaced.  A spare VCN500 of the same model is available and functional. Context Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 285 Figure 7-13. Figure 7-13 Placing a VCN500 Step 4 Tighten the captive screws in the ears using a Phillips screwdriver to close the mounting ear buttons, as shown in Figure 7-14. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 286: Replacing The Hard Disk
Pull out the hard disk for about 3 cm, wait for 30 seconds at least until the hard disk stops rotating, and pull it out. Use a screwdriver to loosen the screws from the hard disk and remove the hard disk. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 287 Close the ejector lever and push the hard disk in position. Figure 7-16 Installing a new hard disk Step 4 Observe the hard disk indicator to check whether the hard disk works properly. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 288: Replacing An Ipc6325 Camera
NetEco 6000 Device Installation and Commissioning Guide 7 Device Maintenance Follow-up Procedure If the hard disk works abnormally, contact Huawei technical support. 7.2.6.3 Replacing an IPC6325 Camera Prerequisites  The camera needs to be replaced.  A spare camera of the same model is available and functional.
Page 289: Replacing An Ipc6225 Camera
 A camera needs to be replaced.  Spare dome cameras of the same model are available and functional. Procedure Step 1 Loosen the four ST39 tapping screws on the camera. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 290: Replacing The Access Management System
Step 1 Disconnect power supply from the access controller. Then, remove cables that connect to the access controller, label the cables, and record where the labeled cables were connected. Step 2 Remove the access controller from the wall, as shown in Figure 7-20. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 291 Step 5 Install the new access controller by performing the operations prior to Step 3 in a reverse order. Step 6 Reinstall the removed cables for the access controller according to the labels and start the access controller. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 292: Replacing A Double-Door Magnetic Lock
Recommended tools and materials: crimping tool, Phillips screwdriver, hex key (delivered with the product package), step ladder (2 m). Procedure Step 1 Remove the cover of the magnetic lock, as shown in Figure 7-22. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 293 Step 2 Remove magnetic lock cables from the terminals and route the cables out of the cable holes, as shown in Figure 7-23. Figure 7-23 Removing cables Step 3 Remove the base and the magnetic lock, as shown in Figure 7-24. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 294 Step 5 Install the new magnetic lock. Remove the fixing plate from the magnetic lock using the delivered hex key as shown in Figure 7-26. The four hex socket screws should be removed in this step. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 295 If gaps exist between the electromagnets and the magnetic iron plates, rectify the fault by referring to Figure 7-27. If the magnetic iron plates are not level with each other, adjust them by using the flap shown in Figure 7-28. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 296 Device Installation and Commissioning Guide 7 Device Maintenance Figure 7-27 Adjusting the gaps between the electromagnets and the magnetic iron plates Figure 7-28 Flap for adjusting heights of magnetic iron plates Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 297: Replacing A Single-Door Magnetic Lock
Recommended tools and materials: crimping tool and Phillips screwdriver Procedure Step 1 Remove the post side panel. Step 2 Remove the installation plate of the card reader, as shown in Figure 7-29. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 298 7 Device Maintenance Figure 7-29 Removing the installation plate Step 3 Remove the screws on the card reader cover and remove the cover, as shown in Figure 7-30. Figure 7-30 Removing the cover Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 299 Step 7 Install the new card reader by performing the operations prior to Step 5 in a reverse order. Step 8 Reinstall the post side panel. ----End Follow-up Procedure Power on the access controller and check whether the card reader works properly. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 300: Replacing A Fingerprint And Card Reader
Step 1 Remove the screw that secures the fingerprint and card reader, and remove the cable, as shown by (1), (2), and (3) in Figure 7-34. Figure 7-34 Removing a bottom plate Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 301: Replacing A Card Reader With A Keypad
Figure 7-35 Card reader with a keypad Procedure Step 1 Remove the screw that secures the card reader with a keypad, and remove the cable, as shown by (1), (2), and (3) in Figure 7-36. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 302: Replacing A Fingerprint And Card Reader With A Keypad
 A fingerprint and card reader with a keypad needs to be replaced.  A spare fingerprint and card reader with a keypad of the same model is available and functional. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 303 Step 2 Remove the original bottom plate, as shown by (4) in Figure 7-38. Step 3 Take out the bottom plate of the new fingerprint and card reader with a keypad and secure it. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 304: Replacing An Emergency Door Release Button
Remove the screw that secures the emergency door release button, as shown by (1) in Figure 7-40. Remove the glass panel of the emergency door release button, as shown by (2) and (3) in Figure 7-40. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 305 Step 4 Remove the cover of the emergency door release button using a Phillips screwdriver and remove the glass. If the room door can be opened normally, the emergency door release button is functional. Step 5 Install the emergency door release button. ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 306: Faq
