FOUR SEASON COVER & FLAG
ATTACHING THE FOUR SEASON COVER
STEP 5:
1. Position the four-season cover over the trailer where roll-up window is facing towards the front side
of the trailer. (Fig.12).
2. Wrap the Velcro backed fixing straps and secure the cover around the frame.
3. Secure the Velcro material at the bottom front of the cover to the matching Velcro material on the
lower front fabric panel.
FIGURE 12.
NOTE:
The four-season cover is designed to keep passengers and cargo dry and warm in inclement weather.
It also protects the passengers from flying debris. The four-season cover can be rolled up to allow for
added ventiltion in hot weather. Velcro closures keep the four-season cover in place when rolled up.
WARNING!:
Never use the trailer without the four season cover. The front window or bug screen must
be attached to protect children from flying objects.
STEP 6:
INSTALL THE SAFETY FLAG
1. Find and assemble the 3-piece safety flag.
2. Locate flag pocket in trailer cabin fabric, and insert flag in pocket a as shown (Fig14).
3. Remove flag before attempting to fold Trailer
FIGURE 14.
INSTRUCTIONAL
OWNER'S MANUAL
FIGURE 13.
9
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the T2 BIKE TRAILER and is the answer not in the manual?
Questions and answers
I can’t get my wheels back on
To reattach the wheels on an Allen Sports T2 Bike Trailer, follow these steps:
1. Tip the trailer frame to access the underside.
2. Locate the hole in the end of the hub axle.
3. Slide the quick-release (QR) pin, which is tethered to the bike frame near the wheel bracket, through the hole in the stub axle.
4. Loop the end of the pin over the shaft to secure it.
5. Repeat the process for the other wheel.
6. Ensure the QR pins are properly closed and snapped shut.
Do not use the trailer if the QR pins are missing or damaged, as improperly secured wheels may fall off.
This answer is automatically generated
