- Page 1 Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di istruzioni...
- Page 2 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit www.horizonhobby. com or www.towerhobbies.com and click on the support or resources tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:...
-
Page 3: Table Of Contents
Table of Contents Box Contents ..........3 Flying Checklist ........... 11 Charging Warnings......... 4 Flying the Nano S2 ........11 Battery Charging ..........4 Troubleshooting Guide ......... 12 Transmitter Setup Table (BNF) ......5 Drift Calibration..........13 Transmitter Control (RTF) ....... 7 Exploded View and Parts Listings .... -
Page 4: Charging Warnings
USB Charging Warnings The Battery Charger (EFLC1008) included with • Always monitor the charging area and have a your hovercraft has been designed to safely fire extinguisher available at all times. charge the Li-Po battery. • Always end the charging process if the battery becomes hot to the touch or starts to change WARNING: Failure to exercise caution form (swell) during the charge process. -
Page 5: Transmitter Setup Table (Bnf)
Transmitter Setup Table (BNF) DX6i SETUP LIST ADJUST LIST Model Type HELI TRAVEL ADJ D/R & Expo Swash Type 1 servo 90 Channel Travel Chan Sw Pos Expo THRO 100/100 REVERSE AILE AILE 100/100 Channel Direction ELEV 100/100 THRO ELEV RUDD 100/100 AILE... - Page 6 SYSTEM SETUP FUNCTION LIST Model Type Servo Setup HELI Chan Travel Reverse Chan Travel Reverse Swash Type Normal 100/100 Normal 100/100 Normal F-Mode Setup 100/100 Normal 100/100 Normal Switch 1 Switch B 100/100 Normal 100/100 Normal Throttle Cut -130%1 D/R & Expo Throttle Curve Channel Assign Chan Sw (F) Pos...
-
Page 7: Transmitter Control (Rtf)
Transmitter Control (RTF) Flight mode Panic switch Recovery Bind Dual rate switch switch Power LED/flight mode indicator ON/OFF Switch When pressed down, trim buttons make a sound that increases or decreases in pitch at each pressing. The middle or neutral trim position is heard as a middle tone in the pitch range of the sounds. -
Page 8: Transmitter And Receiver Binding
If you purchased an RTF model, the transmitter is bound to the model at the factory. If for any reason you need to re-bind your Nano S2 to the MLP6DSM, follow the directions below: Binding Procedure for the MLP6DSM (RTF) 1. -
Page 9: Understanding The Primary Flight Controls
Collective pitch up Collective pitch down Understanding the Primary Flight Controls If you are not familiar with the controls of your Nano S2, take a few minutes to familiarize yourself with them before attempting your first flight. Throttle Left Side View... -
Page 10: Safe ® Technology
Right Aileron left Aileron right Flight Modes The Nano S2 RTF comes with the Blade • The model will NOT return to a level MLP6DSM transmitter. This transmitter has a attitude position when you release the flight mode switch that lets the pilot change controls. -
Page 11: Panic Recovery
Nano S2 to descend rapidly. First Flight Preparation Flying Checklist ❏ Always turn the transmitter on first •... -
Page 12: Troubleshooting Guide
Tail boom is cracked Replace tail boom Poor tail authority The tail rotor blade is warped Twist rotor blade back into position or bent or replace Climb out rate is Main gear has slipped on the... -
Page 13: Drift Calibration
15 seconds, using properly, per the binding instructions. as little control input as possible to keep To calibrate the Blade Nano S2: the helicopter steady. 1. After initialization, move the transmitter 4. Land the helicopter by slowly lowering sticks to the bottom, outside corners, as the throttle. -
Page 14: Exploded View And Parts Listings
Exploded View and Parts Listings... -
Page 15: Optional Parts
& Hardware 13 BLH3308 Servo Pushrod set with Ball Links 14 BLH3309 Complete Precision Swashplate 15 BLH1305 Main Rotor Blade Set: Nano S2 16 BLH3312 Main Rotor Hub with Hardware Feathering Spindle with O-rings and 17 BLH3313 Hardware 18 BLH3314... -
Page 16: Limited Warranty
Limited Warranty What this Warranty Covers the Product on which liability is asserted. As Horizon Hobby, LLC, (Horizon) warrants to the Horizon has no control over use, setup, final original purchaser that the product purchased assembly, modification or misuse, no liability (the “Product”) will be free from defects in shall be assumed nor accepted for any result- materials and workmanship at the date of... -
Page 17: Warranty And Service Contact Information
where you can be reached during business service you are agreeing to payment of the hours. When sending product into Horizon, service without notification. Service estimates please include your RMA number, a list of the are available upon request. You must include included items, and a brief summary of the this request with your item submitted for problem. -
Page 18: Fcc Information
• Increase the separation between the Supplier’s Declaration of Conformity equipment and receiver. Blade Nano CP S V2 RTF (BLH1300) • Connect the equipment into an outlet on BRWDXMTX10 | BRWBLH1301 a circuit different from that to which the This device complies with part 15 of receiver is connected. - Page 19 ©2019 Horizon Hobby, LLC. Blade, the Blade logo, E-flite, the BNF logo, DSM, DSM2, DSMX, Safe, the SAFE logo, ModelMatch and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc.
