- Page 1 Shutters Remote Control Guide Shutters Guide de la télécommande Shutters Guía de control remoto...
-
Page 2: Table Of Contents
Table of Contents Thank you for purchasing a LEVOLOR motorized ® shutter. This guide will help you set up and operate your new remote control and help you understand all functions and capabilities, allowing you to make the most of your new shutters. -
Page 3: Remote Control Buttons
Remote Control Buttons Programming Light Favorite Groupings Stop Function Arrows, Tilt Open, Tilt Closed Groupings Battery Compartment Reset Button FRONT BACK Button Key Symbol Function LED Light Color Select all shutter groups at once Groupings 1 ,2, 3, Shutter Groups Blue LED Indicator Light 4, 5, 6... -
Page 4: Explanation Of Functions
Once the shutters have been joined to a GROUP, the remote will operate your shutter. See page 8 "JOIN A SHUTTER TO A GROUP" or download the LEVOLOR App, which will easily walk you through the process. FAVORITES Setting FAVORITES stores a preferred position... -
Page 5: Travel Limit/Stops
FAVORITE position. See page 8 "Set a FAVORITE position" or download the LEVOLOR App, which will easily walk you through the process. TRAVEL LIMIT/STOPS The points when a louver stops along its travels. If the louver does not travel as expected, these limits can be adjusted by resetting the louver travel limits. -
Page 6: Levolor App Overview
Download the app to your mobile device from the Google Play or Apple App Store. The LEVOLOR App is compatible with Android (version 5.1 or newer) and Apple iOS (version 11.0 or newer). -
Page 7: Getting Started
Getting Started BATTERY PLACEMENT 1. Remove the back cover, to expose the battery compartment. 2. Use two new AAA Alkaline batteries (provided). Slide a battery into each compartment being sure to align correct positive and negative ends and press into place. 3. -
Page 8: Activating And Operating
Activating and Operating JOIN A SHUTTER TO A GROUP NOTE: The LEVOLOR remote will not operate a shutter until ® the shutter has been added to a GROUP. 1. Press and hold STOP until the WHITE programming light starts flashing, then release. This puts the remote in program mode. -
Page 9: Operating Shutters
Activating and Operating OPERATING SHUTTERS Once the shutter have been joined to a GROUP or multiple GROUPS, the remote is ready to operate the shutter(s). Multiple shutters can be operated at the same time. 1. To wake up the remote press STOP. -
Page 10: Remove A Shutter From A Group
Activating and Operating REMOVE A SHUTTER FROM A GROUP 1. Press and hold STOP until the WHITE programming light starts flashing, then release. This puts the remote in program mode. 2. Press the desired GROUP number (1, 2, 3, 4, 5 or 6) on the remote. -
Page 11: Additional Programming
Additional Programming NOTE: Without any additional programming, this remote will now operate the same set of window coverings and GROUPS as the original remote OR use the instructions on page 8 to “Join a shutter to a group” to program the second remote differently from original, to control a different set of shutters and/or different GROUPS. -
Page 12: Battery Replacement
Remote Battery Replacement REMOTE BATTERY REPLACEMENT Replacing the batteries in the remote will not cause the loss of any shutter programming, including GROUPS and FAVORITE. The remote uses two alkaline AAA batteries. To replace the batteries in the remote: 1. Slide open back of battery compartment. 2. -
Page 13: Trouble Shooting
Trouble Shooting TROUBLE SHOOTING Problem Shutter does not operate with the remote control. Solution Make sure the Indicator light on the remote control comes on when you try to operate the shutter. If the Indicator light does not come on, replace the batteries in your remote control. -
Page 14: Radio Frequency Compliance
Compliance / Warranty U.S. RADIO FREQUENCY FCC COMPLIANCE STATEMENT U.S. Radio Frequency FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 15: Warranty
Class B Digital Device Notice This Class B digital apparatus complies with Canadian ICES-003, RSS-Gen and RSS-210. WARRANTY For warranty information visit LEVOLOR.com or contact customer service at 1-800-538-6567 Remote Control Guide... - Page 16 ©2019 LEVOLOR , Inc. ® 3 Glenlake Parkway NE 18-0052-022 Atlanta, GA 30328 MK1001LEV-19...
