Respironics Millennium M10 Operating Instructions

Hide thumbs Also See for Millennium M10:

Warning: Do not use extension cords or electrical adapters

1. Select a location that allows the oxygen concentrator to

draw in room air without being restricted. Make sure that

the oxygen concentrator is at least ¼ ft. away from the

walls, furniture, and especially curtains that could impede

adequate airflow to the device. Keep away from heat.

2. Plug the power cord into an electrical outlet.

3. Connect the oxygen tubing to the oxygen outlet port.

i. You may also attach a humidification cup to the

4. Press the power switch to the On ( I ) position. Initially all

the indicator lights will turn on and the audible alarm will

sound for a few seconds. After that time, only the green

indicator light should remain lit.

5. After turning on the Oxygen Concentrator, you can begin

breathing from the device immediately; however, allow at

least 10 minutes for oxygen delivery to reach defined

specifications.

Millennium

Operating Instructions

oxygen outlet port. Make sure the cup is filled

to recommended amount and attach cannula to

hummidication cup.

M10

Table of Contents

Need help?

Do you have a question about the Millennium M10 and is the answer not in the manual?

Page 1: Operating Instructions
Millennium Operating Instructions Warning: Do not use extension cords or electrical adapters 1. Select a location that allows the oxygen concentrator to draw in room air without being restricted. Make sure that the oxygen concentrator is at least ¼ ft. away from the walls, furniture, and especially curtains that could impede adequate airflow to the device.
Page 2 6. Adjust the flow to the prescribed setting by turning the knob on the top of the flow meter until the ball is centered on the line marking the specific flow rate. 7. Be sure oxygen is flowing through the cannula. One way to check is to put the nose piece in a cup of clean water and see bubbles.
