Medium voltage products
HD4/R - HD4/S - HD4/UniAir - HD4/UniMix - HD4/R-SEC
Installation and operating instructions
I.
6.3 Instructions for circuit-breaker operation
11. Instructions for handling apparatus containing
SF
6
13. Quality of the products and environmental
4
5
6
7
8
9
9
9
10
10
11
11
12
17
17
17
17
19
19
19
19
19
19
19
20
20
21
31
31
32
32
32
32
33
34
35
35
36
Power and productivity
for a better world
TM
Advertisement
Table of Contents
Related Manuals for ABB HD4/R
Summary of Contents for ABB HD4/R
-
Page 1: Table Of Contents
Medium voltage products HD4/R - HD4/S - HD4/UniAir - HD4/UniMix - HD4/R-SEC Installation and operating instructions Introduction 1. Packing and transport 2. Inspection on arrival 3. Storage 4. Handling 5. Description 5.1 General information 5.2 Basic configuration 5.3 Operating mechanism 5.4 Fixed circuit-breakers... - Page 3 Responsible behaviour safeguards your own and others’ safety! Please contact the ABB Assistance Service for any further requirements.
-
Page 4: Introduction
Refer to the relative instructions in order to assemble the ac- cessories and/or spare parts correctly. Similarly to all the apparatus we manufacture, the HD4/R, All the installation, putting into service, run- HD4/S, HD4/UniAir, HD4/UniMix, HD4/R-SEC circuit-breakers ning and maintenance operations must be are also designed for different installation configurations. -
Page 5: Packing And Transport
1. Packing and transport The circuit-breaker is shipped in special packing in the open position, with the springs discharged and with the absolute pressure of the pole corresponding to the service value. Each piece of apparatus is protected by a plastic cover to prevent water from infiltrating during the loading and unloading stages and to keep the dust off during storage. -
Page 6: Inspection On Arrival
Wiring diagram. Should any damage or irregularity be noted in the supply on Other documents, sent prior to shipment of the apparatus, are: unpacking, notify ABB (directly or through the agent or supplier) – Order confirmation as soon as possible and in any case within five days of receipt. -
Page 7: Storage
3. Storage When the apparatus must be stored for a certain period of substance per piece of apparatus inside the packing. time, our workshops can (on request) provide suitable packing Should the original packing no longer be available and the for the specified storage conditions. -
Page 8: Handling
4. Handling Before proceeding with any operation, always make sure that The apparatus must not be handled by in- the springs of the operating mechanism spring are discharged serting lifting devices directly under the ap- and that the apparatus is in the open position. paratus itself. -
Page 9: Description
(connector for plug- with a PR521 or REF 601 series device for protection against in circuit-breaker), basic wiring for the connection of electri- overcurrents (only REF601 for HD4/R-SEC). cal accessories. The three poles, the operating mechanism and any optional accessories used are assembled on a sturdy bearing frame. -
Page 10: Operating Mechanism
5.3 Operating mechanism 5.4 Fixed circuit-breakers The ESH operating mechanism with energy stored by means The fixed circuit-breaker (fig. 4) is the basic version, previously of preloaded springs is used for fixed or plu-in HD/4... circuit- described in sect. 5.2. There are two drilled supports in the breakers. -
Page 11: Plug-In Circuit-Breakers
IP30 version and in the reinforced version for internal arc. request) HD4/R-SEC circuit-breakers are used in UniSec switchgear. The circuit-breakers can only be racked-out in safe conditions, The device for signalling the state of the SF gas is supplied on i.e. -
Page 12: Circuit-Breaker Specifications
5.7 Circuit-breaker specifications 5.7.1 General specifications of fixed circuit-breakers with rh lateral operating mechanisms (12 - 17.5 - 24 -36 kV) Circuit-breaker HD4/R 12 HD4/R 17 HD4/R 24 HD4/R 36 Standards IEC 62271-100 • • • • CEI EN 62271-100 •... - Page 13 (Rogowsky coils) on the circuit-breaker itself, one 40/1 A closed-core toroidal TA and a -MU undervoltage release for relay-controlled opening special version with curves “ß = 1” or “ß = 1, RI” for the Belgian market: ask ABB for the availability, delivery lead times and wiring diagram at 12 and 17.5 kV and at 630 A rated current, the rated short-time withstand current is 20 kA for 1 second...
- Page 14 5.7.3 General specifications of fixed circuit-breakers with rh lateral operating mechanisms for ABB UniMix switchgear (12 - 17.5 - 24 kV) Circuit-breaker HD4/UniMix 12 HD4/UniMix 17 HD4/UniMix 24 IEC 62271-100 • • • Standards CEI EN 62271-100 • • •...
- Page 15 5.7.4 General specifications of fixed circuit-breakers with rh lateral operating mechanisms for ABB UniAir switchgear (12 - 17.5 - 24 kV) Circuit-breaker HD4/UniAir 12 HD4/UniAir 17 HD4/UniAir 24 Standards IEC 62271-100 • • • CEI EN 62271-100 • • •...
