IDU CONFIGURATIONS

Table 6 lists the available plug-in unit options.
Type number
NWA-055298-001
NWA-055300-xxx*)
NWA-055303-001
NWA-055303-101
NWA-060926-002-01
Sumitomo SCP6G44-GL-
CWH
NWA-060926-003-01
Finisar FCLF8521P2BTL
NWA-055294-001,-002
NWA-055310-001
CBE-009983-001,-003
NWM-034915-001
NWM-034910-001
NEC-XCB-1023-0,4
NWA-055302-001
NWA-055302-101
NWA-055304-004
NWA-055304-104
NWA-055306-001
NWA-055307-001
NWA-055289-002
Table 6. IDU cards
*) xxx = 001 (discontinued); 202 = ASIC version; 102 = PRTA version (required for L1 physical Radio Traffic Aggregation); 322 =
unified version, available 9/2012.
Limitation: the SFP modules installed in each MC-A4, GbE-A or STM1-A SFP port have to be identical or
the right port empty. Third party SFP modules do not generate an alarm (note: FW version dependent)
but correct operation is guaranteed only for an SFP delivered by NEC.
Name
MC-A4
MODEM-A
GbE-A
LX SFP
GbE T (TRI) SFP
FAN-C
PS-A4
136147-3
BLANK COVER
BLANK COVER
XPIC CABLE
16E1-A
STM1-A
MSE-A
AUX-A
CLK2M-C
Description
Control unit with
16E1(MDR) + 2GbE(RJ45)+ 2GbE(SFP) – mandatory
Modem can be installed in universal slots 1 to 4, optional.
TNC connector (female) for the ODU-cable. Grounding connector.
Modem power switch. XPIC-connectors. 512QAM supported HW-
version 2.00 and later
2GbE(T) + 2GbE(SFP) interface card for slots 1 to 4, optional
LX SFP Module 1000 Mbit/s
Electrical GbE (TRI-MODE) SFP: 10/100/1000 BASE-T
Fan unit, mandatory
Power supply unit (one mandatory, second optional)
SFP-port protecting plug
Universal Slot blank cover (mandatory when Universal Slot empty)
Power Supply blank cover (mandatory when PS not installed in slot)
XPIC cable 40 cm, two cables per XPIC modem pair
16 x E1 interface card for universal slots 1 to 4, optional
STM-1 interface card for universal slots 1 to 4
Optical Interface(S-1.1)/(L-1.1) or Electrical G.703, optional
PWE-card for universal slots 1 to 4, optional. For transporting E1 over
Ethernet packets.
Additional interfaces (ALM, EOW, NE2) , for universal slots 1 to 4,
optional.
Clock module, installed on the MC-A4 card, required for Synchronous
Ethernet and SDH-demultiplexing. Optional. Can be retrofitted in the
field.