8.2 How Do I Handle Abnormal Door Control Status? Context If the door control status collected by the NetEco is always open, resolve the issue by following the procedure in this section. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 307: What Can I Do If The Ecc500 Collector Cannot Be Logged In On The Webui
Step 4 Deselect Use a proxy server for your LAN in the Proxy server area. Step 5 Click OK. ----End Follow-up Procedure If the ECC500 collector still cannot be logged in on the WebUI, contact Huawei technical support. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 308: How To Log In To The Ecc800 Webui
If the ECC800 connects to the Internet, and the PC in a LAN accesses the Internet over a proxy  server, do not perform Step 3.3 Step 3.4. Otherwise, you will fail to access the ECC800. Open the Internet Explorer and choose Tools > Internet Options. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 309 WebUI. Choose Tools > Compatibility View, and add the web access address to the compatibility view. Add the ECC800 IP address to the list of trusted sites. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 310 When switching between different versions of the ECC800 on your PC, you are advised to clear the historical Internet Explorer cache. Failing to do so may cause some information missed or exception after login. The following provides the details: Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 311: How To Change The Preset Password For The Ecc500 Collector
Preset passwords of the ECC500 V6 and ECC800 collectors can be modified in the same way. This topic uses the ECC500 V6 collector as an example to describe the modification method. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 312 Step 3 Enter the user name admin and the initial password 000001 or Changeme, and click Login. Step 4 Choose Maintenance > User Management. Step 5 Select the user you want to change, as shown in Figure 8-6. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 313 Step 7 Check Change Password, specify Old Password, New Password, and Confirm for the ECC500 V6 collector, and then click Confirm, as shown in Figure 8-7. Figure 8-7 Changing the password for the ECC500 V6 collector (02) ----End Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 314: How Do I Change The Neteco Ip Address
NetEco and the ECC800. Communicati Port number 31220 31220 Parameters Link to the WAN_1 WAN_1 monitoring IP address Step 3 Update the trap target IP address on the ECC500 WebUI. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 315 NetEco IP address before change in the No. column, and click Delete. Enter the NetEco server IP address in NMS addr, set Permission to Write, write 162 in Trap port, and click Add. Figure 8-9 Setting SNMP parameters_01 Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 316: How Can I Commission A Device That Connects Through The Ecc500 Rs485 Port
On the main menu, choose System Settings > SNMP Settings. Select SNMPv3 for SNMP Version and enter 161 for SNMP Port Number. Click Add in SNMPv3, set User Name, MD5/SHA Password, and DES/AES Password. Confirm MD5/SHA Password and DES/AES Password. Click Confirm. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 317 Step 2 Set A8802RS access controller parameters on the ECC500. Click Monitoring on the main menu, select the expansion card connected to the A8802RS access controller, and set parameters for the connected COM port, as shown in Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 318 The RS485 communications card can be inserted into any one or more slots among slots 1-4 on the ECC500 V6 collector. The RS485 port numbers vary based on slots. Figure 8-14 shows the ECC500 V6 collector slots. Table 8-4 shows the mappings between slots and port numbers. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 319 Set New Password and Confirm password inn the Challenge certification password area and then click Change password. Keep in mind the password that is set in Challenge certification password. The password will be used for transparent transmission settings on the NetEco. Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 320 In the displayed Modify dialog box, set Connection mode to Enable Security Authentication, set Password to the value of Challenge certification password of the ECC500, confirm the password, and click Confirm. Figure 8-16 Page for managing transparent transmission channels Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 321: A Acronyms And Abbreviations
Acronyms and Abbreviations alternating current Advanced encryption standard analog input component object model direct current Data Encryption Standard digital input digital output energy control center Ethernet fast Ethernet iBAT iBattery integrated circuit Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 322 Ethernet radio frequency Revist-Shamir-Adleman Algorithm secure digital SFTP Secure File Transfer Protocol SecureHashAlgorithm subscriber identity module short message service SNMP Simple Network Management Protocol Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.
Page 323 NetEco 6000 Device Installation and Commissioning Guide A Acronyms and Abbreviations Secure Sockets Layer Transport Layer Security uninterruptible power system universal serial bus video cloud node WiFi wireless fidelity Issue 03 (2019-03-10) Copyright © Huawei Technologies Co., Ltd.

Huawei iManager NetEco 6000 Device Installation And Commissioning Manual

About this Document

1 Safety Precautions

2 Installation Preparations

3 Installing Devices

4 Connecting Monitoring Cables to Devices

5 Checking the Installation

6 Adding Devices

7 Device Maintenance

8 Faq

Quick Links

Related Manuals for Huawei iManager NetEco 6000

Summary of Contents for Huawei iManager NetEco 6000
