Razer ATHERIS Master Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

RAZER ATHERIS
MASTER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATHERIS and is the answer not in the manual?

Questions and answers

Related Manuals for Razer ATHERIS

Summary of Contents for Razer ATHERIS

  • Page 1 RAZER ATHERIS MASTER GUIDE...
  • Page 2 From the creators of the best gaming mice in the world comes Razer Atheris, the mouse optimized for both work and play. With a pocket-sized form, it'll bring your A-game whether you're on the battlefield or shuffling between meetings. The Razer Atheris is packed with features such as industry-leading...

  • Page 3: Table Of Contents

    3. TECHNICAL SPECIFICATIONS ................... 5 4. DEVICE LAYOUT ......................... 6 5. SETTING UP YOUR RAZER ATHERIS ................7 6. INSTALLING RAZER SYNAPSE FOR YOUR RAZER ATHERIS ........13 7. CONFIGURING YOUR RAZER ATHERIS ................. 14 8. SAFETY AND MAINTENANCE ..................32 9.

  • Page 4: Package Contents / System Requirements

    1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS PACKAGE CONTENTS ▪ Razer Atheris gaming mouse ▪ 2x AA batteries ▪ Wireless USB dongle ▪ Important Product Information Guide SYSTEM REQUIREMENTS PRODUCT REQUIREMENTS ▪ PC / Mac with a free USB port or Bluetooth 4.0 connectivity RAZER SYNAPSE 3 REQUIREMENTS ▪...

  • Page 5: Registration / Technical Support

    REGISTRATION Register your product online at razer-id.razerzone.com/warranty to get real-time information on your product’s warranty status. If you haven’t registered for a Razer ID yet, register now at razer-id.razerzone.com to get a wide range of Razer benefits. Your product’s serial number can be found here.

  • Page 6: Technical Specifications

    ▪ Ambidextrous design with enhanced rubber side grips ▪ Five independently programmable Hyperesponse buttons ▪ 1000 Hz Ultrapolling ▪ 2.4 GHz dongle ▪ Razer Synapse 3 enabled APPROXIMATE SIZE & WEIGHT ▪ Length: 99.7 mm / 3.9 in ▪ Width: 62.8 mm / 2.5 in ▪...

  • Page 7: Device Layout

    7,200 DPI optical sensor Default DPI stages are as follows: 800, 1800, 2400, 3600, and 7200. The DPI stages can be customized using Razer Synapse 3. ™ F O R G A ME R S . B Y G A M E R S .

  • Page 8: Setting Up Your Razer Atheris

    5. SETTING UP YOUR RAZER ATHERIS INSERTING THE BATTERIES 1. Remove the top cover of the Razer Atheris by lifting the back of the cover then pulling it out. 2. Insert the two included AA batteries into the Razer Atheris following the directions indicated on the battery compartment.
  • Page 9 LOW BATTERY NOTIFICATION The Razer Atheris’ LED indicator will blink red twice in repeated intervals to indicate that the battery level of the inserted batteries are less than 5%*. This lighting sequence will repeat until the batteries are fully drained. Once you receive this notification, it is time to replace the batteries.
  • Page 10 2. Close the top cover and connect the wireless USB dongle to the USB port of your computer. 3. Push the slider switch of the Razer Atheris to 2.4 GHz mode. The LED indicator will start blinking rapidly. 4. Wait until the mouse automatically pairs with the wireless USB dongle. When paired, the LED indicator will change to static blue for 5 seconds before turning off.
  • Page 11 Congratulations, your Razer Atheris is now ready to use in 2.4 GHz mode. CONNECTING THE RAZER ATHERIS VIA BLUETOOTH MODE 1. Push the slider switch of the Razer Atheris to Bluetooth mode ( ). 2. Press and hold the two side buttons and the DPI cycle button simultaneously for three seconds to activate pairing mode.
  • Page 12 ™ F O R G A ME R S . B Y G A M E R S .
  • Page 13 Keep the pairing devices within close proximity of each other for faster and more stable connection. Once your device has been paired, your Razer Atheris will automatically reconnect to the device whenever it is in Bluetooth mode and the device is within range.
  • Page 14 6. INSTALLING RAZER SYNAPSE 3 FOR YOUR RAZER ATHERIS Step 1: Make sure your Razer device is connected to the USB port of your computer. Step 2: Install Razer Synapse when prompted* or download the installer from razerzone.com/synapse3. Step 3: Create your Razer ID or log into Razer Synapse with an existing account.