- Page 16 5.7.5 General specifications of fixed circuit-breakers with rh lateral operating mechanisms for ABB UniSec switchgear (12 - 17.5 - 24 kV) Circuit-breaker HD4/R-SEC 12 HD4/R-SEC 17 HD4/R-SEC 24 Standards IEC 62271-100 • • • CEI EN 62271-100 • • •...
-
Page 17: Instructions For Circuit-Breaker Operation
6. Instructions for operating the circuit-breaker 6.1 Safety indications HD4/... circuit-breakers guarantee a minimum IP3X degree of protection when installed in the following conditions: – fixed version, installed behind a protective metal net – plug-in version, installed in switchgear. In these conditions the operator is totally protected against accidental contact with moving parts. Pay the greatest attention to moving parts if the circuit-breaker is subjected to mechanical operations outside the switchgear or when the protective nets have been removed. - Page 18 6.3.4 Closing operation 6.3.5 Opening operation Make sure that the springs of the operating mechanism are Press the opening pushbutton (3). loaded, as indicated by the yellow signal in the window (7). Opening is displayed by the letter “O” in the green part of the Press the closing pushbutton (4).
-
Page 19: Installation
Comply with the indications in the product standards (IEC 62271-100) if other installation conditions are involved. Please 7.5 Installation of plug-in circuit-breakers contact ABB for special installation requirements. The areas through which power conductors or auxiliary circuit Plug-in circuit-breakers are designed for use in UniSwitch or conductors are routed must be protected against the access of UniAir switchgear. -
Page 20: Earthing
7.7 Earthing 7.6.2 Maximum dimensions of the connections For fixed version HD4/R circuit-breakers, the connections must – Earth fixed version circuit-breakers by means of the spe- be shaped and installed in accordance with the indications cial screw marked with the relative symbol. Clean and de-... -
Page 21: Overall Dimensions
7.9 Overall dimensions 7.9.1 Fixed HD4/R, 12 ... 24 kV, 630 ... 1250 A TN 7237 Figure 9... - Page 22 7.9.2 Fixed HD4/R, 12 ... 24 kV, 630 ... 1250 A TN 7234 Figure 10...
- Page 23 7.9.3 Fixed HD4/R, 36 kV, 630 ... 1250 A TN 7238 Type (A) 307.5 800-1250 302.5 Figure 11...
- Page 24 7.9.4 Plug-in HD4/S, 12 ...24 kV, 630 ... 1250 A TN 7236 Figure 12...
- Page 25 7.9.5 HD4/Uniair, 12 ... 24 kV, 630 ... 1250 A TN 7235 Figure 13...
- Page 26 7.9.6 HD4/Uniair-F, 12 ... 24 kV, 630 A TN 7275 Figure 14...
- Page 27 7.9.7 HD4/Uniair-2R, 12 ... 24 kV, 630 ... 1250 A TN 7274 Figure 15...
- Page 28 7.9.8 HD4/Uniair-A, 12 ... 24 kV, 630 ... 1250 A TN 7273 Figure 16...
- Page 29 7.9.9 HD4/UniMix-F, 12 ... 24 kV, 630 ... 1250 A TN 7366 Figure 17...
- Page 30 7.9.10 HD4/R-SEC, 12 ... 24 kV, 630 ... 800 A 1VCD003536 Figure 18...
-
Page 31: Putting Into Service
Carry out the following operations before putting the circuit- All the operations for putting into service breaker into service: must be carried out by ABB personnel or by – make sure that the power connections to the circuit-break- the customer’s qualified personnel. -
Page 32: Routine Inspections
Replace the coils Clean carefully. Check the insulation resistance with a 2500 • Conductive dust on the insulating parts V Megger (sect. 8.1.) Operate in the manual mode. Contact ABB if the fault • • • Operating mechanism locked persists •... -
Page 33: Servicing Operations
Replacement of parts not included in the “List of spare parts/accessories” (sect. 12.1) must only be carried out by ABB personnel. In particular: – complete pole with bushings/connections – operating mechanism –... -
Page 34: Gas
The GWP (global warming potential) of 1 kg of SF , with refer- Please contact the ABB Assistance Service for information ence to 1 kg of CO2, is calculated over a time period of 100 about how to dispose of SF gas as this operation must only years. -
Page 35: Spare Parts And Accessories
12.1 List of spare parts/Accessories All assembly operations of spare parts/ accessories must only be carried out by – Opening release ABB personnel or by the customer’s suitably – Undervoltage release qualified personnel, in compliance with the – Contact for signalling undervoltage release energised/de-... -
Page 36: Protection
ISO 14001 Standards. Aluminium foil for packaging Recycling or disposal ABB provides its skills and assistance to facilitate the recycling and disposal process for products at the end of their life. It is always necessary to comply with the local regulations when disposing of products. - Page 38 For further details please contact: ABB S.p.A. Power Products Division Unità Operativa Sace-MV Via Friuli, 4 I-24044 Dalmine Tel: +39 035 6952 111 Fax: +39 035 6952 874 E-mail: info.mv@it.abb.com www.abb.it Power and productivity for a better world...
