6.1 ThinkTop Basic AS-Interface setup

ThinkTop Basic Digital and AS-Interface
A printable "one page" version of ThinkTop Basic setup diagram is available on the Alfa Laval website and can easily be found
be typing the document name "ThinkTop Basic setup diagram" in the searh field.
Time- A 60 second time-out is started as soon as any
out: button(s) are released. If no button is pressed
during the time-out period, go to normal
condition (cancel & exit).
Red Active during set-up
- Flashing in step 1
LED:
- Steady in all other steps
or during operations, error condition:
- Steady showing hardware fault,
indication pin out of range
- Flashing showing software fault
Next step
"I"
Enter
"II"
set-up
"1"
"II"*
* Hold for 5 sec.
Quick set-up:
Push: "I", enter setup and wait until red LED flashes.
Push: "I", restart set-up.
Actuator in De-energized position
Push: "II", store position
Actuator in energized position
Push: "II", store position
Push: "II", when red LED is flashing (save & exit)
Set-up done.
"red" flashing
Step 1
Accept Settings
Next
Restart set-up
step
sequence
Save & Exit
Cancel & Exit, no
changes accepted
"red" steady "
green" flashing if
de-energized position
disabled "green" steady
if de-energized position
enabled
Actuator in De-energized
Position
Step 2
Set De-energized Position
"II" Store Position
"I" Bypass
"II"* Disable function
* Hold for 5 sec.
Return to step 1

6 Setup diagram

"red" steady
"yellow" flashing if energized
position disabled "yellow"
steady if energized position
enabled
Actuator in Energized
Position
Step 3
Set Energized Position
Next
"II" Store Position
step
"I" Bypass
"II"* Disable function
* Hold for 5 sec.