  • Page 15: Configuring Your Razer Atheris

    Operating System. SYNAPSE TAB The Synapse tab is your default tab when you first launch Razer Synapse 3. This tab allows you to navigate the Dashboard subtab. Dashboard The Dashboard subtab is an overview of your Razer Synapse 3 where you can access all your Razer devices, modules, and online services.
  • Page 16 MOUSE TAB The Mouse tab is the main tab for your Razer Atheris. From here, you can change your device’s settings such as button assignment and DPI sensitivity. Changes made under this tab are automatically saved to your system. Customize The Customize subtab is for modifying your mouse’s button assignments.
  • Page 17 Sidebar Clicking the Sidebar button ( ) will reveal all current button assignments for your Razer Atheris. ™ F O R G A ME R S . B Y G A M E R S .
  • Page 18 Alternatively, you can skip to a specific button assignment by selecting it on the Customize tab. Upon selecting a button assignment, you may then change it to one of the following functions: Default This option enables you to return the mouse button to its original setting. Keyboard Function This option changes the button assignment into a keyboard function.
  • Page 19 Sensitivity This function allows you to manipulate the DPI setting of your Razer Atheris with a touch of a button. Listed below are the Sensitivity options and their description: ▪...
  • Page 20 ™ F O R G A ME R S . B Y G A M E R S .
  • Page 21 Switch Profile enables you to quickly change profiles and load a new set of button assignments. An on-screen notification will appear whenever you switch profiles. Razer Hypershift Setting the button to Razer Hypershift will allow you to activate Hypershift mode as long as the button is held down. Launch Program Launch Program enables you to open an app or a website using the assigned button.
  • Page 22 Windows Shortcuts This option allows you to assign the mouse button into a Windows Operating System shortcut command. For more information, please visit: http://support.microsoft.com/kb/126449 Text Function Text Function enables you to type a prewritten text with a touch of a button. Simply write your desired text on the given field and your text will be typed whenever the assigned button is pressed.
  • Page 23 Performance The Performance subtab allows you to modify the sensitivity, acceleration, and polling rate. Listed below are the performance options and their descriptions. Sensitivity Sensitivity refers to the distance the cursor will travel based on how far the mouse moved. The higher the DPI, the farther the cursor will travel given the same distance of mouse movement.
  • Page 24 Razer Atheris. Calibration The Calibration subtab allows you to optimize your Razer Precision Sensor to any surface for better tracking. To use this feature, you must click the Add A Surface option where you can select from a comprehensive list of Razer mouse mats or add your own mouse mat.
  • Page 25 Power The Power subtab allows you to manage your device’s energy consumption when running on batteries. You can also set your device to enter sleep mode when it has been idle for a certain amount of time. The Power subtab also allows you to be notified when the device’s power is at a certain level.
  • Page 26 The Profiles tab is a convenient way of managing all your profiles and linking them to your games and applications. Devices View which Razer device is using a specific profile using the Devices subtab. To create a new profile within the selected device, simply click the add button ( ). To rename, duplicate, or delete a profile, simply press the Miscellaneous button ( ).
  • Page 27 You can also sort games based on alphabetical order, last played, or most played. Added games will still be listed here even if it is not linked to a Razer device. ™...
  • Page 28 MACROS TAB If you need to accurately execute a series of complex commands then you need a Macro. A macro is a set of recorded keystrokes, button presses, and cursor movements. The Macros tab allows you to create, edit, and organize these macros so that you can assign them to your mouse buttons.
  • Page 29 To create a macro, simply select a macro name to store your commands, then click the Record menu. Assign a key or button for the macro on Shortcut Key field, select a delay, and select if you want to include mouse movement tracking. Once you have chosen the settings for the macro, click the Start button ( ).
  • Page 30 Once you have recorded a macro, you may edit the commands you have entered by selecting each command on the macro screen. Each keystroke or button press is arranged sequentially with the first command shown at the top of the screen. The Insert menu allows you to put in additional keystrokes, button presses, type texts, run commands, loop a set of commands, or insert an entire macro group.
  • Page 31 Reset tab The Reset tab allows you to perform a factory reset on all connected Razer devices with on- board memory. All profiles stored on the selected device’s on-board memory will be erased. Note: Performing a factory reset on devices without on-board memory will only create a new profile for your device on Razer Synapse 3 using the default settings.
  • Page 32 ™ F O R G A ME R S . B Y G A M E R S .

  • Page 33: Safety And Maintenance

    8. SAFETY AND MAINTENANCE SAFETY GUIDELINES In order to achieve maximum safety while using your Razer Atheris, we suggest that you adopt the following guidelines: Should you have trouble operating the device properly and troubleshooting does not work, unplug the device and contact the Razer hotline or go to razersupport.com...
  • Page 34 Razer. Some surfaces will cause undue wear on the feet requiring constant care and eventual replacement. Do note that the sensor of the Razer Atheris is ‘tuned’ or optimized especially for the Razer mouse mats. This means that the sensor has been tested extensively to confirm that the Razer Atheris reads and tracks best on Razer mouse mats.

  • Page 35: Legalese

    LIMITATION OF LIABILITY Razer shall in no event be liable for any lost profits, loss of information or data, special, incidental, indirect, punitive or consequential or incidental damages, arising in any way out of distribution of, sale of, resale of, use of, or inability to use the Product. In no event shall Razer’s liability exceed the retail purchase price of the Product.
  • Page 36 For the avoidance of doubt, in no event will Razer be liable for any costs of procurement unless it has been advised of the possibility of such damages, and in no case shall Razer be liable for any costs of procurement liability exceeding the retail purchase price of the Product.
