- Page 1 SW-S/D with REVOLUTION ACTIVE USER GUIDE...
- Page 3 GRADIENT SW-S/D Congratulations for your purchase of Gradient SW subwoofer system for the Gradient Revolution Active loudspeakers. This manual covers also the active crossover- amplifier and special features of the loudspeaker system. We recommend you to read this manual entirely to fully utilize the high performance of...
- Page 4 10mm wrench. If necessary, the adjustable feet can be replaced by M6 spikes. The subwoofer units should be placed on the inner or outer side of the Gradient Revolution speakers so that the distances from the listener will be within +- 0.5m (20”) (Figure 1.). However the distance between the Gradient Revolution and the subwoofer unit can be larger.
- Page 5 Revolution Revolution +/- 0.5 m Figure 1. The subwoofer units should be placed on the inner or outer side of the Gradient Revolution speakers so that the distances from the listener will be within +- 0.5m. Revolution Pre-amp Crossover-amp Figure 2. The SW unit is connected in series with the...
- Page 6 6dB more headroom. It is possible to add any number of bass sections to the system. If one wish to drive the top units of the Gradient Revolution with an external power amplifier, line level output is available for the purpose.
- Page 7 Pins are connected in the following way: Pin 1+ = SW + and Revolution Bass + Pin 1- = SW – and Revolution Bass - Pin 2+ = Revolution TOP + Pin 2- = Revolution TOP - Made in Finland by Gradient Labs Ltd www.gradient.fi...
