- Page 1 KD-X560BT MONITOR WITH RECEIVER INSTRUCTION MANUAL • Updated information (the latest Instruction Manual, etc.) is available from <http://www.jvc.net/cs/car/>. © 2019 JVC KENWOOD Corporation B5A-2953-00 (K)
-
Page 2: Table Of Contents
Preparation ........................7 Playback operations ....................7 • When you purchase optional accessories, check Function settings ....................7 with your JVC dealer to make sure that they work Tuner ..................8 with your model and in your area. Tuner Basic Operation..................8 • The Radio Data System or Radio Broadcast Data Tuner function settings ..................8... -
Page 3: Getting Started
Getting Started Initial Settings Clock settings Press an hold < > to display the general setting. Press <E>/<F> to select [ Turn the volume knob to select [Time Format], then press the knob to select the time format ([12h] or [24h]). Turn the ignition key of your car to ACC. -
Page 4: Basics
Basics Basics Volume knob (turn/press) Remote sensor Detach button Monitor Common operations Select a source Press < > to display the HOME screen. Ñ Turning on the power HOME screen appears. Press < >. Turn the volume knob to select the source, then Ñ... -
Page 5: Usb
Preparation Playback operations Ñ Connecting a USB device Open the front port cover. Connect the USB device with the USB cable. Audio files/Video files The unit reads the device and playback starts. Do this • USB maximum power supply current : Play/pause Press the volume knob. -
Page 6: Function Settings
Ñ Selecting a track in a list (Searches file) Function settings Press < > to display the LIST screen. Press < > to display the function menu. Press <E>/<F> to select whether you Turn the volume knob to select the item to set search by audio files [ ], video files [ ] or... -
Page 7: Ipod/Iphone
iPod/iPhone iPod/iPhone Ñ Source screen Preparation Ñ Connecting iPod/iPhone Open the front port cover. Connect the iPod/iPhone using the KS-U62 (optional accessory). 1 Playback status/Playing time/Total playing time Play time bar : For confirmation of current playing The unit reads the device and playback starts. position •... -
Page 8: Tuner
Tuner Tuner Tuner Basic Operation Tuner function settings Press < > to display the function menu. Turn the volume knob to select the item to set (see the table below), then press the knob to make a selection. Press < >. -
Page 9: External Components
External Components Using external audio players Rear view camera To use a rear view camera, the REVERSE lead connection is required. For connecting a rear view camera. (P.18) Ñ Displaying the picture from the rear view camera The rear view screen is displayed when you shift the gear to the reverse (R) position. -
Page 10: Bluetooth Smartphone
Bluetooth smartphone Bluetooth smartphone Ñ About the Bluetooth smartphone and Receive a phone call Bluetooth audio player This unit conforms to the following Bluetooth specifications: Version Bluetooth Ver.4.2 Profile Smartphone/ Cell-phone: HFP (Hands Free Profile) PBAP (Phonebook Access Profile) Audio player: A2DP (Advanced Audio Distribution Profile) AVRCP (Audio/Video Remote Control Profile) Sound codec... -
Page 11: Make A Phone Call
Bluetooth smartphone Make a phone call Playing Bluetooth Audio Device Press < > to enter Bluetooth mode. Press < > to display the HOME screen. Turn the volume knob to select [BT Audio], then press the knob. Do this Press the volume knob. Play/pause Select a file Press <E>/<F>... -
Page 12: Function Settings
Setup Setup Settings Function settings Press < > to display the function menu. Turn the volume knob to select the item to set (see the table below), then press the knob to make a selection. Press < > to exit. ✎... -
Page 13: Sound Settings
Setup Sound settings Bluetooth Settings Sync ON/OFF: Activates or deactivates the Phonebook synchronization of the phonebook in the connected mobile phone with the unit. Displays the information about the Information connected Bluetooth device (device name, phone name, Bluetooth version, and mac address). Press <... -
Page 14: Remote Control
Remote control This unit can be operated using the remote control. Functions of the Remote control The remote control RM-RK258 (optional accessory) Buttons can be used. • Aim the remote control directly at the remote sensor WARNING on the faceplate. •... -
Page 15: Installation
Installation Installation Before Installation • Secure the wires with cable clamps and wrap vinyl tape around the wires that comes into contact with Before installation of this unit, please note the metal parts to protect the wires and to prevent short following precautions. -
Page 16: Installing The Unit
Installation Ñ Installation procedure Ñ Trim plate 1) To prevent a short circuit, remove the key from 1) Attach accessory 1 to the unit. the ignition and disconnect the ¤ terminal of the battery. 2) Make the proper input and output wire connections for each unit. - Page 17 Installation Ñ Removing the trim plate 1) Use the extraction key (accessory 4) to lever out the four tabs (two on the left part, two on the right part). 2) Pull the trim plate forward. Ñ Removing the unit 1) Remove the trim plate by referring to step 1 in “Removing the trim plate”.
- Page 18 Installation Ñ Connecting wires to terminals Connect to the Light Green (Parking sensor wire) vehicle’s parking brake detection switch For best safety, be sure to connect the parking harness. sensor. Purple/White (Reverse sensor wire) Connect to vehicle’s reverse lamp harness when using the optional rear view camera.
- Page 19 Installation 1 3 5 7 2 4 6 8 1 3 5 7 2 4 6 8 Accessory 7 Accessory 6 Blue/White (Power control/ Antenna control wire) Connect either to the power control terminal when using the optional power amplifier, or to the power terminal for the booster amplifier of the film-type or short pole type antenna.
-
Page 20: About This Unit
About this Unit About this Unit Ñ Acceptable Video files Maintenance Video Video codec Audio codec Ñ Cleaning the Unit format MPEG-1 MPEG-1 MPEG Audio Layer 2 If the front panel of this unit is stained, wipe it with (.mpg, .mpeg) a dry soft cloth such as a silicon cloth. -
Page 21: Copyrights
• Disconnect the iPod/iPhone, then connect it again. trademarks owned by the Bluetooth SIG, Inc. • Select another source, then reselect “iPod”. and any use of such marks by JVC KENWOOD Corporation is under license. Other trademarks and The iPod/iPhone does not turn on or does not trade names are those of their respective owners. -
Page 22: Specifications
About this Unit Ñ FM tuner section Specifications Frequency Range (step) Ñ Monitor section : 87.9 MHz – 107.9 MHz (200 kHz) Frequency Response Picture Size : 30 Hz – 15 kHz : 3.0 inches (diagonal) wide Drive System Ñ AM tuner section : TFT active matrix system Frequency Range (step) Number of Pixels... - Page 23 About this Unit Ñ Audio section Maximum Power (Front & Rear) : 45 W Full Bandwidth Power (1% THD) : 17 W × 4 Speaker Impedance : 4 – 8 Ω Equalizer : 7 Band Band Frequency: 62.5/ 160/ 400/ 1k/ 2.5k/ 6.3k/ 16k Hz Level: -7 –...
- Page 25 About this Unit For Argentina FCC STATEMENT Ñ Información acerca de la eliminación 1. This device complies with Part 15 of the FCC Rules. de equipos eléctricos y electrónicos Operation is subject to the following two conditions: al final de la vida útil (aplicable a los (1) This device may not cause harmful interference, and países que hayan adoptado sistemas (2) This device must accept any interference received,...
