Nupro Freedom™
Cordless Prophy System with SmartMode™ Technology
Directions For Use
Please read carefully and completely before operating unit.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nupro Freedom and is the answer not in the manual?

Questions and answers

Related Manuals for Dentsply Sirona Nupro Freedom

Summary of Contents for Dentsply Sirona Nupro Freedom

  • Page 1 Nupro Freedom™ Cordless Prophy System with SmartMode™ Technology Directions For Use Please read carefully and completely before operating unit.

  • Page 2: Table Of Contents

    1. Indications for Use 2. Contraindictions 3. Warnings 4. Precautions 5. Adverse Reactions 6. Nupro Freedom™ Cordless Prophy System with SmartMode™ Technology Description 7. Unpacking the System 8. Infection Control Procedures 9. Charging the Cordless Handpiece and Sleep Mode 10. Powering and Charging the Optional Wireless Foot Pedal 11.

  • Page 3: Overview

    Overview The Nupro Freedom™ Cordless Prophy System with SmartMode™ Technology offers a cordless design that eliminates cord drag and allows clinicians easy access and comfort during prophylaxis procedures. SmartMode™ Technology controls the speed of the handpiece using the DPA’s pressure against the tooth, eliminating the need for a foot pedal.

  • Page 4: Precautions

    4. Precautions • Before using this product, carefully read and follow all instructions and save them for future reference. Observe all precautions and warnings. The cordless handpiece system can only be used with Nupro Freedom • ® Disposable Prophy Angles.

  • Page 5: Nupro Freedom

    6. Description of Nupro Freedom™ Cordless Prophy System with SmartMode™ Technology Nupro Freedom ® Disposable Prophy Angle Removable, Autoclavable Outer Sheath Cordless Handpiece Inner Module On/Off/Mode Button Charging Base for Cordless Handpiece (See Section 9) Charge Indicator (Charging - See Section 9)

  • Page 6: Unpacking The System

    The objective of the information provided in this section is to reduce the potential for patient cross contamination when using a Nupro Freedom™ Cordless Prophy System with SmartMode™ Technology during routine dental care. In the event any regulatory agency disagrees with this information, the agency requirements take precedence.
  • Page 7 Instructions for Steam Sterilizing the Outer Sheath (Cont.) CLEANING: MANUAL Disassemble by removing the disposable prophy angle (DPA) from the Outer Sheath, and the Outer Sheath from the inner module. Prepare enzymatic solution per manufacturer’s recommendation. Using a lint-free cloth dampened with the prepared detergent, thoroughly wet the Outer Sheath with the prepared detergent.

  • Page 8: Charging The Cordless Handpiece And Sleep Mode

    If necessary, the cordless handpiece may be “quick charged” for a single use in 15 minutes. Please note that the cordless handpiece motor will not operate when charging. Use only the Nupro Freedom™ Cordless Prophy System Power Supply and cord. Failure to do so could cause your system to malfunction and void your warranty.

  • Page 9: Powering And Charging The Optional Wireless Foot Pedal

    The optional wireless foot pedal should be charged for at least 2.5 hours prior to first use. The optional wireless foot pedal should then be recharged every month. Use only the Nupro Freedom™ Cordless Prophy System Power Supply and cord. Failure to do so could cause your system to malfunction and void your warranty.

  • Page 10: Synchronizing The Handpiece And Foot Pedal

    11. Synchronizing the Cordless Handpiece 11.7 When the Mode indicator and bottom charge Indicator begin blinking Blue alternately, the cordless handpiece and Optional Wireless Foot Pedal inner module is ready to sync. Follow this procedure when: • the optional wireless foot pedal or cordless handpiece inner module is replaced for any reason •...

  • Page 11: Preparation For Use

    Install the cordless handpiece inner module into the outer sheath by aligning the angle on each and snapping in place. 12.5 Attach a Nupro Freedom Disposable Prophy Angle ® to the cordless handpiece by aligning the swoops on each and snapping in place.

  • Page 12: Using Smartmode™ Technology And/Or Optional Wireless Foot Pedal

    12.7 Charge Status: Cordless Handpiece Charge Level Charge Indicator Color Charge Indicator Color Light Functional Description (when outside charging base) (when in charging base) Cordless Handpiece Charge is between 90%-100% Three Solid Green Three Solid Green Cordless Handpiece Charge is between 50%-89% Two Solid Green and Two Solid Green One Blinking Green...
  • Page 13 13.3.1 Apply pressure on the optional wireless foot pedal to control the rotation speed of the DPA throughout the procedure (mode Indicator turns solid Blue). By slightly increasing the pressure, the speed of the DPA cup will increase. By reducing pressure, the speed of the DPA cup will decrease. 13.3.2 To return the cordless handpiece to Standby Mode, remove pressure from the optional wireless foot pedal.

  • Page 14: Specifications

    14. Specifications Power Supply manufacturer: GLOBTEK Power Supply model number: WR9QA1200USBNMEDRVB AC Input Continuous (100-240 VAC) AC Input Current Less than 0.7A AC Input Phases Single AC Input Frequency 50-60 Hz DC Output Power DC Output Voltage and Current +5VDC at 1A Output Regulation +/- 10% Weight...

  • Page 15: Symbol Identification

    16. Symbol Identification The following standard symbols appear on the device label. Class II Equipment Class II Equipment Type B applied part MEDICAL EQUIPMENT WITH RESPECT TO ELECTRIC SHOCK, FIRE AND MECHANICAL HAZARDS ONLY IN ACCORDANCE WITH UL 60601-1CAN/CSA-C22.2 No. 601.1, ANSI/AAMI ES60601-1 (2005, 3rd ed.), CAN/CSA-C22.2 No.

  • Page 16: Disposal Of Unit

    Guidance and manufacturer’s declaration – electromagnetic immunity The Nupro Freedom™ is intended for use in the electromagnetic environment specified below. The customer or the end user of the Nupro Freedom™ should assure that it is used in such an environment.
  • Page 17 To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be con- sidered. If the measured field strength in the location in which the Nupro Freedom™ is used exceeds the applicable RF compliance level above, the Nupro Freedom™ should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the Nupro Freedom™.

  • Page 18: Troubleshooting

    4. If using an optional wireless foot pedal and it is not plugged into the Nupro Freedom Power Supply, make sure that the foot pedal is not off or discharged (see section 10). Or, you may plug the optional wireless foot pedal into the Nupro Freedom Power Supply and the wireless foot pedal will operate via the power supply.

  • Page 19: Accessories

    Nupro Freedom Disposable Prophy Angles and Nupro Freedom Prophy Packs ® ® The Nupro Freedom™ Cordless Prophy System with SmartMode™ Technology is compatible with a wide range of Nupro Freedom ® Disposable Prophy Angles and Nupro Freedom ® Prophy Packs.

  • Page 20: Limited Warranty

    The DENTSPLY Professional Nupro Freedom™ Cordless Prophy System with SmartMode™ Technology is designed exclusively for dental use and this warranty is not applicable to other uses. This warranty extends to Nupro Freedom™ systems purchased from an authorized DENTSPLY distributor, and only to the original purchaser.
